BH-M76 is a sports stereo bluetooth headset with music time about 4 hours with 50% Volume when fully
charged when fully charged；easy to charge(using standard micro USB cable，5V charging voltage)，support
bluetooth 4.1profile(HFP v1.6, A2DP v1.2, AVRCP v1.4)，and TTS voice prompt、dual language switch function and
etc；two kinds of wearing style：with ear hook or directly in ear，rotating earplug angle to wear according to the
wearing style.
■ Function button
"Multi-function button"
POWER OFF state
Long press this button for 3 seconds：Power ON and entering into pairing mode
Long press this button for 1 seconds: Power ON or entering into re-connection mode
POWER ON state：
Short press this button：Play/Pause/Answer/Hang up/End/cancel call
Double click this button: Redial the last outgoing call
Long press for 1 seconds：Reject the call when call coming
Long press for 3 seconds：Power OFF
"Volume down button"
Long press this button for 1 seconds:Previous song/Mute when calling
Short press this button ：decrease the volume
"Volume up button
Long press this button for 1 seconds:Next song/Audio switch between phone and headset when calling
Short press this button：increase the volume
"Magnetron switch function"
ON and Connection State：
Magnetron adhesion state：Adhesion is in pause state when music playing
Magnetron separation state：Magnetron switch is in playing mode when pause music
BH-M76 Bluetooth headset
English Manual V001
"
Adhesion is in end state when call coming
Magnetron switch is in hang on call state when call coming in Magnetron separation state
Advertisement
Table of Contents
Related Manuals for Sky Wing BH-M76
Summary of Contents for Sky Wing BH-M76
- Page 1 BH-M76 Bluetooth headset English Manual V001 BH-M76 is a sports stereo bluetooth headset with music time about 4 hours with 50% Volume when fully charged when fully charged；easy to charge(using standard micro USB cable，5V charging voltage)，support bluetooth 4.1profile(HFP v1.6, A2DP v1.2, AVRCP v1.4)，and TTS voice prompt、dual language switch function and etc；two kinds of wearing style：with ear hook or directly in ear，rotating earplug angle to wear according to the...
-
Page 2: Led Indication
■ Headset button and interface description LED Indication Power ON: Blue LED flashes twice Power OFF: Red LED flashes one second Pairing mode: Blue and red LED flashes alternately Unconnected standby mode: Blue LED flashes twice every 5 seconds Connected standby mode: Blue LED flashes once every 10 seconds. Talking mode: Blue LED flashes once every 10 seconds. - Page 3 3 seconds to enter into pairing mode,blue A, I and red LED flashes alternately. Open the phone and turn on Bluetooth, search "BH-M76" Bluetooth device, click "BH-M76" to B， connect. After several seconds you will hear the successful pairing connection tone and LED turn to Blue with slowly flash, the phone will show successful connection with the "BH-M76".
- Page 4 ”multi-function button ”can’t make a phone call, please turn off your Bluetooth and turn on again on your mobile phone, and click on "BH-M76" pairing connection record, then play music or make a phone call after manual connection is successful.
- Page 5 automatic turn off. A call come in headphone will report the number prompt. D， Technical Parameters Bluetooth Version:: V4.1 Wire size: 45*14*12mm Battery Voltage: 3.7V Battery Capacity：90mAh Speaker Size: Φ8mm Headphone Power：5mW*2 THD≤10% Net weight: about 18g SNR: ≥90dB Charging Voltage: 5V Charging time：about 2hours Charging Curren: ≤80mA Standby time ：about 110 hours...
- Page 6 Note： changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
- Page 7 Notice: ● Do not allow children to play this product. ● Do not hit or beat the product. ● Do not forcibly on rotating horn head, in case of avoiding internal circuit is broken ● Please note waterproof, anti-high temperature, using in cold regions will lead to product’s performance degradation.
