Summary of Contents for SLaudiolab SRS-200BS
- Page 1 SRS-200BS User’s Manual (Bluetooth Stereo Headset)
-
Page 2: Safety Notices
Safety Notices Prior to use, please read “Bluetooth Stereo Headset user’s manual”, carefully for its instructions and notices and use it appropriately. Please follow the instructions in order to prevent user’s risks and property damages. Warnings Please do not damage the headset with a sharp object. (such as nail, knife and scissors) Please do not wet or soak headset in water. - Page 3 Please do not rebuild, disassemble or repair the headset arbitrarely. If rebuilt, disassembled or repaired arbitrarely it will be not able to receive any free repair service. If you are listening to music at a high volume for a long period of time, it may damage your hearing.
-
Page 4: Table Of Contents
Table of Contents Safety Notices ..........2 Warnings ............2 Cautions ............2 Introduction..........5 Package ............5 Features............6 Before Starting to Use......... 7 Preparations ............. 7 Charging ............7 Usage............8 Turning On/Off the Headset......8 Connecting the Headset to a Bluetooth Device8 Calling .............. -
Page 5: Introduction
SRS sound effect Package After purchasing, detach the BD_Address/serial number label from the product, keep it attached to the blank of the warranty (required for the after-sales service.). SRS-200BS Body DC chager Earphone Sponges Part of the components shall be changed without notice for quality improvement. -
Page 6: Features
Features Microphone Input Operation Status Music Play / Pause / Stop Call / Terminate / SRS Button Button Move to the Volume Up (+) Next Button Button Move to the Volume Down (–) Previous Button Button Power Switch DC Charge Terminal... -
Page 7: Before Starting To Use
Before Starting to Use Preparations Please read the instructions carefully before its useage. Charging The product includes a built-in battery. Please charge it with the DC charger provided in the box. After purchasing this product, please charge the battery fully before using it for the first time. -
Page 8: Usage
Bluetooth device user’s manual. 3. Select “SRS-200BS” from the searched list. 4. Enter “0000” when Bluetooth asks for password or pin-number. 5. Select “SRS-200BS” from the list of registered devices. * Once registered, there is no need for re-registering for future connection. -
Page 9: Calling
Calling Calling to the Latest Number Press the call button to check the last call history saved in the phone. Press the call button again to call the last number. (Depends on the type of the mobile phone, you may call without saving the call history.) Calling with a Voice Please press the call button... -
Page 10: Receiving A Call
Receiving a Call Please press the call button when the phone rings. Hanging up the Call Please press the call button to hang up the phone. Refusing a Call Please press the call button for more than 2 seconds. Volume Control Adjust the headset speaker volume by pressing the volume button while talking. - Page 11 Multi-Party Call Function (3-Way Call) This product is constructed with a multi-party call ability. (To have a multi-party call, user’s device should support the Bluetooth function.) Calling Waiting You can put the current call in a wait state by pushing the button shortly while talking on the phone, and can terminate the call in a wait state by pushing the button...
-
Page 12: Listening To The Music
Listening to the Music Press the button to listen to the music saved in the phone through the headset. Headset Button Press for 2 seconds Play Press for 2 seconds Stop Playing Music Press shortly while playing music Pause Adjusting volume Press Play the Press... - Page 13 Receiving a call while playing music The bell rings automatically stopping the music. (Operation status LED flickers Red in 5 second interval.) When the music stops and the bell rings, press the call button briefly. Please press the call button to hang up the phone.
-
Page 14: Using Srs 3D Sound Effect
Using SRS 3D Sound Effect Headset facilitates the SRS 3D sound effect function. Use the SRS 3D sound effect to enjoy a high quality 3D sound. Press the call button for 4 seconds while listening to music for high quality SRS sound effect. The Blue operation status LED flickers twice in 5 second interval. -
Page 15: Specifications
Maximum 3.5 hours Music Play Time Maximum 3.5 hours Battery Charging Time 2 hours Adaptor Spec Rated Input: AC 100~240V, 50/60Hz Rated Output: DC 5V, 700mA Dimension SRS-200BS Body (61.0 x 29.5 x 7.6 mm) Weight 27g ( including earphone) -
Page 16: Troubleshooting
Troubleshooting Problem Action If the operation status LED is not responding even ▶ The operation status after turning on the power switch, it is because the LED is not turned on. battery is discharged. Use after charging it sufficiently. ▶ Registration should be made from the user’s Device registration Bluetooth device after setting the headset to the can not be done. -
Page 17: Led Status Indication
LED Status Indication Headset Status LED Indication Status Sound Getting higher Power On Blue LED blinks 4 times 2 syllables On Charging Red LED turns on Charging completion Blue LED turns on Connection Standby Red and Blue LEDs blink Getting higher Mode (Pairing Mode) (max. -
Page 18: Quality Warranty
Quality Warranty 제품 보증서 Thank you for purchasing SLaudiolab products. Since the quality assurance period of this product starts from the date of purchase, please have the purchase date written on this sheet to have appropriate services. SLaudiolab assures this product as shown below according to the following compensation rules and regulations. - Page 19 10% to the amount. If the replacement is not possible. Refund Product Bluetooth Stereo Headset Model SRS-200BS Serial No Date of Purchase Name Customer Name Agent SLaudiolab Co., Ltd. 6F Won-il Bldg, #57-30 Nonhyun-Dong, Gangnam-Gu, Seoul...
- Page 20 For CE Marking Declaration of conformity We, SLaudiolab Of 6F Won-il Bldg, #57-30 Nonhyun-Dong Gangnam-Gu, Seoul, Korea Declare under our sole responsibility that our product SLaudiolab type SRS-200BS To which this declaration relates is in conformity with the Appropriate standards EN 300 328, EN 301 489-1,...
- Page 21 (2) This device must accept any interference received, including interference that may cause undesired operation. Caution: Changes or modifications not expressly approved by SLaudiolab could avoid the user’s authority to operate the equipment. NOTE: FCC Radiation Exposure Statement: This Equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment.
- Page 22 SLaudiolab Co., Ltd. 6F Won-il Bldg, #57-30 Nonhyun-Dong, Gangnam-Gu, Seoul, Korea Printed in Korea...
