Continental AG I BS PG3 CFRF WM User Manual of the Continental Radio Frequency Transmitter Type Page 1 of 7...
Page 2
Continental AG I BS PG3 CFRF WM 1. GENERAL DESCRIPTION OF THE RF TRANSMITTER The Acura fob is a transmitter designed to provide remote keyless entry, passive entry, passive engine start, and immobilization functionality. The term that Honda uses to describe such a transmitter is a SMART fob. The Acura fob MY18 is initially going to launch in North America on the platform RDX.
Continental AG I BS PG3 CFRF WM Technical Description The components which constitute the Acura MY18 RDX fob are: • Power Supply • Microcontroller • User Interfaces • LF Antenna (3D-Antenna in one SMD) • RF Antennas • The PCB is 4 layer Pb-Free FR4 with double-sided component placement.
Page 4
Continental AG I BS PG3 CFRF WM Variants Matrix: chromated buttons (Acura) Button config (second digit) 433 MHz 1-1-1-P 2-2-1-P Not used 1b-1b-P Not used 1-1-2-P Not used 1-1-1-x 2-2-1-x Not used 1b-1b-x Not used 1-1-2-x Not used Page 4 of 7...
< 10 mW Channel 2: 434,18 MHz 6. LABEL DESIGN USA and Canada: Continental Model: T2x FCC ID:KR5T2X IC:7812D-T2X Owner Manual Canada: Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Page 6
Continental AG I BS PG3 CFRF WM Page 6 of 7...
