Summary of Contents for Nucraft Dialogue
- Page 1 Dialogue Install Guide Level 2: Audio Conferencing w w w . n u c r a f t . c o m • t o l l f r e e : 1 - 8 7 7 - n u c r a f t...
- Page 2 Dialogue Install Guide Dialogue is ready to connect remote audiences when you are, whether they’re Level 2 - Audio Conferencing across town or overseas. all the tools are at your fingertips; no need to drag a (Allows remote voices to be clear,...
- Page 3 Dialogue Install Guide Reference 0a Step 2 Installation at Table Locate Microphone Assembly Reference 0b Step 3 Installation at Wall Unscrew and Remove Microphone Windscreen Reference 0c Step 4 Cat 7 Flat Cables (color coded) Uncoil Microphone Cord Step 5...
- Page 4 Dialogue Install Guide Step 6 Step 9a Feed Cable Through Hole Reattach Windscreen to Microphone Step 7 Step 9b Position Microphone Over Hole (perpendicular to Microphone Install is Complete, Repeat Steps table’s edge) 1 - 9A on all Microphones Step 8a...
- Page 5 Dialogue Install Guide Step 10b Step 12 Underside of Power Cove without Speaker Locate Speaker and Grill, Attach to Underside of Power Cove Step 11a Step 13 Insert Mounting Screw Tighten Down Mounting Nuts to Speaker Step 11b Step 14...
- Page 6 Dialogue Install Guide Step 15b Step 17a Speaker Assembly Complete If Required, Drill Cable Pass Through (1.5” - 2”) at Bottom Left of Mount Step 16a Step 17b Using Provided Lag Screws, Attach Monitor Mount Finished Drill Hole to Wall in Predrilled Holes...
- Page 7 Dialogue Install Guide Step 19 Step 21b Feed Green Wall-End (Ref 0c.) Flatwire Snap Bottom Section of Wall Into Place Through Wall (Behind Steel Frame) Step 20a Step 22a Feed Yellow Wall-End Flat Wire (Ref 0c.) Hang Monitor on Wall Mount (not securing...
- Page 8 Dialogue Install Guide Step 24 Step 28a Hang Monitor Back Panel on Monitor Mount From Underside of Conference Table, Daisy- Chain Power Coves Step 25 Step 28b Attach Power (Black Cable in Background) and Daisy-Chained Power Coves, Full View Control (Gray Cable Hood) to Monitor...
- Page 9 Dialogue Install Guide Step 30b Step 32b Microphone Connections to Mic-Pod Complete Backside of Dialogue Gateway, Full View Step 31a Step 33 Connect Microphone Cords to Microphone Connections Attach Gateway to Underside of Table Step 31b Step 34a Microphone Cords Connected to Microphone Connections...
- Page 10 Wire Cabling through Cable Management Complete Harnesses (Where Necessary) Step 36a Step 38 View of Backplane of Dialogue Gateway Locate Mic-Pod Hook-up Kit (Contains 5 Cables) Step 36b Step 39a Connect Harness Pairs to Gateway Backplane Connect Orange Cable to Mic-Pod...
- Page 11 Dialogue Install Guide Step 39c Step 43 Reference: Mic-Pod Daisy-Chain as Needed Insert USB Phonebook (shipped w/ Gateway, but Not Installed) into Phonebook Jack Step 40 Step 44 Route all Pod Harnesses to Gateway Locate Remotes and Insert Batteries Step 41 Step 45a Connect Mic-Pod to Gateway Marked “Mic Box”...
- Page 12 Receiver Step 47 Power-Up Dialogue System Step 48 Dialogue Level 2 Installation is now Complete w w w . n u c r a f t . c o m • t o l l f r e e :...
- Page 13 Dialogue Install Guide DialogueHelp@nucraft.com For Help w w w . n u c r a f t . c o m • t o l l f r e e : 1 - 8 7 7 - n u c r a f t...
