6Harmonics Inc.
GWS-3000
Operating Manual
September 12th, 2013
Steve Beaudin & Yu Zhou
Phone: 613-366-1768
Email:
steve@6harmonics.com
yu.zhou@6harmonics.com
Version 1.0
Security Notice: This document is confidential. The Intellectual Property Rights belong to 6Harmonics Inc.
@2013 6Harmonics Inc. All Rights Reserved
1
Advertisement
Table of Contents
Summary of Contents for 6Harmonics GWS-3000
- Page 1 6Harmonics Inc. GWS-3000 Operating Manual September 12th, 2013 Steve Beaudin & Yu Zhou Phone: 613-366-1768 Email: steve@6harmonics.com yu.zhou@6harmonics.com Version 1.0 Security Notice: This document is confidential. The Intellectual Property Rights belong to 6Harmonics Inc. @2013 6Harmonics Inc. All Rights Reserved...
-
Page 2: Table Of Contents
7.14 getchanlist command ......................22 7.15 getrxgain command......................... 22 7.16 setrxgain command ........................ 23 7.17 monitor command ........................23 7.18 setinstaller command ......................23 7.19 getinstaller command ......................23 7.20 setsubchanlist command....................... 24 7.21 getsubchanlist command......................25 @2013 6Harmonics Inc. All Rights Reserved... - Page 3 7.28 reboot command ........................27 8 Power Control and Link Configuration..................... 27 8.1 Manual Power Control........................ 27 8.1.1 Point to Point Link ................... 28 8.1.2 Point to Multi-Point Link................... 29 Automatic Power Control ....................... 31 @2013 6Harmonics Inc. All Rights Reserved...
-
Page 4: Revision Control
Removed the “settxatten” and “gettxatten” from the User Interface commands. Steve Beaudin September 13 Approve Released for FCC submission 2014 Table 1: Revision history of the document @2013 6Harmonics Inc. All Right Reserved... -
Page 5: Fcc Regulatory Information
This device must not be co-located or operating in conjunction with any other antenna or transmitter. Only the following components are approved for use with the radio. • Power over Ethernet Mid-Span: PowerDsine 9001G-40/SP @2013 6Harmonics Inc. All Right Reserved... -
Page 6: Introduction
• OMNI Antenna SL15918A, 3.5 dBi Gain 4. Introduction The GWS-3000 radio modules are a wireless access solution which utilize the unlicensed TV Band, also known as “White Space Spectrum.” These radio’s are designed to provide high reliability, non line of sight (NLOS) point to point (PtP) or point to multi-point (PtMP) radio links at a very low cost of ownership. -
Page 7: Product Overview
Wall Mount Configuration. A picture of the GWS-3000 can be seen in the diagram above. The module measures 30.5 cm in width, 30.5 cm in height. The thickness of the module is 8.5 cm from the front panel to the heat fins on the rear of the enclosure. -
Page 8: System Diagram
This User’s Manual is intended to provide guidance on what the Host Software does and how to use the Host Software to make the GWS node function properly. The GWS-3000 Host Software provides the following functionalities: a) Initialize host board and GWS-3000 radio; @2013 6Harmonics Inc. All Right Reserved... -
Page 9: Node Initialization
None Warning: This connection is for a professional installer which has been trained by 6Harmonics and can damage the module if performed improperly. This connection is used to burn the first image on the host board. The module is shipped with the latest software pre-loaded and this procedure should not need to be performed by the customer. -
Page 10: Ssh
6Harmonics. Root access requires a User Name and Password and is only available to 6Harmonics personnel or professional installers which have been trained and certified by 6Harmonics. This guide is meant for both non-certified users as well as professional installers which have been trained and certified by 6Harmonics and as such we provide instructions on how to use both the User Interface and the SSH interface. - Page 11 @2013 6Harmonics Inc. All Right Reserved...
-
Page 12: Configure The Ip Address Of The Nodes
After downloaded the image, reboot the node and choose boot from NAND. The default ip address for GWS node is 192.168.1.1 Default mode is BTS. @2013 6Harmonics Inc. All Right Reserved... -
Page 13: Upgrade Image
6.7 Configurations 6.7.1 Configure GWS Node Mode as BTS or CPE GW-3000 S Node can be configured as BTS or CPE. By default: GWS Mode is BTS SSH to GWS Node, open /etc/init.d/config-wireless @2013 6Harmonics Inc. All Right Reserved... - Page 14 By default: GWS Mode is BTS, to set it to CPE mode, change config_ap to config_sta Save it, type re in SSH shell @2013 6Harmonics Inc. All Right Reserved...
