Dynadie 12252 Operating, Maintenance And Safety Instructions

Models:
12250 – 5,000 Strokes Per Minute
12252 – Dynadie ® Kit
12254 – Dynadie ® Scraper Kit
WARNING
!
Index Key
No. Part # Description
1 02581 Cover
2 02584 Dowel Pin
3 02586 Wrist Pin Coupler
4 02587 Bearing
5 02583 Crank
6 96071 Set Screw (2)
7 02582 Retaining Ring
8 02578 Yoke
9 02514 Housing
10 02518 Barrel Slider
11 02576 Scuff Plate
12 02575 Lock Plate
13 95585 Roll Pin
14 95291 Screw (2)
15 02520 Slider
16 02577 Barrel Control
17 02521 Socket
18 02522 Ball Joint
19 02523 Retainer
20 02572 Spring
21 02519 Tool Holder
22 96113 Button Head Cap Screw
23 02573 Guard
24 02574 Nut
25 02500 Insert
26 96166 Set Screw
27 12267 Insert
28 50784 Set Screw
29 01041 Grease Fitting
30 01461 Lock Nut
31 01558 Insulator Collar
32 12153 Bearing (2)
33 02579 Key
34 02510 Planetary Carrier
35 02513 Gear (2)
36 02512 Gear Shaft (2)
37 02511 Ring Gear
38 02649 Bearing
39 54529 Shim Pack (3/pkg.)
40 02507 Front Bearing Plate
41 01479 Spacer
42 02504 Rotor
43 02505 Blades (4/pkg.)
44 02506 Cylinder
45 50767 Pin
46 02676 Rear Bearing Plate
47 02696 Bearing
48 02679 Shield
49 01024 O-Ring
50 95730 O-Ring
51 01469 Speed Regulator Assembly
52 12257 Housing
53 95558 Retaining Ring
54 01449 Valve Stem
55 12132 Pin
56 01448 Throttle Lever
57 01464 Seal
58 01472 Tip Valve
59 01564 Air Control Ring
60 01468 Spring
61 95711 Retaining Ring
62 01578 Inlet Adapter
63 01486 Felt Silencer (4)
64 01379 Bronze Muffler
65 96065 O-Ring
66 01446 Air Defector
67 95620 Retaining Ring
68 94535 Muffler Assembly
69 94407 Flow Control Swivel
Always operate, inspect and maintain this tool in accordance with the Safety Code for portable air tools
(ANSI B186.1) and any other applicable safety codes and regulations. Please refer to Dynabrade
Warning/Safety Operating Instructions for more complete safety information.
1
T
29
W
1
A
8
28
9
A
8
THREADS
10
11
12
13
14
A
8
W
1
15
16
A
8
6
17
A
2
19
18
W
1
20
21
22
A
8
T
23
24
T
17 N•m
25
26 27
Dynadie
A 6
8
W
1
2
A
1
4
3
37
33
34 N•m
35
34
32
31
30
41
LEFT
HAND 39
40
38
RIGHT
57
HAND
THREADS
51
49
50
A
52 53
8
17 N•m
54
Parts Page Reorder No. PD01•51R
Effective June, 2001
Air Motor and Machine Parts
STROKE LENGTH
ADJUSTMENT
INSTRUCTIONS
1. Disconnect tool from
air supply.
2. Remove 02581 Cover.
8
3. Rotate 02583 Crank until
7
5
96071 Set Screw is visible
through side of 02514
Housing.
32
4. Using 3mm hex key loosen
set screw.
5. Leave hex key in set screw
and rotate 02583 Crank to
desired location from
0-6mm.
W
6. Tighten 96071 Set Screw
1
and secure cover.
36
45
O
1
43
44
42
23 N•m T
63
A
8
61
64
59
62
60
O
58
1
55
56 69
Oil: O = Air Lube
O
1
A
Adhesive: A
A
A
T Torque: N•m x 8.85 = In. - lbs.
Wicking: W
W
1
III
®
'
s
47
48
46
67
65
66
68
KEY
= Loctite #609
1
= Loctite #271
2
= Loctite #567
8
= Gear Oil
