Instruction Manual
Minimum System Requirements:
Hardware:
PC with Intel Pentium 4
128 MB RAM
50 MB Hard Drive Space
CD-ROM Drive
Software:
Microsoft Windows XP with internet connection
Digital Photo Frame – PC Link (Auto-run)
IMPORTANT INFORMATION
DO NOT CONNECT YOUR DIGIT PHOTO FRAME TO YOUR
COMPUTER
INSTRCUTION MANUAL. FAIL TO DO SO MAY RESULT IN
PRODUCT DAMAGE.
IMAGES FILES IN THIS DEVICE CANNOT BE BROWSED OR
VIEWED BY PROGRAMS OTHER THAN THE ONE PROVIDED.
Digital Photo Frame
UNLESS
YOU
for
HAVE
READ
1
THOROUGH
THIS
Advertisement
Table of Contents
Summary of Contents for Unicorn DPF4000
- Page 1 Instruction Manual Digital Photo Frame Minimum System Requirements: Hardware: PC with Intel Pentium 4 128 MB RAM 50 MB Hard Drive Space CD-ROM Drive Software: Microsoft Windows XP with internet connection Digital Photo Frame – PC Link (Auto-run) IMPORTANT INFORMATION DO NOT CONNECT YOUR DIGIT PHOTO FRAME TO YOUR COMPUTER UNLESS...
- Page 2 Main Features: Digital Photo Frame Clock with calendar Daily Alarm Auto power off 1.5V AA battery x 4 Keypad Layout Key Name Press Once Press and hold for 2 second Go to previous picture Go to Set Alarm mode Go to next picture Auto slide mode, ON/OFF DOWN MODE...
- Page 3 Download Photo Once the USB cable is plugged, it will enter USB mode and show “Connecting….” on the screen. Note: Some PC’s do not have sufficient power output from their USB port, therefore batteries must be installed in the photo frame when download photo. PC Auto-run program will start automatically as below: Click “Add Image”...
- Page 4 To select a portion of the photo to display, move the cursor to the edges of photo and it will change to a double end arrow. Click and drag to change the selection size. Move to cursor inside the selection, click and drag it to desired location. Same photo can be display on the screen but need to add 4 times manually.
- Page 5 Click “Split Mode” for large photo display. Select the desired area by dragging the selection frame. Click on the centre of the selection frame to move it.
- Page 6 Click “OK” when finished. Click “Save” to download all selected photo to the photo frame. WARNING！ Never disconnect the USB cable when downloading photo to the photo frame. Wait until the process is finish. Otherwise the photo frame may be damaged. Auto power off time and photo slide speed can be set by clicking “Setting”.
- Page 7 BATTERY REPLACEMENT This device operates on four AA batteries. Be sure to read the following precautions before replacing batteries. 1) Turn off the unit before replacing batteries. 2) Remove the battery cover. Remove the old batteries and insert new batteries into the empty compartment with correct polarity.
- Page 8 RESET THE UNIT Reset the unit if it fails to respond. Insert the pointed end of a paper clip into the small round hole located directly below the word RESET on the rear cabinet. Push gently. In Case of difficulty - Check the battery to ensure that it is fresh and properly installed.
