- Page 1 For VITA PREMIUM SPA Installation and user’s manual Read this manual before operation...
-
Page 2: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS For your own safety and that of your product, make sure to following the safety precautions below. Fail to follow the instruction may result in serious injury, property damage or death. Improper installation or operation will void the warranty. Read, understand and follow all instructions: DANGER Risk of accidental drowning:... - Page 3 the average temperature of spa-pool water should not exceed 40°C(104°F). - Since excessive water temperatures have a high potential for causing fetal damage during the early months of pregnancy, pregnant or possibly pregnant women should limit spa water temperatures to 38°C(100°F).
-
Page 4: Specifications
1. SPECIFICATIONS 1.1. Specifications VITA PREMIUM 6 persons Model SP-VIP160 Capacity 6 persons Ø 72.4″ × 28,7″ Dimension (outer) 184 cm × 73 cm Ø 62.9″ × 28.7″ Dimensions (inner) 160 cm × 73 cm Water capacity 1100 L - 242 gal GB... -
Page 5: Package List
2. PACkAGE lIST 2.1. Package list Ensure to check all parts are present: 8x Foam walls Pump unit Outer liner Inner liner Top cover 2x Caps 2x Filter cartridge RCD plug 10mA Drain hose Drainage cap Inflation hose... -
Page 6: Installation
The installation and maintenance instructions described in the following pages are also detailed on the DVD included. Our installation and maintenance videos are also available on our website www.netspa.eu. 3.1. Site selection WARNING : Before proceed to installation your spa, please make sure that the future location meets the following conditions : •... - Page 7 3.3. Assembling 1) Lay your spa outer liner out in the 2) Add the foam wall segment with the 3) Ensure that the three connection selected area. three holes in it for connection to the holes in the foam wall are aligned base liner.
- Page 8 13) Your pool is now assembled. 14) Then inflate the cover of your spa. 15) Connect the inflation hose to the connector and connect your pump unit. 16) Insert the inflation hose into the 17) Inflate this structure for about 3 18) Then remove the inflation hose.
- Page 9 3.4. Pool cover and security After each use, the control panel must be locked and the pool must be coated with its top cover and it must be at- tached to the base protector with the safety buckles. Each safety buckles has a lock system ; closed buckle, the latch in up position locks the buckle, the latch in down posi- tion unlocks the buckle.
-
Page 10: Control Panel
4. USAGE 4.1. Control panel Screen Temperature Increase units indicator temperature Decrease temperature Temperature units selector Massage Filtration Heater 4.2. Functions Once powered-up, the LED displays the current water temperature automatically. The temperature units selector changes the temperature units from Celsius de- grees to Fahrenheit degrees. - Page 11 Press the filter button to activate the water filtration. The green indicator light will turn on when the filtration system is activated. Note: - If massage function is on, the filtration can’t be activated. Press the heating button to activate water heating and filtering system at the same time.
-
Page 12: Maintenance
5. MAINTENANCE 5.1. Water maintenance WARNING : A bad pool water quality can harm your health. Depending on the frequency and conditions of use: - The filter cartridge should be regularly cleaned (150 hours max.). - The filter cartridge should be replaced every 1 to 2 month. - The pool water should be changed every 15 to 30 days. - Page 13 5.3. Drainage and storage Drainage Check the stopper on the bottom of the pool and the drain cap. Unscrew the drain cap. Connect the drainage hose. Remove the stopper on the bottom of the pool. Completely drain all water from the spa pool.
-
Page 14: Troubleshooting
Clean or Replace the cartridge (see chapter 5.2) Water is not clean Pool filled water quality Change the pool water completely Improper water treatment Refer to the chemical manufacturer’s instructions IMPORTANT Do not return the product to the store Contact your local after sales service on www.netspa.eu. - Page 15 The filled water is over 50°C not work, buzzing described in next paragraph. If this does ture indicator. (122°F). warn. not solve the problem, contact NetSpa service center. ·Inlet or outlet on inner wall are ·Clean inlet and outlet blocked. ·Clean or replace filter cartridge...
-
Page 16: Return Procedure
6.3. Return procedure In case of malfunction, please contact the customer service center NetSpa by connect- ing to the following address: http://support.netspa.eu After verifying your information, and an online diagnosis of your spa one of our repre- sentatives will contact you to provide you indicated the procedure. -
Page 17: Warranty Registration
● This warranty is valid only in the country of purchase in such countries where NetSpa sells and services the same model with identical technical specifications. - Page 18 NetSpa is a trademark of Poolstar group...
