USER'S GUIDE
Young Shin Electronics,Inc.
USER'S GUIDE
2WAMANT
FCC ID : O44J2WAMANT
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions :
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference
that may cause undesired operation.
CAUTION : Changes or modifications not expressly approved by the party
responsible for compliance could void the user s authority to
operate this device.
Young Shin Electronics, Inc.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 2WAMANT and is the answer not in the manual?

Questions and answers

Summary of Contents for Young Shin Electronics 2WAMANT

  • Page 1 (2) This device must accept any interference received, including interference that may cause undesired operation. CAUTION : Changes or modifications not expressly approved by the party responsible for compliance could void the user s authority to operate this device. USER'S GUIDE Young Shin Electronics,Inc. Young Shin Electronics, Inc.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Wiring Diagram Page 4 Notes for Wire Connection Page 6 Switch and Jumper Setting Page 12 Installation of Antennas Page 12 Option Programming for Four Button Remotes for FM or SS Units Page 13 Installation of AM Antennas Page 14 Option Programming with Programming Button for AM Units Page 14...

  • Page 3: Wiring Diagram

    Wiring Diagram Page 4 Page 5...
  • Page 4 Pin #7: Green/ Red This wire is used to power the (+) Ignition This wire is also an input for the Young Shin Electronics,Inc. used to monitor the status of the vehicle and for programming. Pin #8 : Black This wire needs to be connected to a chassis (-)Ground.
  • Page 5 Alternator input. Either way you use it, it is for engine sensing. This wire tells the Young Shin Electronics,Inc. when to quit cranking the starter of the vehicle. There are a couple of ways to find the correct voltage for either type of sensing.
  • Page 6 Please note that this feature requires more advanced installation. Error Number Tach Learning Error Diagnosis Please call Technical Support for details. (# of times parking lights flash) Dip Switch #1 is on alternator sensing. Pin #4 : Blue This wire is a (-) 200mA Unlock Output Manual Car Key is in the off position.

  • Page 7: Switch And Jumper Setting

    When installing on automatic transmissions the jumper must be cut. Please note : if a unit with a cut jumper is installed on a manual transmission the warranty will Young Shin Electronics,Inc. be void and will have no liability. Wait a few seconds. You will hear a number of chirps and see a...

  • Page 8: Installation Of Am Antennas

    Installation of AM Antennas Within 4 seconds after you released the switch, press and release PS for the number of times of the option number you want to change. The antennas have been calibrated for Within 2 seconds, the LED and Parking Lights will flash the same horizontal installation at the left-top corner number of times as you pressed the switch at step 3.

  • Page 9: Option Programming For Six Button Remotes

    Option Programming for Six Button Remotes Some vehicles such as Mercedes-Benz and the Lexus ES300 require you to The procedures will be same as the 4 button remotes except the use unlock the car to disarm the factory alarm before remote starting the vehicle. of the different buttons.

  • Page 10: Diagnosing Problems With Auto-Start

    Diagnosing Problems with Auto-Start Feature Optional Factory Default If there is a problem in auto-starting your car, you will see three flashes of the parking lights when you attempt to auto-start the car. Wait for 2 seconds and the Cold Start with Temp Sensor cause for the error, will be indicated by the number of times the parking lights flash.
