ASSEMBLY AND INSTALLATION
INSTRUCTIONS
GT-SL1
TO AVOID RISK OF ELECTRICAL SHOCK, BE SURE TO
WARNING:
SHUT OFF POWER BEFORE INSTALLING OR SERVICING
THIS FIXTURE
180° MOTION ACTIVATED LED FLOODLIGHT
Questions, problems, missing parts? Please contact
1-800-865-6799
THANK YOU!
WARNING ：
TO AVOID RISK OF ELECTRICAL SHOCK, BE SURE TO SHUT OFF POWER
WHILE INSTALLING OR SERVICING THIS FIXTURE.
GT-SL1
Advertisement
Table of Contents
Related Manuals for GT-Lite GT-SL1
Summary of Contents for GT-Lite GT-SL1
- Page 1 ASSEMBLY AND INSTALLATION INSTRUCTIONS GT-SL1 TO AVOID RISK OF ELECTRICAL SHOCK, BE SURE TO WARNING: SHUT OFF POWER BEFORE INSTALLING OR SERVICING THIS FIXTURE 180° MOTION ACTIVATED LED FLOODLIGHT Questions, problems, missing parts? Please contact 1-800-865-6799 THANK YOU! WARNING ：...
-
Page 2: Important Safety Information
Select the installation location carefully. Do not install in areas having pedestrian or motorized traffic, pools or bodies of water, or trees/bushes that move in the wind. All of these may trigger the motion sensor security light and may be GT-SL1... -
Page 3: Tools Required
TOOLS REQUIRED: Philips Screwdriver HARDWARE INCLUDED Part Description Quantity Gasket(not to Scale) #6-32×3/4 in. junction box screw #8-32×3/4 in. junction box screw Mounting Strap Wire Nut Fixture Mounting Screw O Ring GT-SL1... -
Page 4: Installation
CAUTION: For best performance, mount the fixture about 8ft (2.4m) above the ground. BB / CC Notice: Do not connect this light fixture to a dimmer switch or timer BB / CC Eave Mount Junction Wall Mount GT-SL1... -
Page 5: Mounting The Fixture
Connect the fixture black wire to the house black loose wires remain sticking out from underneath the cover plate. wire and fixture white wire to the house white wire using wire nuts (EE) provided. □ Carefully tuck the wires back into the electrical box. GT-SL1... - Page 6 Lux, slide the knob counterclockwise. When the motion stops, the light will remain on for the predetermined time set (1min- 10min), then the light will turn off automatically. GT-SL1...
-
Page 7: Troubleshooting
□ The sensitivity may be set too high □ Reduce the sensitivity apparent reason □ The light fixture is wired through a dimmer or □ Do not use a dimmer or timer to control timer the light fixture GT-SL1... -
Page 8: Year Limited Warranty
This warranty excludes coverage of finish or color against tarnishing, flaking, and discoloration. If the original purchaser ceases to own the GT-Lite Lighting product this warranty and any implied warranty will be void.
