Summary of Contents for Sonorix OBA-0110
-
Page 2: Table Of Contents
Description of Parts ..................................3 Charging the Audio Adapter................................. 4 Switching the Audio Adapter ON/OFF ............................4 Pairing Audio Adapter with SONORIX Headset........................... 4 Using Audio Adapter with Headset to Listen to Music........................5 Hints for Optimum Audio Transmission............................6 Useful Tips on Audio Adapter Application ............................ -
Page 3: Introduction
3.5mm stereo jack(headphone) of any audio devices or USB port of laptops or desktops without Bluetooth functionalities. We hope you enjoy the unique wireless features provided by SONORIX. (Multi-Function Button) Audio Connector What’s included in the Package... -
Page 4: Charging The Audio Adapter
To power off Audio Adapter, click and hold MFB for 3-4 seconds until LED flashes red rapidly and then release button. Pairing Audio Adapter with SONORIX Headset With Headset in pairing mode, mount battery onto Audio Adapter. Click and hold MFB for 3-4 seconds until LED flashes blue rapidly and continue holding the button for 4 more seconds and when LED flashes slow constantly release button. -
Page 5: Using Audio Adapter With Headset To Listen To Music
BLUETOOTH AUDIO ADAPTER Using Audio Adapter with Headset to Listen to Music Power on Headset and Audio Adapter to establish Bluetooth connection. Plug one end of Stereo or USB cable into Audio Adapter and the other To use Audio Adapter to stream audio from PC, plug one end of the mini end into Stereo or USB input of audio device. -
Page 6: Hints For Optimum Audio Transmission
BLUETOOTH AUDIO ADAPTER Hints for Optimum Audio Transmission Useful Tips on Audio Adapter Application The performance of wireless audio streaming depends on the environment 1) Audio Adapter can be connected to USB port or Audio Jack of audio where it is used. Walls, partitions, doors, furniture etc can block the path of devices and can be switched from one mode to another by pressing transmitted radio... -
Page 7: Led Indicator
BLUETOOTH AUDIO ADAPTER LED Indicator Specifications Audio Adapter LED Indicator Standards Bluetooth Specification V1.2 Bluetooth Link Established Continuous OFF RF Frequency Range 2402 ~ 2480 MHz Flashes Blue rapidly and then switches Pairing Mode Profiles Supported A2DP to slow Blue flash after 4 secs Transmission Power 0.25 ~ 2.5mW (Class 2) Flashes Blue rapidly and then switches... - Page 8 BLUETOOTH AUDIO ADAPTER Disclaimer Notice Product Warranty The manufacturer shall not be liable for errors contained herein or for incidental or Openbrain Technologies warrants this product against all defects in consequential damages in connection with the furnishing, performance or use of this material. material and workmanship for a period of one year from the date of This document contains proprietary information, which is protected by international patent purchase by end user.
- Page 9 www.SONORIX.com...
