BonnetPro MiniMax Terminator Owner's Manual

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

Download this manual

MULE 220R

Owner's/Operator's Manual

Table of Contents

Need help?

Do you have a question about the MiniMax Terminator and is the answer not in the manual?

Questions and answers

Summary of Contents for BonnetPro MiniMax Terminator

Page 1 MULE 220R Owner’s/Operator’s Manual...
Page 2 WARNING tO AVOID FIRE, DO nOt usE WItH A FLAMMABLE OR COMBustIBLE LIQuID tO CLEAn FLOOR. tHIs MACHInE CAn CREAtE sPARks. DO nOt usE AROunD COMBustIBLE MAtERIALs. Bonnet Pro 4529 Bethlehem Pike Telford, PA 18969 Phone: (215) 723-5330 www.bonnetpro.com...
Page 3 Oil must be changed after the first 50 hours and every 500 hours thereafter. 14 ounces Mobil SHC 634 Gear oil must be used. Failure to do so will void your warranty. See instruction in owner’s manual or video at www. bonnetpro.com on the MiniMax page.
Page 4 PLEASE NOTE: Before using your MiniMax. When you receive you MiniMax you will need to change the solid plug with the breather plug that is supplied in the little bag attached to the chassis, pic #1. Making sure the machine is on a flat and level surface so no gearbox oil drains out remove the solid plug using a ¼...
Page 5: Oil Change Instructions
Oil Change Instructions Your new MiniMax Terminator uses a gearbox that contains oil rather than grease. This allows you to easily change the lubricant in your machine. Grease will weaken and become soiled over time. With oil like in your car, you can easily add new clean lubricant for a long product life.
Page 6 Thank you again for your purchase. Please feel free to call 877-477-1615 if you have questions. You can also watch the MiniMax video at www.bonnetpro.com and if you want more low moisture cleaning info please watch the “How to Encap” video at our site...
Page 7: Operation
This manual is only available online at bonnetpro.com. It provides necessary operation and maintenance instructions and an illustrated parts list. Read this manual completely and understand the machine before operating or servicing it. this manual cannot cover all safety issues and variables.
Page 8: Important Safeguards
thank you for your purchase. WarninG: Maintenance and repairs must be done by authorized personnel only. WarninG: Keep all fasteners tight. Keep adjustments according to Your new MiniMax Carpet Machine will afford you many specifications. years of trouble-free operating satisfaction provided it is given proper care.
Page 9: Safety Precautions
operation SafetY PreCautionS • Unless trained and authorized. • Unless operator manual is read and understood. this machine is intended for commercial use only. it • Unless cord is properly grounded. is designed exclusively to clean carpets in an indoor •...
Page 10: Safety Lock
WarninG To prevent injury, always remove the electrical plug from the electrical outlet before changing the Revive encapsulation pads or bonnets and before leaving the machine. PrePare tHe MaCHine for oPeration To attach the drive block or brush or other attachment, be sure the handle is “locked”...
Page 11: Machine Operation
See more about bonnets in our 'Bonnet 101' video found at 4. Before starting the machine, hold the handle so the machine base bonnetpro.com in the CT6 Education Center. is parallel to floor. This will reduce the abrupt jolt when starting the machine.
Page 12: Transporting Machine
15 seconds and press the reset button located on the 7. Change oil after first 50 hours and every 500 hours thereafter. handle. See video at bonnetpro.com concerning oil changes and machine maintenance. 8. Do not operate the machine in the same spot for a long period of time.
Page 13 operating the MiniMax Pump Your pump is the demand type. Meaning if you have no demand or When starting, using the front sprayer your initial setting might be water flow it will not run/ make noise. If your solution control valve between the blue and silver colored rings on the solution control valve is closed or the front sprayer valve is shut and the shower feed valve (pic#1) For a setting using the shower feed you might start between...
Page 14 Do not over tighten handle clamp This will cause the clamp to fail and is not covered under warranty. To Bonnet Pro suggests using your hand and not your foot to engage and disengage the handle clamp. Your hands extra adjust your handle clamp, tighten it as much that is needed to prevent sensitivity should allow you to prevent over tightening and the handle from slipping during transportation but no more.
Page 15: Troubleshooting
troubleshooting ProBLeM CauSe SoLution Machine does not operate. Faulty power cord. Contact Service Center. Tripped circuit breaker. Reset circuit breaker on machine. Tripped building circuit breaker. Reset circuit breaker in building. Faulty machine wiring. Contact Service Center. Faulty On/Off handle switch. Contact Service Center.
Page 16 Steps and Coil Hose WARnInG: When going up stairs: It is always the operator’s responsibility to assess the safety of moving their MiniMax up stairs to make sure conditions are safe. Always remove the chemical jug if full and the detachable power cord to lighten the machines weight.
Page 17 WARNING tO AVOID FIRE, DO nOt usE WItH A FLAMMABLE OR COMBustIBLE LIQuID tO CLEAn FLOOR. tHIs MACHInE CAn CREAtE sPARks. DO nOt usE AROunD COMBustIBLE MAtERIALs. Bonnet Pro 4529 Bethlehem Pike Telford, PA 18969 Phone: (215) 723-5330 www.bonnetpro.com...
Page 18: Warranty Limitations And Exclusions
MiniMax Warranty Bonnet Pro warrants this product against defects in manufacturing, materials, or workman- ship for a period of twelve (12) months from the date of consumer purchase and two years on the chassis. This warranty does not cover the finish on the MiniMax. Defective parts will be repaired or replaced with new or reconditioned parts at the company’s option.

This manual is also suitable for:

Minimax mule 220r