- Page 15 SSH shell to reboot the GWS node Now GWS Node is acting as CPE @2013 6Harmonics Inc. All Right Reserved...
-
Page 16: Wireless Configuration
, save it, type config_ap in SSH shell then reset the GWS Node. 6.7.2 Wireless Configuration There are two ways to modify the wireless configuration 1. For temporary change. (No reset needed) Open /etc/config/wireless @2013 6Harmonics Inc. All Right Reserved... - Page 17 Open /sbin/config_ap for BTS or /sbin/config_sta for CPE Attention: Modifying the wireless settings are for debug purposes only and you must be trained by 6Harmonics prior to attempting, otherwise you may impair performance of the wireless link. @2013 6Harmonics Inc. All Right Reserved...
-
Page 18: Radio Turn On (For Non Database Application)
Show sub channel list txoff Turn off Tx txresume Resume the Tx gettxstatus Show tx status getrxstatus Show rx status setchanlist Set channel list setsubchanlist Set Sub Channel list setrxgain Set Rx Gain getrxgain Show Rx Gain @2013 6Harmonics Inc. All Right Reserved... -
Page 19: Help Command
US, the module needs to querry the available channel from FCC database and the SW will only allow the module to tune to a channel which is part of the channel list received from the data base. GWS Cmd >setchan 35 @2013 6Harmonics Inc. All Right Reserved... -
Page 20: Getchan Command
7.8 settxpwr command The “settxpwr” command allows the user to set the tx power in 0.5dbm steps. The following is to set the tx power to 11.5dbm: GWS Cmd >settxpwr 11.5 GWS Cmd > @2013 6Harmonics Inc. All Right Reserved... -
Page 21: Gettxpwr Command
Note: The “u” and “d” commands are used to perform manual power control and load balancing to optimize network performance. The can be used to increase or decrease transmit power during while the node is in service and carrying traffic. @2013 6Harmonics Inc. All Right Reserved... -
Page 22: Setchanlist Command
“rxatten0” and “rxatten1”. “rxatten0” is situated after the LNA but before the downconverter and for maximum sensitivity should be left at a value of 0. “rxatten1” is located at IF @2013 6Harmonics Inc. All Right Reserved... -
Page 23: Setrxgain Command
White Space database and the node will not be allowed to connect to the database unless there is a valid entry. 7.19 getinstaller command The “getinstaller” shows who installed the GWS Node @2013 6Harmonics Inc. All Right Reserved... -
Page 24: Setsubchanlist Command
Setsubchanlist 14 15 16 17 18 19 20 21 22 The software will then know that the node can only transmit on a channel between 14 and 22, inclusive. @2013 6Harmonics Inc. All Right Reserved... -
Page 25: Getsubchanlist Command
The software will only allow the user to increase the power up to the limit allowed by the regulatory standard in a given market. For the GWS-3000 in the US, this is 20 dBm. -
Page 26: Getagcmode Command
AGC completely using the “setagcmode 0” command. The receiver of the GWS-3000 has been designed to sustain fairly high levels of interference and for the vast majority of deployments leaving the radio in “agcmode 2” (the default configuration) will provide good results. This information is purely to give our customers some insight and help them optimize network performance in the even that a node is subjected to very strong interference. -
Page 27: Getrxatten Command
8.1 Manual Power Control For small networks the user may prefer to perform the power control manually to have a good control over the interference and to balance the load between links. @2013 6Harmonics Inc. All Right Reserved... -
Page 28: Point To Point Link
Below is a description of how to perform power control manually using the GWS- 3000 user interface. 6Harmonics is currently developing a SON algorithm which will perform power control at the network level. This algorithm is not yet released but should become available sometime late in 2013 or early 2014. -
Page 29: Point To Multi-Point Link
Ideally, the signal from all CPE’s should be received by the BTS at about -75 dBm. 8.1.2.1 Configure the link: • Telnet into the BTS and each of the CPE’s. • From the telnet session type “monitor” @2013 6Harmonics Inc. All Right Reserved... - Page 30 Furthermore, for some links it may not be possible to achieve an RSSI of -75 dBm, at which point the link should be set to transmit at the maximum permissible power to get the best RSSI and hence SNR. @2013 6Harmonics Inc. All Right Reserved...
-
Page 31: Automatic Power Control
Automatic Power Control 6Harmonics is in the process of developing and testing an automatic power control algorithm. This capability will be important for larger deployments and will be introduced later in 2013. The feature is not yet available. END OF DOCUMENT...
