INSTALLATION MANUAL
For crystalline solar photovoltaic modules
According with IEC61215 edition 2 & IEC61730 standards
1.
2.
3.
4.
Electrical mounting
..................................................................................
...........................................................................................
.............................................................................................
5.
................................................................................
........................................................................................
6.
....................................................................................
......................................................................
..........................................................................
..................................................................
.................................................................
.............................................................................
.................................
........................................................................
.....................................
.......................................................................
.............................................................................
.........................................
2
2
3
3
4
4
5
5
5
9
9
9
10
10
10
11
11
Installation manual for crystalline solar photovoltaic modules
EN
Advertisement
Table of Contents
Related Manuals for TALESUN TP672M-315
Summary of Contents for TALESUN TP672M-315
-
Page 1: Table Of Contents
INSTALLATION MANUAL For crystalline solar photovoltaic modules According with IEC61215 edition 2 & IEC61730 standards Introduction 1.1 Purpose of the manual ..............1.2 Disclaimer of liability ................1.3 Production identification ..............Safety guidelines 2.1 General safety guldelines ..............2.2 Product precaution ................ -
Page 2: Introduction
· Talesun assumes no liability for damage, loss, or expense arising out of or in any way connected with such installation, operation, use or maintenance. Talesun assumes no responsibility extending beyond the functional capability and safety of the modules. -
Page 3: Production Identification
· Keep children and unauthorized persons away from the modules. · In case of damaged modules or operational errors of the solar array, always contact your installer or Talesun Technical Customer Service. · Do not wear metallic ornaments or metallic devices while installing or troubleshooting photovoltaic systems. -
Page 4: Product Precaution
· Do not open the junction box under any circumstances. · Only carry out modifications to the modules that have been confirmed by Talesun in writing in advance. · Do not carry out any extra drilling (e.g. for fasteners) on the modules. -
Page 5: Mechanical Installation
3 MECHANICAL INSTALLATION 3.1 SELECTING THE LOCATION · The modules are certified according to the norm IEC 61215 and others for safe operation in moderate climates. · Do not expose the modules to chemicals. · Do not place the modules in standing water. The junction box is splash-proof only. ·... - Page 6 · For roof mounting applications the assembly is to be mounted over a fire resistant roof covering rated for the application. Talesun modules have been listed as Class C according to UL790 standard. · Any roof penetration required to mount the module must be properly sealed to prevent leaks.
- Page 7 Method B: Clamping installation · Modules can be installed with clamps. Modules must be securely attached to the mounting structure with four clamps on the short frame. · The modules must be properly secured to their support so that they can with stand live load condition, including wind up lift, to the pressure they have been certified for.
- Page 8 · Use four clamps on the short frame, and the clamping zone is from module edge to 1/4 width of the short frame. · Use a torque wrench for installation, and the compression for each clamps is not strong to avoid potential damages to module frames.
-
Page 9: Module Selection
WIND/SNOW LOAD · The modules have been designed to resist a static load of 5400 Pa (positive load). · When using a insertion system on a short frame without additional support-rail, the modules have been designed to resist a static load of 2400 Pa. ·... -
Page 10: Grounding
DANGER! Life danger due to electric shock! · Please do not attempt to correct problems on your own! · In case of problems or damaged modules (for example, glass breakage, damaged cables) please contact your installer or the Talesun Technical Customer Service. -
Page 11: Maintenance
However, rain may not adequately clear more stubborn grime (i.e. pollen, vegetation, bird droppings, etc.). Such soiling which shades the active area of the module can lead to a reduction in the system‘s performance. Talesun recommends the following maintenance in order to ensure optimum performance of the module: ·... - Page 12 Maximum Fuse Pmax Vmpp Impp Model System Rating Voltage (V) TP672M-315; 1000(IEC) 37.3 8.45 46.0 8.87 TP672M-310; TP672M-310B 1000(IEC) 36.9 8.40 45.8 8.83 TP672M-305; TP672M-305B 1000(IEC) 36.5 8.36 45.5 8.79 TP672M-300; TP672M-300B 1000(IEC) 36.1 8.32 45.2 8.75 TP672M-295; TP672M-295B 1000(IEC) 35.9...
- Page 13 Maximum Fuse Pmax Vmpp Impp Model System Rating Voltage (V) TP672P-315; 1000(IEC) 36.6 8.61 45.4 9.17 TP672P-310; 1000(IEC) 36.4 8.52 45.2 9.09 TP672P-305; 1000(IEC) 36.2 8.43 45.0 8.99 TP672P-300; TP672P-300B 1000(IEC) 36.0 8.33 44.8 8.90 TP672P-295; TP672P-295B 1000(IEC) 35.8 8.24 44.5 8.82 TP672P-290;...
- Page 14 Maximum Fuse Pmax Vmpp Impp Model System Rating Voltage (V) TP636P-150; TP636P-150B 1000(IEC) 18.0 8.33 22.7 8.78 TP636P-145; TP636P-145B 1000(IEC) 17.8 8.15 22.5 8.61 TP636P-140; TP636P-140B 1000(IEC) 17.7 7.91 22.4 8.43 TP636P-135; TP636P-135B 1000(IEC) 17.5 7.71 22.1 8.31 TP636P-130; TP636P-130B 1000(IEC) 17.4 7.47...
- Page 15 Web: www.talesun.com Switzerland Talesun Solar Switzerland AG c/o Muheim & Merz Bundesplatz 2 6300 Zug, Switzerland Singapore Talesun Solar (Singapore) Pte. Ltd. 50 Kallang Avenue #01-02 Singapore 339505 Hong kong Talesun Solar Hong Kong Limited 36/F, Tower Two, Times Square...
- Page 16 www.talesun-eu.com...
