User Manual

(Model: JS-300G)

J COMMUNICATIONS CO.,LTD.

Address: 124-4, Ojeon-dong, Uiwang-si, Gyeonggi-do, Republic of Korea

Tel: 82-31-428-7326, Fax:82-31-451-2994

http//:www.jcomco.com

- 1 -

Table of Contents

Need help?

Do you have a question about the Road Eye JS-300C and is the answer not in the manual?

Questions and answers

Summary of Contents for J COMMUNICATIONS CO Road Eye JS-300C

Page 1 User Manual (Model: JS-300G) J COMMUNICATIONS CO.,LTD. Address: 124-4, Ojeon-dong, Uiwang-si, Gyeonggi-do, Republic of Korea Tel: 82-31-428-7326, Fax:82-31-451-2994 http//:www.jcomco.com - 1 -...
Page 2: Table Of Contents
Table of Contents 1. Product Introduction 2. Precautions for Safety 3. Cautions in Use 4. Specification 5. Package Contents 6. Description of Part 7. LED Signal Descriptions 8. Installation Guide 9. Function Description 10. How to use Viewer Program - 2 -...
Page 3 The contents of this document are protected by applicable Republic of Korea and International Copyright Laws. Unless otherwise stated, the copyright owner is J COMMUNICATIONS CO.,LTD. The document and information contained within may not be copied, transmitted, reprinted, published, translated, hosted, or otherwise distributed by any means without the explicit written permission of the copyright owner.
Page 4: Product Introduction
1. Product Introduction Road Eye is a Driver Recording System which applies GPS (Global Positioning System), GPRS and 3D acceleration gravity sensor (G-Sensor). Before using this product, please be sure to read this manual. Actual product specifications may differ from what is indicated in this manual as product enhancements are implemented without prior notice.
Page 5: Cautions In Use
This product is designed to be used with Cigar Jack Power. In case of using direct electric power (B+ Power) of car, please discuss with a specialist, and any problem occurred in this case will belong to users responsibility. 3. Cautions in Use 3-1.
Page 6 (Refer to the manual) Rights of all the software and hardware related to this product belong to J COMMUNICATIONS CO., LTD. Unauthorized reproduction, processing and distributing can be punished by intellectual property rights management law as well as claimed compensation for damages.
Page 7: Specification
4. Specification Front Camera 120° ⅓” CMOS 300K Pixel Digital Sensor / WDR Support External Camera Option (90° ¼” CCD 270K Pixel NTSC) H.264 (VGA 640*480 up to 30fps) Recording Resolution ★ 2ch use : VGA 640*480 up to 15fps Internal GPS Shock Sensor Internal 3D G-Sensor...
Page 8: Package Contents
5. Package Contents Please check the contents after opening the gift box. (Refer to the below images) JS-300G Cigar Jack Power Cable SD Memory Card User Manual Viewer Program CD A/V Cable (For TV Connection) Cable Tie / Holder GPRS Ant (Only for JS-300G) External Camera &...
Page 9: Description Of Part
6. Description of Part Lock Front Camera Main Power Card 1.TV Out Jack (A/V Mode) SIM Card Slot 2.External Camera Video In (Only for JS-300G) Jack External Emergency GPRS Antenna YELLOW: GPRS (Only for RED: Event Mode Double Faced Foam Jack BLUE: GREEN: Normal Mode...
Page 10: Led Signal Descriptions
7. LED Signal Descriptions GREEN BLUE YELLOW Classification Status (Event) (Full Time) (GPRS) (GPS) Power connecting ( With SD Card ) Blinking at 1 sec interval one after ○ ○ ○ another. Power Connecting (Without SD Card) ○ ○ Blinking at 0.5 sec interval by turns Stand by Event Recording ○...
Page 11: Installation Guide
8. Installation Guide 8-1 .PRECAUTIONS Turn off the engine before installation. Connect the main power of the device at last after installation. ( , here in after called “Power”) Insert SD Memory card before connecting the device. Install the device in safe and bright place. Connect the main power through cigar jack provided (DC 12V ~ 24V).
Page 12 5. Working Test Play back the saved data after testing drive. Then, check if the data is recorded correctly and revise the camera place on it. ★ JS-300G is working based on High- Sensitivity Camera Sensor. The recorded video image can be shown dark if the device is installed toward the sky.
Page 13 8-3. Start 1. Insert SD Card into JS-300G, then power on. Red, Yellow and Blue LED will light sequentially at a second interval. about 3 seconds after lighting, JS-300G will start running. If it powers on without SD Card, Red and Green LED will be blinking alternately at 0.5 sec interval. In this case, disconnect the power and connect power again after inserting SD Card.
Page 14 8-5. Normal Record Mode (Full Time Recording) 1. Green LED is blinking at a second interval on Normal Record Mode. 2. Normal Record Mode records video and audio at 5 minute interval successively. 3. If SD Card storage is full during Normal Mode, JS-300G will overwrite from the file saved first. 4.
Page 15 If presses Down Key on either Normal Record Mode or Event Record Mode for more than 3 seconds, Calibration will be operated with Red LED blinking rapidly at 0.1 second for a second. After the calibration, G-Sensor Data will show the value, X = 0g, Y = 0g and Z = +1g, regardless of the mounting place.
Page 16: Function Description
Head-On Collision Back-Up Collision 9. Function Description 9-1. GPRS Functions (GPRS Function is only for JS-300G) 9-1-1. GPRS Specification Used band: Quad-band (E-GSM 850 / 900 / DCS1800 / PCS1900 MHz) Operated Frequency ; -. EU (Up link: 880.200 MHz ~ 914.800 MHz , 1 710.200 MHz ~1 784.800 MHz) (Down link: 925.200 MHz ~ 959.800 MHz, 1 805.200 MHz ~ 1 879.800 MHz) -.FCC(Up link: 824.200 MHz ~ 848.800 MHz , 1 850.200 MHz ~1 909.800 MHz)
