- Page 1 INSTRUCTION MANUAL MULTICOOKING MACHINE SUPERCHEF MODEL: CLCM-1500 Read carefully these instructions before using the appliance and save them for future reference...
- Page 4 Safety measures for the correct use of this product 1. Read this instruction manual carefully before using this product and save it for future reference. 2. The safety of the use of this product is guaranteed when it is connected to a socket that has a power point with an earth wire connection that meets the required standards.
- Page 5 14. The manufacturer abstains from any responsibility for damages caused due to inadequate, incorrect or imprudent use of the machine by the user. 15. Avoid use of this machine near to inflammable materials (curtains, etc.) or heat emiting apparatus (gas heaters, vitro ceramic etc.) 16.
- Page 6 Description parts and accessories The kitchen machine is made up of the following parts and accessories: 1 - Central unit 2 - Control panel 3 - Stainless steel bowl of 2 litres 4- On/Off Switch (1-0)
- Page 7 4 – Measuring cover 5 – Bowl cover 6 – 4 Stainless steel blades 7 – Stainless steel bowl of 2 litres 8 – Illuminated pilot light 9 – LCD screen 10 – Timer 11 – Temperature 12 – On/Off Switch 13 –...
- Page 8 ACCESORIES INCLUDED WITH KITCHEN MACHINE Cooking basket Steam tray Mixing tool Heat resistant Spatula...
-
Page 9: Control Panel
CONTROL PANEL ILLUMINATED PILOT LIGHT When turning the kitchen machine with the On/Off Switch (0-1) located on the rear of the machine, a red pilot light situated in the upper part of the screen will come on and will remain this way until the machine is disconnected from the electrical supply. -
Page 10: Lcd Screen
SPEED For a more versatile kitchen machine, comes with 10 speeds for boiling, mixing, blending, kneading and chopping that are controlled by the Speed button. Prees SPEED button and then the control buttons + o - to select the required speed. Speed for creamy mixtures and dough. - Page 11 TIME The selected time appears in the upper part of the screen with the symbol of the clock and the word Time. Here the time is shown in minutes and seconds and can be programmed up to a maximum of 90 minutes. (See Figure 1) SPEED The selected speed is shown on the screen by the...
- Page 12 BOWL COVER IS OPEN Kitchen machine comes with two security sensors in the cover and base of the bowl. When the cover is open or incorrectly closed, this warning symbol will appear on the screen. PROGRAMMED TEMPERATURE REACHED This symbol flashes on the screen for a few seconds to indicate that kitchen machine has reached the selected temperature.
- Page 13 Before using the kitchen machine for the first time, make sure that it has all the listed parts and accessory. 1. Placing the bowl Ensure that the blades are well placed in the bowl. Connect the bowl to the central unit by placing it in the cavity of the central unit and lightly pressing it down so that it fits correctly in place.
-
Page 14: Components And Accessories
COMPONENTS AND ACCESSORIES Bowl The kitchen machine is made of stainless steel and has a maximum capacity of 2litres with marked levels of 0.5 litres indicated on the outside and inside of the bowl. Caution: 1. Never fill the bowl exceeding the maximum level amount for safer use of the kitchen machine and for better performance. -
Page 15: Steam Tray
STEAM TRAY The Steam Tray accessory is perfect for steaming meat, fish and vegetables. This accessory consists of three parts the first of them being an outer tray for collecting liquids that may fall from the ingredients during the cooking process. A second and smaller size tray is used for placing the ingredients inside for steaming. - Page 16 GETTING STARTED WITH THE KITCHEN MACHINE Important - Place the kitchen machine on a clean and stable surface that does not radiate heat - The kitchen machine comes with two security sensors that can be found in the handle and bottom of the bowl, for an optimum use of the machine, the bowl has to be properly fitted to the central unit, Otherwise the machine will detect an error and will not work - Make sure the bowl, blades and all the accessories are well cleaned before using the machine...
-
Page 17: Technical Specifications
6. Thoroughly dry all the components and bowl accessories after each wash for optimum performance of the machine. 7. Clean the cavity of the central unit with a damp towel and dry it well. TECHNICAL SPECIFICATIONS Model: CLCM-1500 Voltage: 220V-230V / 50Hz Electric cable: 1.8 m Motor: 500W for mixing, 1000W for cooking Speeds: 10+Turbo Maximum temperature: 110°C...
