Introduction
Thank you for purchasing our portable digital video camera! This camera can be
used to shoot videos as well as take photos. Additionally, it supports SD cards of up
to 64GB capacity to extend the memory of the DVR camera.
Main Features
•
Digital Video resolutions: – 1920 x 1080 (FHD 30fsp), 1280 x 720 (HD 30 fps),
and 640 x 480 (VGA 30 fps)
•
mega-pixel camera, providing 10 definitions:
5600 x 4200 (24M), 5200 x3900(20M)，4640 x 3480 (16M), 4000 x 3000 (12M),
3648 x 2736 (10M), 3648 x 2048 (7MHD), 2592 x 1944 (5M), 2048 x 1536 (3M),
1920 x 1080 (2MHD) and 640 x 480 (VGA)
•
3.0" touchscreen, LCD
•
16x digital zoom
•
External high sensitivity microphone
•
External Hot Shoe
•
HDMI output
•
WIFI
1
•
Supports VGA (Video Graphics Array)
•
USB ports
•
CD-ROM drive
Getting to Know Your Camera
Power buton
Light compensating lamp
Lens
Self-timer lamp
LCD Touchscreen
Status indicator
MIC/HDMI/USB
W/T(Zoom Out/Zoom In)
Record Button
4
•
Supports remote control
•
Supports LED light-compensating lamp
•
Supports 64GB external SD card (Grade 6 or above strongly recommended)
•
Internal microphone and speaker
•
can be used to shoot videos and take photos
•
Supports deleting, protecting and printing of photos on the camera
Packing List
•
High-Definition digital camera
•
USB cable
•
User manual
•
Warranty card
•
HDMI Cable
•
Remote control
•
Charger
•
Battery
Mode Button
Light
button
DISP button
Mic Menu button
Preparing Your Camcorder for Use
Installing the Battery
Your DVR camcorder requires 1 pc Lithium battery;
1.
Open the battery compartment on the side of the camera.
2.
Insert the battery with the correct polarity as indicated.
3.
Replace the battery compartment cover.
Photo Button
4.
Press the power button to turn on the camera. The battery status icon will display
at the right bottom corner of the LCD screen.
2
5
