Summary of Contents for MEGAPOWER MVP232
- Page 1 User’s Manual MODEL MVP232 HIGH RESOLUTION PORTABLE DIGITAL PRESENTER VISUAL PRESENTER...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Chapter 1 – Introduction ------------------------------------------------------ 1-5 About Your Digital Presenter ----------------------------------------------- 1.2 Safety Information ------------------------------------------------------------ 3-4 1.3 System Contents -------------------------------------------------------------- 4-5 Chapter 2 – Installation ------------------------------------------------------ 6-7 2.1 Setting Up ----------------------------------------------------------------------- 6 2.2 Connector Panel ---------------------------------------------------------------- 7 Connecting to TV or Monitor or Multimedia Projector ----------------- 7 Chapter 3 –... - Page 3 Note: 1. The appliance inlet of the power supply is the disconnector from mains and must be anytime easily accessible. 2. The maximum noise level of the product is LPA£70dB (A) DIN 45635-19-01-KL2. 1. Der Gerätestecker des Netzteiles bildet die Trennvorrichtung zum Versorgungsstromkreis und muß...
-
Page 4: Chapter 1 - Introduction
Chapter 1 Introduction 1.1 About Your Portable Digital Presenter The Portable Digital Presenter is a convenient, versatile, state-of-the-art presentation system. It is an effective and valuable tool for presenting printed material or 3-D objects on a TV or through a multimedia projector onto a large screen. The enlarged display allows large groups simultaneously view the object clearly and lively, and is particularly well suited for business meetings, conferences and group instruction. -
Page 5: System Contents
If liquid has been spilled into the Digital Presenter. If the Digital Presenter has been exposed to rain or water. If the Digital Presenter does not operate normally by following the operating instructions. Adjust only those controls, which are covered by the operating instructions. Improper adjustment of other controls may result in damage and will often require extensive work by the authorized technical staff to restore the Digital Presenter to normal operation. - Page 6 USB Cable VGA In Remote Adaptor Cable Control MVP232 User’s Manual User's Manual Carrying Bag...
-
Page 7: Chapter 2 - Installation
Chapter 2 Camera Head LED Lamp Goose Neck Control Panel Base 2.1 Setting Up Place the Portable Digital Presenter on a flat surface. Raise or Adjust the Goose Neck and turn the CCD camera so that the camera lens is pointing to the object to be displayed. Plug DC jack of the AC Power Adapter into the port labeled DC 12V on the rear panel of the Digital Presenter. -
Page 8: Connector Panel
2.2 Connector Panel This illustration shows the connector panel on your Digital Presenter. Refer to this figure when connecting the Digital Presenter. 2.3 Connecting to TV or Monitor or Multimedia Projector... -
Page 9: Chapter 3 - Using The Digital Presenter
Chapter 3 Using the Digital Presenter 3.1 Control Buttons The following describes the control button on the Remote Control and Control Panel of the Digital Presenter. Control Panel POWER Power ON or Off the Presenter TELE Zooms in and enlarges size of object WIDE Zooms out and reduces size of object ROTATE... - Page 10 Remote Control FREEZE Freezes the current image Toggles between RGB & internal AV output SIGNAL Compare current & stored image DIVISION NEGATIVE Press this function for negative film Stores images CAPTURE PLAYBACK Recalls stored images NEXT Shown next stored images TEXT Toggles between Text &...
-
Page 11: Chapter 4 - Care And Maintenance
Chapter 4 Care and Maintenance The information in this chapter describes how to care for and prevent accidental damage to your Digital Presenter You should treat your Visual Presenter with the same care you would give to any other valuable equipment 4.1 Cleaning the Digital Presenter Housing DO NOT try to service the Digital Presenter. -
Page 12: Chapter 5 - Troubleshooting Guide
Chapter 5 Troubleshooting Guide If you are having a problem operating the Visual Presenter, first make sure you have set it up according to the instructions in Chapter 3. You should also check the adjustments and the INPUT connections. Verify that all power is switched on. Before calling for service, check the troubleshooting suggestions in this chapter. -
Page 13: Appendix 1 - Product Specifications For Mvp-232
Appendix 1 Product Specifications for MVP-232 Projection Lens f=6.0 mm, F=1.6 Zoom 13X Digital Zoom Total Effective Pixels 1024 x 768 ; 1280 x1024 Resolution 800 TV Lines (VGA) Focusing Manual Imager 1/3” 2 million pixel sensor TV System PAL or NTSC Image Store 20 Images Signal to Noise Ratio...
