Summary of Contents for Sundrax CGP-3-2DE2B
- Page 1 Version 1.02 June 13, 2017 User Manual CrossGate PRO CGP-X-2DE2B, CGP-X-4DE4B...
-
Page 2: Table Of Contents
Table of contents Appearance Specifications Safe operation General information Merging Connection types Installation Web-settings •Main settings •Advanced settings •Network settings •Profiles settings •Firmware update BeDMX configuring Technical maintenance... -
Page 3: Appearance
Appearance Pic.1 Main interfaces and indicators Bluetooth antenna DMX LED indicators Ethernet LED indicators DMX output Ethernet port DMX input Rack mount case Specifications BeDMX ports 2 or 4 DMX ports 2 or 4 Connectors 4 or 8 XLR (5 pins, 3 pins) Ethernet port 10/100 Base-TX Ethernet connectors... -
Page 4: Safe Operation
Safe operation WARNING! The device uses hazardous voltage AC 230 V In installation, operation, preventive maintenance and repairs of the device, the requirements of the safety rules must be followed. To ensure safe and reliable operation of the devices, please ob- serve the following requirements: •... -
Page 5: Merging
Merging Variable merging options: (highest takes precedence), AUTO (latest takes precedence), (last modified takes precedence – intelligent merging mode that provides availability to manage instal- OVERLAY lation from two consoles simultaneously), (merges cus- tom slots from two ArtNet/sACN streams, fully customized through PRIORITY web interface), (for sACN streams with priority tag, con-... -
Page 6: Installation
Installation Before mounting and power up, it is necessary to verify protec- tive earthing and cable connections. 1. Ensure the device has no damage due to transportation. 2. Install device into 19’’ rack and fix it using 4 screws (not in- cluded in package). - Page 7 Pic.2 Main settings •Indication – buttons to switch the LED indication modes: Normal Indication depending on the current port status Blink Search mode. LEDs are off. •Device name – edit device name (up to 17 characters); •Device description – editable device description (up to 63 characters);...
-
Page 8: Advanced Settings
Subnet Art-Net subnet number (0-15) Universe Art-Net universe number (0-15) IN- input, OUT- output, LOOP- loop output with network I/O mode loopback, OFF- off Merge mode Merging mode (LTP, HTP, Auto, Priority, Overlay) sACN stream number (from 1 to 65279, the value ACN unv. - Page 9 Pic.3 Advanced settings For transmitter – current state of connections with receivers 1,2,3,...,7 (“+” - connection established, “-“ - connection not established/lost). “ ” 4 to 4 Set connection scheme 4 to 4 config (to connect 2 or more devices CrossGate PRO with each other) “...
-
Page 10: Network Settings
•Overlay/loopback settings – settings of overlay merging: Set Art-Net universe (from 0 to 15). Universe Start slot number and sampling step in the merged Src.start, Src.step stream Dst.start, Start slot number and sampling step in the output stream Dst.step The number of steps of copying Steps cnt. -
Page 11: Profiles Settings
•MAC address – MAC address and the secondary IP address of the device, which are set by the manufacturer and are not editable. The secondary IP address can be used to get access to device’s web-interface even in situation when the main IP address is lost/forgotten by the user;... -
Page 12: Firmware Update
Firmware update To upgrade the Firmware of the device, press link “Firmware”. Pic.6 Firmware update page •Reboot – reset the device, also confirm uploaded firmware; •Current firmware rev. – version of the current firmware; •New firmware file – browse for new firmware’s file; •Update firmware –... -
Page 13: Bedmx Configuring
BeDMX configuring Network configuring (receiver): 1. Using Web-interface set “IN” port mode. 2. Device is ready for further configuration of the network. Network configuring (transmitter): 1. Using Web-interface set “OUT” port mode. 2. Turn on all receivers that are needed to connect to device, placing them at a minimal distance from the device. -
Page 14: Technical Maintenance
Technical maintenance Maintenance the device, search and troubleshooting should be performed by service personnel. The device should be free from dirt, dents, connecting cables and wires must be intact and securely fastened. - Page 15 Please send all your warranty-related questions to support@sundrax.com All Sundrax products are covered by a 36 months warranty.
- Page 16 Sundrax Electronics, 6008, First Central 200 2 Lakeside Drive, Park Royal, London NW10 7FQ United Kingdom + 44 (0) 208 991 33 19 office@sundrax.com www.sundrax.com...
