- Page 1 SR-AX104 The SARAMONIC SR-AX104 is a 2-channel XLR audio adapter with preamplifiers and phantom power, ideal for any DSLR cameras with a built-in microphone jack. COPYRIGHT 2011-2021 SARAMONIC INTERNATIONAL A brand of DSQN Web: www.saramonic.com User Manual Email: info@saramonic.com...
-
Page 2: Product Introduction
The SR-AX104 makes your recording work much easier. Level meter allows you to verify the proper input levels in real time, the output signal can be adjusted by the level controls for optimum recording. -
Page 3: Product Structure
1.2 Product Structure XLR Inputs Level Meter Two balanced XLR inputs Indicates the sound level in dB for each channel Monitor In Gain Switches Monitor input jacks for connecting the AV cable Selects LOW for unity gain or HIGH for +20dB boost Battery Compartment Peak Switches Operates on one 9 volt battery (not included). - Page 4 Many microphones will operate on 12V to save battery power. LINE/MIC/PH Switches Select LINE or MIC or Phantom levels The MIC level is for self powered microphones or wireless system. The LINE level is for mixers and other audio devices with a line level output, set the switch to LINE to attenuates the signal to about 40dB.
- Page 5 1.3 Product Structure Maximum Input Levels MIC level: -3 dBu LINE level: +14 dBu Output Level Nominal MIC levels Frequency Response 20 Hz to 20 kHz (+/- 0.5 dB) Less than 0.01% @ 1kHz, -36dBu input S/N Ratio 85 dB @ 1 Khz, -30 dBu input Gain LO gain: 0 dB HI gain: 20 dB...
-
Page 6: Operation
Set the M/S switch. When using one channel, switch to M for mono. (2) Attach the SR-AX104 to the base of the camera. Spin counter-clockwise to tighten up the When using two channels, switch to S for stereo. adapter with the camera. Mount the adapter to a tripod with the tripod socket on the bottom of the adapter. -
Page 7: Warranty
By disabling AGC function, the hiss can be eliminated when (2) Saramonic International will repair or replace the product that under the warranty for free during the camera is recording during quite moments. -
Page 8: Packing List
(5) Wherever you purchased our products, you will be served very well at local retailer. (6) Saramonic International reserves all the rights for the ultimate interpretation. 4 Compatibility Professional XLR microphones, wireless systems, other audio devices such as mixing boards.
