K-Mate BTS002 User Manual

Mini bluetooth stereo speaker
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Brief introduction................................................2
2. About the speaker..............................................................3
Getting started....................................................3
1. Overview..........................................................................4
2. Charging the battery of the speaker........................................4
Using the speaker................................................4
1. Turning on/off the speaker...................................................5
2. Pairing the speaker with Bluetooth devices...............................5
How to enter pairing mode....................................................5
3. Making a call with the speaker...............................................6
4. Music playback..................................................................8
5. Re-connecting with a Bluetooth device....................................8
6. Auto-off.............................................................................9
7. Using the speaker with an external device................................9
8. Connecting with a non Bluetooth device.................................10
9. LED indicator....................................................................11
10. Indication tone...................................................................11
Care and maintenance..........................................12
FAQs..................................................................12
Specifications......................................................13
BTS002
Mini Bluetooth stereo speaker
User's manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BTS002 and is the answer not in the manual?

Questions and answers

Summary of Contents for K-Mate BTS002

  • Page 1: Table Of Contents

    BTS002 Mini Bluetooth stereo speaker User’s manual Brief introduction…………………………………………2 1. Bluetooth wireless communication technology………………….….2 2. About the speaker………………………………………………….….3 Getting started…………………………………………….3 1. Overview………………………………………………………….…….4 2. Charging the battery of the speaker…………………………….…...4 Using the speaker………………………………………...4 1. Turning on/off the speaker……………………………………………5 2. Pairing the speaker with Bluetooth devices……………………..5 How to enter pairing mode………………………………………….…5...

  • Page 2: Brief Introduction

    A2DP—Advanced Audio Distribution Profile AVRCP—Audio/Video Remote Control Profile You can listen to music wirelessly using BTS002. It has the following features: 1) Pairing with a Bluetooth mobile phone or PDA supporting HFP. Answer a call, end a call and reject a call...

  • Page 3: Getting Started

    Every time the speaker is tured on, it will connect to the last connected device automatically. Remark: Even though the paired device and the speaker support the same Bluetooth profiles, functions may vary due to specification differences of the paired devices.

  • Page 4: Charging The Battery Of The Speaker

    2. Charging the battery of the speaker The speaker comes with a built-in rechargeable battery, prior to using it, it is recommendable to charge the battery fully for the first time. Connect the USB cable to an computer USB port and the USB cable plug to the charging socket of the speaker.

  • Page 5: Pairing The Speaker With Bluetooth Devices

    4) Activate your mobile phone’s Bluetooth function and set your mobile phone to search for Bluetooth devices. After the search is completed, select “BTS002” from the Bluetooth device list; 5) According to the indication, enter password or PIN No:”0000” and press ”...

  • Page 6: Pairing The Speaker With Bluetooth Transmitter

    5) After successful pairing and connecting, the LED will flash blue for twice every 4 seconds. Remarks: The pairing password of BTS002 is “0000”. So, BTS002 can only pair with Bluetooth transmitters whose pairing password is “0000”, too. If pairing still fails after several tries, refer to the Bluetooth transmitter’s user’s manual for further information.
  • Page 7 Press button Adjust the volume During a call adjust the volume Short press button twice Microphone mute During a call quickly Microphone Short press button twice Cancel mute mute quickly Press and hold button Call transfer (speaker to During a call for about 2 seconds untill you mobile phone) (speaker)

  • Page 8: Music Playback

    You have to select to transmit the sound via Bluetooth in the settings menu then and choose “BTS002” as speaker device. The music will be transmitted to the speaker then. Please refer to the your mobile phone’s user manual for further information.

  • Page 9: Auto-Off

    6. Auto-off The speaker will turn off automatically if no devices can be connected after 5 minutes in order to save power. Remark: When the speaker disconnects with a Bluetooth device, it will return to pairing mode for 3 minutes then return to standby mode for 5 minutes, at last it will turn off automatically.

  • Page 10: Connecting With A Non Bluetooth Device

    8. Connecting with a non Bluetooth device You can listen to music through the stereo speaker from an external device that does not even support the Bluetooth function. Step 1: Turn LINE IN/OUT button to “IN” as the following picture shows: Turn LINE IN/OUT button to “IN”...

  • Page 11: Led Indicator

    9. LED indicator While the speaker is charging LED indicator Status of the speaker The LED is red Charging in progress The LED is off Finish charging While the speaker is not charging LED indicator Status of the speaker The LED flashes red and blue Pairing mode alternately The LED flashes blue for twice...

  • Page 12: Care And Maintenance

    Care and maintenance Read the following recommendations before using the speaker. Following these you will be able to enjoy our product for many years. Do not expose the speaker to liquid, moisture or humidity to avoid the product’s internal circuit being affected. Don’t use abrasive cleaning solvents to clean the speaker.

  • Page 13: Specifications

    5. Why is there no sound when playing music with the speaker? a) Make sure the speaker has connected with Bluetooth device well; b) Ensure the paired device supports A2DP. 6. Why can’t I remotely control the pause, play, previous track and next track functions with the speaker when playing music? The function needs the Bluetooth device paired with the speaker to support AVRCP (Audio/Video Remote Control Profile).
