70m 1x4 HDBaseT Splitter, HDCP2.2 compliant
Support POC, RS232 Pass through
Features
•Incorporate HDBaseT technology
•Distribute 1Ultra HD HDMI signal to 4 identical HDBaseT outputs, with 1x loop HDMI output
•Transmitter Distance up to 70m under 1080p, 40m under 4K
•HDCP 2.2/1.4 compliant
•Support resolution to 4K@60Hz, YUV 4:2:0, VESA resolution up to 1920x1200
•Support Dolby TrueHD, DTS-HD Master Audio
•With wide-band Bi-Directional IR control (38 ~ 56 kHz)
(IR extension from Sender to Receiver or from Receiver to Sender)
•HDBaseT output 1 supports RS232 and Ethernet pass through
•Support 3D
•Support POC (Receiver powered by HDBaseT Splitter)
•DC 12V power supply
Operating Instructions
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SX-SPH04-70 and is the answer not in the manual?

Questions and answers

Summary of Contents for Foxun SX-SPH04-70

  • Page 1 Operating Instructions 70m 1x4 HDBaseT Splitter, HDCP2.2 compliant Support POC, RS232 Pass through Features •Incorporate HDBaseT technology •Distribute 1Ultra HD HDMI signal to 4 identical HDBaseT outputs, with 1x loop HDMI output •Transmitter Distance up to 70m under 1080p, 40m under 4K •HDCP 2.2/1.4 compliant •Support resolution to 4K@60Hz, YUV 4:2:0, VESA resolution up to 1920x1200 •Support Dolby TrueHD, DTS-HD Master Audio...
  • Page 2 Operating Instructions Operating Instructions TABLE OF CONTENTS Package Contents Dimensional drawing Panel Descriptions Connecting and Operating Applications Maintenance Product Service Warranty Packing contents 1) Main Unit: 1x4 HDBaseT Splitter 2) 2x Power supply DC 12V 3) 4x IR-TX cable 4) 4x IR-RX cable 5) 1x Phoenix plugs for RS232 cable termination 6) 4x screws 7) 2x detachable mounting ears...
  • Page 3 Operating Instructions Operating Instructions VESA Resolution Refresh rate VESA Resolution 640x480 59.94Hz 640x480 800x600 1024x768 1280x768 1280x960 60Hz 1280x1024 1680x1050 1920x1080 1280x720 1360x768 1400x1050 1920x1200 Dimensional drawing...
  • Page 4 Operating Instructions Operating Instructions 4) Connect 4pcs IR TX cables to the IR-TX sockets on the splitter and connect 4pcs IR RX cables to the IR-RX sockets on the splitter. 5) Connect IR RX cable to IR-In port of Receiver, connect IR TX cable in to IR-Out port of Receiver. Front Panel 6) Power up all units, the splitter,Receiver, sources and displays.
