MOTi Quick Start Guide - MOTi Gym Wearable
1 What's in the Box
MOTi x 1
Base x 1
Strap size-L x 1 (Upper Arm)
Strap size-S x 1 (Wrist / Ankle)
USB cable x 1
MOTi Key
Micro USB for Charging
MOTi Working Modes
2
2.1
Two Working Modes: Pedometer Mode and Workout Mode controlled by MOTi Key
Workout Mode:
Pedometer Mode: press the MOTi Key and hold for 3 seconds or longer time until
2.2
Please put MOTi on your Left Wrist while using the Device in Pedometer mode
(Button)
press the MOTi Key and MOTi vibrates for 0.5 second
MOTi vibrates. MOTi will vibrate for 2 times, each time lasts for 0.5
second.
LED Indicator
1
MOTi QSG-R1.3-2015 EN
Power Key
Advertisement
Summary of Contents for MOTi Gym Wearable
- Page 1 Workout Mode: press the MOTi Key and MOTi vibrates for 0.5 second Pedometer Mode: press the MOTi Key and hold for 3 seconds or longer time until MOTi vibrates. MOTi will vibrate for 2 times, each time lasts for 0.5 second.
-
Page 2: Charging The Battery
If LED Indicator start flashing in Red, which is alert of low battery power. Please immediately charge your MOTi. In case MOTi is not in use for a period of time, please still charge MOTi once a month for better sustaining the battery life. - Page 3 Right Ankle Put MOTi tied closely on your Left Wrist and get it parallel to the ground; Press the MOTi Key and LED will stay in Red for 2 seconds and then off automatically, MOTi is activated in Workout Mode.
- Page 4 Put MOTi on Right Ankle; please make sure it is in the right position and direction as shown in the picture. Press the MOTi Key, the blue light keeps on for 2 seconds then off. MOTi is in Workout Mode.
- Page 5 MOTi QSG-R1.3-2015 EN 5 MOTi APP Start-up MOTi is developed for testing under iOS8.1 and later version with BLE accessibility Please go to App Store and Install MOTi App. Click to Install MOTi APP...
- Page 6 MOTi QSG-R1.3-2015 EN Click MOTi to run the App after installation is done. Click to Open MOTi APP...
- Page 7 MOTi QSG-R1.3-2015 EN Start using MOTi App Click to Create Account...
- Page 8 MOTi QSG-R1.3-2015 EN 6 MOTi Setting and Connecting to Mobile Device Searching MOTi device for connecting with Mobile device Click Setting and then Click MOTi, MOTi searching starts as shown below Click for Connecting after MOTi Searching...
- Page 9 MOTi QSG-R1.3-2015 EN Connect MOTi to your mobile device MOTi is connected successfully with mobile device shown as below. You can also disconnect with Mobile by clicking “Disconnect”. Click to disconnect with Mobile...
- Page 10 Turn on: Press the Power Key, red and blue lights flash in turn for 5 cycles (total in 5 seconds), MOTi is on and the Connecting Mode is activated. Please make sure APP is installed and turned on before connecting.
- Page 11 MOTi if it is not in connecting mode with the mobile device) Wearing MOTi in right position and direction 3 different colors of LED light will be displayed for 2 seconds to indicate if MOTi is successfully recognized in 3 different wearing positions on your body separately following with 0.5 second of vibration.
-
Page 12: Fcc Statement
MOTi QSG-R1.3-2015 EN FCC Statement FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
