Connetion Menu - TCL LE40FHDE5200 User Manual

Power off timer: use ◄/► to select Once, Daily
or Off. If you select Once or Daily, you should
set a time period after which the TV automatically
switches to off at Timer below this item. Highlight
Timer, use ◄/► to select input space, enter the
off time using the digit keys.
Sleep timer: sets a period of time after which the
TV set goes into standby mode. Use ◄/► to set
the period (120 minutes maximum). To disable this
function, select Off.
Connection Menu
Netflix
You can set the correct Time Zone for your area.
To choose a time zone:
1. Select Time > Time Zone, then press OK/► to open
Time Zone screen
2. Press ◄/► to select the time zone for your area.
3. Press the MENU button to go back to the previous
screen, or press the CLEAR button to close the
menu.
Youtube
You can set the correct Time Zone for your area.
To choose a time zone:
1. Select Time > Time Zone, then press OK/► to open
Time Zone screen
2. Press ◄/► to select the time zone for your area.
3. Press the MENU button to go back to the previous
screen, or press the CLEAR button to close the
menu.
Share & See
Note: This manual covers products with Share & See .
Share & See is DLNA-compatible.
Connecting to your PC
Make sure to set up a wired or wireless connection
from your TV to a router first. Then connect your PC to
your router either through a network cable or wirelessly.
Follow the steps in turn specified hereafter, then you
can enjoy recorded video, picture, music and/or text files
saved on your PC.
Adding media from your PC for sharing
Install a DLNA media server in your PC. The simple and
familiar server you may install is Microsoft Windows
Media Player 11. Allow your TV to share the designated
files on your PC.
1. Open Microsoft Windows Media Player 11.
- Select Library > Media sharing.
- Check the checkbox Share my media to.
- Select the icon of the TV set connected to your PC.
- Select Allow to allow the TV set to access your PC,
and select OK to enable your allowing.
Menu Operation
Note: you can push Settings button to customize
your desired settings.
2. - Select Library > Add to Libray.
- Select your personal folders or folders of other
users that you can access for sharing.
- Select Add and press OK to enable your adding.
Share & See application
1. Select Conenctions > Share & See, then press ◄/►
to select On.
2. Press Menu on the remote control and select Media,
then press OK to launch Share & See applications.
Stopping Share & See function
1. Select Conenctions > Configuration > Internet
connection, and set it to Off.
2. Or select Conenctions > Share & See, and set it to
Off.
Network connection
You can set up your TV so that it can access the Internet
through your local area network (LAN) using a wired or
wireless connection.
Connecting to a wired network
You can attach your TV to your LAN using cable in three
ways:
• You can attach your TV to your LAN by connecting
the LAN port on your TV to an external modem using
a Cat 5 cable.
• You can attach your TV to your LAN by connecting the
LAN port on your TV to a IP Sharer which is connected
to an external modem. Use Cat 5 cable for the
connection.
• Depending on how your network is configured,
you may be able to attach your TV to your LAN
by connecting the LAN port on your TV directly to a
network wall outlet using a Cat 5 cable. Note that the
wall outlet is attached to a modem or router elsewhere
in your house.
Select Connections > Configuration > Internet
connection, then select Ethernet to connect to a wired
network.
Connecting to a wireless network
To connect your TV to your network wirelessly, you need
a wireless router or modem and a Wireless LAN adapter.
Recommend connecting your Wireless Lan adapter to
your TV's USB 1 port.
1. Select Options > Network > Configuration >
Interface, then select Wireless to connect to a WiFi
wireless network.
2. Select Wireless setting and press OK/► to enter.
3. Connection Methods: you can setup the wireless
network connection three ways.
- Scan
• Select Wireless setting > Scan, then press
OK/►, the TV will scan all access points within
range. The access points found by the TV will be
displayed.
• Select an available access point, then press
OK/► to connect the TV to it.
17
