- Page 1 Installation, Programming and Operator Guide Part Number TBD IntelFlex™Controller Kitchen System...
- Page 2 Congratulations on your purchase of a JTECH Kitchen Messaging System Managers Pagers Desktop Controllers containing the IntelFlex Kitchen Controller. Please take a few minutes to review this manual prior to installing and operating your system. Please inspect the System upon receipt. If the contents appear to be damaged, notify the shipper immediately to file a claim and notify JTECH Customer Care.
- Page 3 General Specifications DC Operating Voltage: 13.5VDC 2.4A Power Adapter 110-240VAC 50-60Hz power adapter Transmitter Power Output:: 0.1-2 Watts - adjustable using 5 levels. Keypad Display: 20 Button LED Modulation: FSK 512 BPS Protocol: POCSAG Transmit: 512. 1200, 2400 Baud Kitchen System with Clamp Bracket Dimensions 7-9/16”...
- Page 4 Antenna Port: 50 ohm BNC Antenna (Standard) 6” (153mm) Rotating Whip Stainless Steel” Operating Frequency: UHF synthesized 450-470 MHz. (standard) Temperature Stability: -22°to 122°F (-30 to 50°C) at better than 5 ppm Weight : 2.5-3.0 Lbs (1.14-1.36Kg) -Depending on Mounting Brackets used.
- Page 5 Kitchen System with Wall Bracket Dimensions 6-7/8” (174.6mm) 7-9/16” (192.1mm) 6-7/8” (174.6mm) Left Side Front View (With Clamp Right Side View Mount Bracket) View Rear View Expansion/Remote EXPANSION REMOTE Connector Area (Bracket Attached) Expansion Connector Remote Connector...
- Page 6 IntelFlex Kitchen System Highlights • Designed for used in restaurant kitchens and similar applications. • Available in 20, 40 and 60 button systems with 20 buttons per Panel. • Connect additional panels for Expeditor or Server Cancel functions. • Page up to 60 Wait Staff Pagers and one or more Manager Pagers at any time (depending on programming).
- Page 7 Expeditor or Server Cancel Panels (Optional) Panels: Additional Panels can be connected to the Controller. The Panels can then be programmed for cancel or expedite modes. When a Panel is programmed for Cancel Mode” , it will: “ • Require Wait Staff to cancel their page at the Cancel Panel. •...
- Page 8 . • USB Keyboard: Attach a Keyboard to the Controller to send a alphanumeric page to Managers Pagers. • USB Flash Drive: Use a JTECH USB Flash Drive to upgrade software and to backup user settings.
- Page 9 Antenna Choices to Extend Range All Extended Range Antenna choices require FCC approval and licensing. JTECH can assist in acquiring any additional licensing. • Magnetic Mount Antenna with 12ft (3.6m) Cable: All metal indoor/outdoor Antenna with a magnetized base for mounting to steel or iron.
- Page 10 Numeric and Alphanumeric (Managers) Pagers can be added at any time. • Pages can also be sent from a IntelFlex Desktop Controller (optional) to Wait Staff and Managers Pagers. Send Numeric information to Numeric and Alphanumeric (Managers) Pagers as well.
- Page 11 Installing the Kitchen Controller and Cancel/Expeditor Panel • Mount on a wall, clamp to a shelf or let it sit on any flat surface. • Mount as high as possible from the floor with the antenna tip at least 18” away from any metal.
- Page 12 Assembly for Clamp Brackets Shelf, Table or Counter Top Mounting Assembly for Stand Bracket Shelf, Table or Counter Top Assembly for Wall Bracket Walls or Vertical Surface Wall mounting screws are not supplied. Select wall mounting hardware as needed.
- Page 13 Powering the Kitchen Controller 1. Connect the Power Adapter to the Kitchen Controller and plug it into a 120VAC outlet. 2. The Controller LED’s will light in a sequence, TRANSMIT light will light and the POWER light will flash. 3. After several seconds, the TRANSMIT light turns off and the Kitchen Controller is ready for use.
