RTcomUSA Digital Extender DC-AD2 User Manual

Dvi converter
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
User's Manual
DVI Converter
DC-AD2
Cautions:
1. Digitalextender® logo is our own trademark of RTcomUSA.,Inc.
2. Any of the products may be changed without any notice in order to improve the function of the product.
3. The design and specification of the product may be changed without any prior notice.
Copyright 2007 RTcomUSA., Inc.
Total Digital Connectivity Solutions
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Digital Extender DC-AD2 and is the answer not in the manual?

Questions and answers

Summary of Contents for RTcomUSA Digital Extender DC-AD2

  • Page 1 DC-AD2 Cautions: 1. Digitalextender® logo is our own trademark of RTcomUSA.,Inc. 2. Any of the products may be changed without any notice in order to improve the function of the product. 3. The design and specification of the product may be changed without any prior notice.

  • Page 2: Table Of Contents

    2 INSTALLATION ..............................8 2-1 I ..............................8 NSTALLATION 2-2 A ........................8 CCESSING THE MENU SYSTEM 3 INPUT STANDARD TIMING CHART ......................10 4 CONNECTOR PIN ASSIGNMENT......................... 12 5 TROUBLESHOOTING............................. 13 6 WARRANTY INFORMATION ........................14 Copyright 2007 RTcomUSA., Inc.

  • Page 3: Basic Understandings Of The Product

    RTcomUSA, Inc. Tel: 973-383-4878 Fax:973-383-1160 info@digitalextender.com 1-2 Package Includes Each package includes the following items DC-AD2 Unit : 1 5V 2A ,AC/DC Power Adapter : 1 User’s manual :1 Copyright 2007 RTcomUSA., Inc.

  • Page 4: Declaration Of Conformity

    Certification for Safety The extension system is certified pursuant to IEC60065 and its AC/DC power adapter is certified by UL1310, 1950, 60950 for North America, cUL or CSA for Canada, Copyright 2007 RTcomUSA., Inc.

  • Page 5: Description, General Specification

    DC Power Jack DVI-D Single link Receptacle D_SUB,DVI Image Scaler PW181 Pixelworks Power Consumption 5W Max DC +5V Board Diemension 140 x 110 mm User Controls 6 Buttons Control Power & OSD Plug & Play DDC2B VESA Copyright 2007 RTcomUSA., Inc.

  • Page 6: Environmental And Reliability Specifications

    Moves the highlight icon Down to the function that user wants Moves the highlight icon Up to the function that user wants + ( Right ) -.Increases the adjustment of the selected function - ( Left ) -.Decreases the adjustment of the selected function Copyright 2007 RTcomUSA., Inc.

  • Page 7: Electrical Specification

    Video signal LED Indication Consumption < 5 W Active Active Active LED On Stand-by Inactive Active Blanked Green Blink 1sec Suspend Active Inactive Blanked Green Blink 1sec < 3 W Inactive Inactive Blanked Green Blink 1sec Copyright 2007 RTcomUSA., Inc.

  • Page 8: Installation

    12. Press both Down and Up button to execute Color calibration for 5 sec with 16 gray pattern. 13. It’s available on resolution 1280*1024@60 under. 14. We strongly recommend that color calibration be executed at resolution 1280*1024@60. Copyright 2007 RTcomUSA., Inc.
  • Page 9 Reset the unit to factory outgoing status Return SUB MENU Exit Exit OSD MENU Exit Menus Sub-menus Function Descriptions Displays current display mode. Displays the driver board operating duration Information No Item Menus Sub-menus Function Descriptions Exit No Item OSD MENU Exit Copyright 2007 RTcomUSA., Inc.

  • Page 10: Input Standard Timing Chart

    - Active time(ms) 15.880 12.795 16.006 12.804 16.018 31.999 - Front porch(ms) 0.062 0.017 0.016 0.013 0.010 0.026 - Sync width(ms) 0.124 0.050 0.047 0.038 0.040 0.079 - Back porch(ms) 0.600 0.466 0.594 0.475 0.500 1.226 Copyright 2007 RTcomUSA., Inc.
  • Page 11 - Sync width(us) 1.23 1.185 - Back porch(us) 1.94 1.876 - V-Frequency(Hz) 60.300 60.000 - Period(ms) 16.584 33.333 - Active time(ms) 16.018 31.999 - Front porch(ms) 0.01 0.026 - Sync width(ms) 0.04 0.079 - Back porch(ms) 0.05 1.226 Copyright 2007 RTcomUSA., Inc.

  • Page 12: Connector Pin Assignment

    TMDS DATA 3M(N.C) DVI-D 29pin TMDS DATA 3P(N.C) Hot Plug Detect TMDS DATA 0M TMDS DATA 0P TMDS DATA 0/5 Shield TMDS DATA 5M(N.C) TMDS DATA 5P(N.C) TMDS DATA Clock Shield TMDS Clock P TMDS Clock M Copyright 2007 RTcomUSA., Inc.

  • Page 13: Troubleshooting

    5. Makes sure all DVI connectors are tightly secured to DVI ports. Loose the DVI connectors will results in no or poor picture. 6. Turn off all equipments (video sources, Converter and Monitor), restart all equipments. Copyright 2007 RTcomUSA., Inc.

  • Page 14: Warranty Information

    Warranty Limitation and Exclusion RTcomUSA shall have no further obligation under the foregoing limited warranty if the product has been damaged due to abuse, misuse, neglect, accident, unusual physical or electrical stress, unauthorized modifications, tampering, alterations, or service other than by RTcomUSA or its authorized agents, causes other than from ordinary use or failure to properly use the product in the application for which said product is intended.
  • Page 15 © 2007 RTcomUSA All Rights Reserved Revision 1 RTcomUSA, Inc Locations RTcomUSA. Inc 286 Houses Corner Road Sparta, NJ 07871 USA Tel: 1-973-383-4878 Fax: 1-973-383-1160 www.digitalextender.com For order support, please contact your Distributor or Reseller. For technical support, check with the Email: rtcomusa@earthlink.net...
