Summary of Contents for DS 1260
- Page 1 Weighing Indicator (Ds-1260) Operation Manual 혼을 담은 제품으로 귀사의 만족스런 파트너가 되겠습니다 감사합니다 DS LOAD CELL - I -...
- Page 2 - II -...
- Page 3 WEIGHT DS-1260 ZERO TARE SET/ 1) LAMP. - ZERO : IN CASE THE WEIGHT IS “0”, THE O-POINT LAMP IS INDICATED. - TARE : IN CASE THE VESSEL HAS THE WEIGHT, IT IS LIGHTED. - SP 1 : IN CASE (+) WEIGHT VALUE IS LARGER THAN SP1.
- Page 4 - THERE IS DIP S/W FOR ZERO POINT AND SPAN. (1-6ZERO POINT AND 7-8 SPAN) 5) AC-IN - THE USABLE VOLTAGE OF DS-1260 IS THE DOUBLE USE OF AC110V/220V, AND THUS CAN BE ADJUSTED. BEFORE THE POWER IS APPLIED, BE SURE TO CONFIRM THE USABLE VOLTAGE, AND THEN WHEN THE CHANGE-OVER IS REQUIRED, OPEN THE CASE, AND THEN ADJUST THE CHANGE-OVER SWITCH NEXT TO THE FOLLOWING TRANSFORMER.
- Page 5 1) OUTLINE - WHAT IS SETUP ? IT MEANS THAT THE FUNCTION OF EQUIPMENT IS PROPERLY SELECTED IN ACCORDANCE WITH THE USABLE PURPOSE. - CALIBRATION THIS IS THE WORK WHICH INDICATES THE CORRECT WEIGHT BY THE ADJUSTMENT OF “0” POINT PASSAGE SCOPE AND THE SCALE. 2) METHOD - IN ORDER TO USE PROPERLY UPON THE PURPOSE OF EQUIPMENT, BE SURE TO PERFORM THE SETUP FIRSTLY, AND THEN TO PERFORM THE CALIBRATION.
- Page 6 3) SET-UP ( F-FUNCTION AND SETTING ) F-Function FUNCTION CONTENTS S & C MODE CHANGE-OVER DECIMAL POINT POSITION 0, 1, 2, 3, LESS THAN(0, 0.0, 0.00, SETTING-UP 0.000) THE DECIMAL POINT WEIGHT BACK-UP Normal, Back - UP ZERO TRK, SCOPE SETTING-UP ～...
- Page 7 (1) SETUP-SETTING WHEN “CLR” IS PRESSED ON S&C MODE, THE INDICATOR SHOWS "F01-XX". “F” ON THE INDICATOR IS THE ABBREVIATION OF FUNCTION OF SETUP MODE, AND THE NUMBER OF FURTHER 2 FIGURE, SHOWS THE FUNCTION NUMBER. THE NUMBER OF THE LAST 2 FIGURE SHOWS THE SETTING - UP OF FUNCTION ON THE RELEVANT F.N.
- Page 8 * SET-UP ( F-FUNCTION AND SETTING ) DECIMAL POINT ● 0.00 0.000 Weight Back-up ● Normal Mode Back-up Mode NOMAL:THE WEIGHT IN NOT MORIZED. �� BACK-UP:IT KEEPS THE UNDER WEIGHING, AS IT STANDS, IN THE POWER FAILURE. �� NOTE) AFTER ADJUSTING THE WEIGHT IN THE NOMAL BACK-UP : STATE, SET UP IT TO BACK-UP MODE.
- Page 9 VESSEL KEY OPERATION MODE ● STABLE VESSEL KEY NON-STABLE VESSEL KEY * MAKING THE VESSEL KEY TO PERFORM THE STABLE & NON-STABLE OPERATION ZERO-POINT KEY OPERATION MODE ● STABLE VESSEL KEY NON-STABLE VESSEL KEY * MAKING THE ZERO KEY TO PERFORM THE STABLE & NON-STABLE OPERATION HOLD MODE ●...
- Page 10 SPAN ADJUSTING CONSTANT AMENDING MODE. ADJUSTING METHOD IF THE NUMERICAL KEY 99 IS PRESSED IN THE SET-UP MODE, AND THEN CLR KEY IS PRESSED, THE CONSTANT IS INDICATED IN THE WEIGHT. IN THE AMENDMENT, DO NOT REGARD THE DECIMAL POINT, AND THEN PRESS SET/CAL KEYAFTER THE INPUT.
- Page 11 2) CALIBRATION METHOD IF “SET/CAL” IS PRESSED ON S&C MODE, THE INDICATOR SHOWS “D XX”. THE CALIBRATION IS DIVIDED TO 7 STEPS, AND THEN WHEN EACH STEP IS DONE IN ORDER, AND THE LAST “END” IS INDICATED, THE PERFECT CALIBRATION GETS TO BE FINISHED. BE SURE TO USE “SET/CAL”...
- Page 12 3) ERROR - ERR-01----SETTING-UP MORE THAN 1/10000 (1 SCALE VALUE/TOTAL WEIGHT) - ERR-02----THE SCALE-WEIGHT-SETTING-UP VALUE IS LAGER THAN THE SETTING-UP VALUE OF TOTAL WEIGHT. - ERR-03----THESCALE-WEIGHT-SETTING-UP VALUE IS SMALLER THAN 80% OF TOTAL-WEIGHT SETTING-UP VALUE. - ERR-04----THE MOTION OF WEIGHT OCCURS IN THE CALCULATION OF CONSTANT VALUE.