- Page 14 Connecting the Cancel or Expeditor Panel with Managers Button 1. The Cancel/Expeditor Panel must be connected to the Kitchen Controller Panel before connecting power. 2. Connect the Cancel/Expeditor Panel to the Kitchen Controller Panel using the 25’ (7.6m) the RJ12 Phone Cord supplied. 3.
- Page 15 Connecting a 40 Button System with Cancel/Expeditor Panels Kitchen Controller Managers Buttons 1-20 Button 1 Expansion Panel Buttons 21-40 Cancel/Expeditor Cancel/Expeditor Panel Managers Panel Buttons 1-20 Button 2 Buttons 21-40 All Expansion Panels connect together using the supplied 1’ (0.3m)Cables.
- Page 16 Connecting a 60 Button System with Cancel/Expeditor Panels Kitchen Controller Managers Expansion Panel Buttons 1-20 Button 1 Buttons 41-60 Expansion Panel Buttons 21-40 Cancel/Expeditor Panel Cancel/Expeditor Cancel/Expeditor Buttons 1-20 Panel Panel Buttons 21-40 Buttons 41-60 Managers Button 2 All Expansion Panels connect together using the supplied 1’...
- Page 17 Range Testing When the Controller is put into Range Test Mode, it will continue to send a page every 3-4 seconds for 4 minutes. This will allow a person to walk the area where your Pagers will be used and check for dead spots or weak signal areas.
- Page 18 Paging using a Controller or Expeditor Panel 1. Press the number on the Controller or Expeditor Panel of the Pager you want to page. 2. The light on the Panel, next to that number will turn ON. 3. The TRANSMIT light will turn ON for 2-3 seconds and turn off. 4.
- Page 19 Using the Cancel Panel • The Cancel Panel is used to cancel (end) pages sent from the Controller. • After the Controller sends a page, the Wait Staff must cancel (end) the page by pressing the Pager number button on the Cancel Panel. •...
- Page 20 Paging from a IntelFlex Desktop Controller If you also have a IntelFlex Desktop Controller set to the same Frequency and Cap Code Prefix (see IntelFlex Desktop Controller manual), you can page your Wait Staff, Manager or group of Mangers from it.
- Page 21 Standard Program Settings Factory Settings: Unless ordered otherwise, the factory defaults are: • Pick Up Period: = 40 seconds • All Call: = Selected • Remote Panel Setting = Expedite mode • Number Of Vibrations = Single Vibration • Transmit Power = 2 Watt (Maximum) Pick Up Time Factory setting is 40 seconds.
- Page 22 Cancel/Expedite Mode The Panel can be programmed as a Cancel or Expeditor Panel and cannot be both at the same time. A Cancel Panel is used by the Wait Staff to cancel their pages after picking up an order. A Expeditor Panel is used by an Assistant or Chef to page the Wait Staff.
- Page 23 Return Material Authorization (RMA) number. If advance replacement of equipment service is used and the defective equipment is not received back at JTECH within 10 days, JTECH will bill the amount of the list price of the equipment to the Customer.
- Page 24 2. Payment Terms. Normal payment terms are C.O.D. unless otherwise set forth in this proposal. Any outstanding balances not paid by the date on which they are due to JTECH Communications Inc. Inc. shall be subject to interest of 1 1/2% per month on the...
- Page 25 Agreement is terminated by Buyer for any reason other than default by JTECH, Buyer shall be liable immediately thereupon, to pay to JTECH the full contract price for all goods completed by JTECH pursuant to the Agreement and for all work in process at the time of termination.
- Page 26 FCC RF Exposure Statement Under Industry Canada regulations, this radio transmitter may only operate using an antenna of a type and maximum (or lesser) gain approved for the transmitter by Industry Canada. To reduce potential radio interference to other users, the antenna type and its gain should be so chosen that the equivalent isotropically radiated power (e.i.r.p.) is not more than that necessary for successful communication.
-
Page 27: System Warranty
SYSTEM WARRANTY JTECH Communications, Inc. warrants its equipment to be free from defects in materials and workmanship for a period of one year. Its obligation under this warranty is limited to repairing or replacing, at its own sole option, any such defective products.