Page 17 Yellow LED blinks under GPRS disconnection and it is lighting continuously when GPRS is connected and available to data Tx / Rx. When GPRS Data is transmitted or received, Yellow LED blinks at 0.1 second interval. JS-300G provides to transmit the below data such as G-Sensor value, GPS data through SMS to the designated number.
Page 18 1. GPRS Bearer -. IP Address: Proxy Server IP Address. Proxy Server can be skipped when it is not used. . APN: Access Point Name -. Proxy port: HTTP Proxy port (TCP) -. User ID: Authentication User ID -. Password: Authentication Password 2.
Page 19 ★ TV-Out Signal Format (NTSC, PAL, PAL-M) setting should be done through the configuration set on the viewer program. File Viewer Mode Connect the power under the status of pressing PLAY Key and File Viewer Mode which can replay the saved files through TV-Out is started. (Green LED is blinking on operating.) 1.
Page 20 3. Select the target file to playback Playback the file recorded on Event Mode 1. Select EVENT FILE VIWER 2. Select EVENT File 9-3. Playback through PC Road Eye JS-300G Viewer Program installation 1. Insert CD provided into PC and click “Next” when the below setup Wizard start image pops up. 2.
Page 21 3. Select Start Menu folder and press “Next” button. - 21 -...
Page 22 4. Press “Next” button when the below image pops up. 5. Press “Install” button to install the program when the below image pops up. - 22 -...
Page 23 6. When the installation is completed, the below image pops up. Then, press “Finish” button to finish the process. - 23 -...
Page 24 Codec Installation To play back the files recorded through JS-300G Viewer program, K-Lite codec provided with a bundle CD must be installed. 1. Double click Klcode475b.exe file on CD and start the installation. Press “Next” button when the below image pops up. 2.
Page 25 4. Press “Next” button when the below image pops up. 5. Press “Next” button when the below image pops up. 6. Press “Next” button when the below image pops up. - 25 -...
Page 26 7. Press “Next” button when the below image pops up. 8. When the installation is completed, the below image pops up. Then, press “Finish” button to finish the process. - 26 -...
Page 27: How To Use Viewer Program
10. How to use Viewer Program - Double click Viewer Program Icon . - Viewer Program Main Screen Playback Display Slide Bar: It shows a play back progress and users can start play back a file on a specific part with moving it.
Page 28 Menu Button and Control Button and Control Function Description Volume Control It controls the play volume. Stop Stop playing and back to the start of the playing file. Previous Play the previous file when selects the plural files and views in series. Play / Pause Press this key to pause during playing.
Page 29 Play List Button and Control Button and Control Function Description Open Folder It selects the folder to play. Delete It deletes the selected file and G-Sensor, GPS Log file which were saved together. ★ In the case of the file recorded by 2channel, it would deletes the file recorded by 1channel together.
Page 30 Playback Movie File Playback a single file 1. Select a target root folder in SD or PC with clicking Open Folder on Playback List screen. 2. Select a target file to play on the file list and double click. After selecting a file on the list, Playback button can be pressed to play.
Page 31 Configuration Set Click Configuration Set button and the below configuration image will pop up. 1. G-Sensor Trigger Level: Set the sensitivity of G-Sensor. Move the slide bar and select the value between 0.10 ~ 0.99. (Default Value: 0.50) (0.30: Sensitive, 0.50: Normal, 0.70: Dull) 2.
Page 32 2. Insert SD Card into JS-300G and connect the power. 3. When Red, Yellow and Blue LED is sequentially on at a second interval and JS- 300G is started, Update is progressed with Green LED blinking rapidly at 0.1 second interval. 4.
Page 33 Normal Movie_yyyy mm dd \Gps Folder GPS Log on the Normal Record Mode is saved on the name of “gps_yyyymmdd_hhmmss.txt” in this folder. 4. Setup Folder Environment Variables and G-Sensor Calibration Data files are saved into this folder. 5. Temp Folder This is a folder to save the temporary files for GPRS functions.
Page 34 This Limited Warranty shall apply to the JCOM Product including all accessories as contained within the original JCOM gift box (“the Product”). J Communications Co., Ltd. (JCOM) warrants that product from its authorized distributor will meet the applicable product specifications and be free from all defects in material and workmanship for an applicable period herein (“Limited Warranty”).
Page 35 10. Before returning any units for service, the Customer is solely responsible for backing up data and removing any confidential, proprietary, or personal information from the Product. JCOM’s is not responsible for damage to or loss of any programs, data, or removal storage media. 11.
Page 36 or limitation of incidental or consequential loss or damage, or limitation of the implied warranties, in which case the preceding limitation of exclusions may not apply to such Customers. Please note Warranty service availability and response times may vary from country to country and may also be subject to registration requirement in the country of purchase.
