Summary of Contents for Promise Thunderbolt 3 Dock TD-300
- Page 1 Thunderbolt™ 3 Dock TD-300 Product Manual...
-
Page 2: Safety Instructions
Before attempting to connect, operate or adjust this product, please save and read the User’s Manual completely. The style of the product shown in this User’s Manual may be different from the actual unit due to various models. Safety Instructions Always read the safety instructions carefully: •... - Page 3 Copyright This document contains proprietary information protected by copyright. All right are reserved. No part of this manual may be reproduced by any mechanical, electronic or other means, in any form, without prior written permission of the manufacturer. Trademarks All trademarks and registered trademarks are the property of their respective owners or companies.
-
Page 4: Regulatory Compliance
Regulatory Compliance FCC Conditions This equipment has been tested and found to comply with Part 15 Class B of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received and include interference that may cause undesired operation. -
Page 5: Table Of Contents
Contents ..............1 ntroductIon ................ 1 eatures ............2 ackage ontents ............. 2 ystem equirements ..............2 PeciFications ..............3 ardware ............ 5 isPlay conFiguration ........... 5 ulti monitor conFiguration os ..............5 inDoWs ..............6 xtenD ............7 roubleshooting macos ................ -
Page 6: Introduction
Introduction The Thunderbolt™ 3 Dock TD-300 provides extra connectivity and versatility to various peripherals for your computer. Connections for Thunderbolt devices, HDMI monitor, USB 3.0 devices, Ethernet, SD memory card, and audio speakers, headphones and microphone are all available in this compact docking station. -
Page 7: Package Contents
Package Contents » » Thunderbolt™ 3 Dock TD-300 » » AC/DC Adapter Input: 100-240V Output: 20V/6.75A » » Quick Start Guide » » Thunderbolt™ 3 Cable (50 cm/19.7 inch) System Requirements Supported Operating System ® » » Windows ® » » macOS Specifications Interface Thunderbolt 3, 2 ports... -
Page 8: Hardware
Hardware # Front Panel Description Power LED This will light green when the power cable is attached and the device is receiving power. Thunderbolt 3 This will light blue when there is a valid link LED Thunderbolt 3 connection established. SD 3.0 Insert SD memory card for data transfer. -
Page 9: Rear Panel
# Rear Panel Description USB 3.0 Use USB cable with Type A connector to connect USB 3.0 devices. USB 3.0 is backward compatible with older USB devices. Gigabit Ethernet Use Ethernet cable to connect to local network for network and Internet access. Thunderbolt 3 Use Thunderbolt 3 cable to connect Thunderbolt 3 equipped monitor or other... -
Page 10: Display Configuration
Display configuration Multi-monitor configuration Once»the»extra»monitors»are»connected,»they»can»be»configured» to Mirror mode, Extend mode or set the primary display. Windows OS To»change»display»settings»for»multi-monitor»configuration»in» Windows, follow these steps: 1. Position the mouse anywhere on the Windows Desktop, 2. Right-click and select Display Settings. -
Page 11: Extend Mode
Extend Mode 1. Access Display Settings menu (see ”Multi-monitor configuration”»on»page»5). 2. Select the preferred monitor at top of the page. 3. Select Multiple Displays > Extend these displays. 4. Click Apply»to»confirm»and»exit. 5. Once the setting is completed, simply drag and drop the application icons or the opened windows to the add-on monitor. -
Page 12: Troubleshooting
Troubleshooting Cursor disappeared If the status remains in the extended mode but the docking station is disconnected, the desktop will still be panned to the add-on monitor. The cursor may not be found on the primary monitor in such a case. If it happens, connect the add-on monitor through the docking station again or keep moving the mouse. - Page 13 Set the Primary Monitor 1. Access Display Settings menu (see”Multi-monitor configuration”»on»page»5). 2. Select the preferred monitor at top of the page. 3. Check the box to Make this my main display. Note For some computers, you may need to disable the main display by unchecking the box of Extend the desktop onto this monitor or Extend my Windows desktop onto this monitor.
-
Page 14: Macos
macOS 1. Click on the Apple icon in the top left corner of the screen and select System Preferences…/ Displays. 2. To rearrange the displays, drag them to the desired position. To»relocate»the»menu»bar,»drag»it»to»a»different»display. To switch to Mirror Mode, check the Mirror Displays box. -
Page 15: Audio Configuration
Audio configuration By default, when the docking station is connected to a computer, the»audio»configuration»may»be»changed»to»USB»(Multimedia)» Audio Device automatically (this setting depends on models). If it does not work, follow the steps below to setup. 1. Open Control Panel and then select the hardware and sound icon.
