NTT docomo hitoe Instruction Manual

Wearable body sensor smart clothing
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Thank you for purchasing hitoe Transmitter
Please read these instruction manuals before using the device and save them for further reference.
■Component
hitoe transmitter
Precautions for safe handling
●Please carefully read the 'Safety precautions' before use, and use the product properly.
We also recommend that you keep this manual handy for future reference.
●The safety precautions must be abided by without fail because they are for preventing harm
to the users, to other people, and damage on assets.
●The following categories explain the degrees of harm and damage in case the displayed
contents are not abided by and the product is used incorrectly.
DANGER
WARNING
CAUTION
■Below icons show instructions to follow.
The action is prohibited (i.e., the action must not be performed).
Disassembling is prohibited.
The product must not be wet while it is used.
The product must not be handled with wet hands.
The user is forced to perform the action (i.e., the action must be performed).
●This product contains following battery.
Displayed : Li-ion 00
hitoe transmitter
Instruction Manual
Incorrect handling will imminently risk the users' lives or inflict
severe injuries on the users'.
Incorrect handling could 'risk the users' lives or inflict severe injuries
on the users'.
Incorrect handling could 'inflict minor injuries and physical damage'.
Type of battery: Lithium-ion battery
Micro USB cable

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the hitoe and is the answer not in the manual?

Questions and answers

Summary of Contents for NTT docomo hitoe

  • Page 1 Instruction Manual Thank you for purchasing hitoe Transmitter Please read these instruction manuals before using the device and save them for further reference. ■Component hitoe transmitter Micro USB cable Precautions for safe handling ●Please carefully read the ‘Safety precautions’ before use, and use the product properly.
  • Page 2 Important safety instructions for hitoe transmitter and micro USB cable. DANGER DO NOT use, store or leave the product at places where temperatures become high (such as near fire or heating devices, inside a heating device, in direct sunlight, inside a car under a blazing sun).
  • Page 3 Important safety instructions for hitoe transmitter DANGER DO NOT put the device in a fire or attempt to heat it. It could cause ignition, explosion, generation of heat and leakage of liquid of the built- in battery. DO NOT inflict excessive forces such as driving in a nail, hitting with a hammer, stepping on it, etc.
  • Page 4 Make sure that pet animals do not bite on the product It could cause ignition, explosion, generation of heat and leakage of liquid of the built-in battery. In case anomalies such as generation of heat are experienced, stop using the product immediately and keep it away from body.
  • Page 5 Important safety instructions for micro USB cable WARNING DO NOT use damaged USB cable. It could cause fires, skin burns and electric shocks. DO NOT use the micro USB cable at places where humidity is high, such as in the bathroom.
  • Page 6 When inserting/removing the micro USB cable into/from the corresponding device, do so horizontally and by not inflicting excessive forces. It could cause fires, skin burns, injuries and electric shocks. When the corresponding device is not used for long hours, pull out the micro USB cable from the device.

  • Page 7: List Of Materials

    List of materials ■hitoe transmitter Location-of-use Materials/Surface processing External component External connection terminal Stainless/ Main body Cover for terminal for Fitting pin part Elastomer external connection Packing Silicon rubber Snap Button Brass/Copper tin plating Screw cap, Button, Label ■micro USB cable...

  • Page 8: Precautions For Use

    Precautions for use Common requests  The product is waterproofed, however, do not immerse inside the product in water, and do not sprinkle water over the attachments and optional items. The micro USB cable is not waterproofed.  Do not use the product at places where humidity is high, such as in the bathroom, and avoid rain.
  • Page 9 Requests on hitoe Transmitter  Avoid extremely high and low temperatures. Use the product in the temperature range of 0℃～40℃ and in the humidity range of 20％～80％.  Fixed-line phones, TVs and radios have a negative impact, therefore, the product must be used as far from those devices as possible.
  • Page 10 Requests in case Bluetooth ®functions are used  As for security during communications using Bluetooth, the product supports the security functions compliant with the Bluetooth standard specification. However, depending on the setting, security may not be sufficient. Therefore, caution must be exercised when communicating by using the Bluetooth functions.
  • Page 11 Caution The product has the IPX5※1 and IPX7※2waterproof performance when the cover of the terminal for external connection is tightly closed without openings or gaps. ※1.IPX5 means that functions are protected from water jets created with a water nozzle of the inside diameter of 6.3mm with 12.5L/min.
  • Page 12  Damaged or deformed packing of the cover for the terminal for external connection causes entering of liquid such as water inside the product.  In case liquid such as water is splashed when the cover for the terminal for external connection is open, the liquid enters inside the product and causes electric shocks or trouble.

  • Page 13: Fcc Caution

    FCC caution  Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.  This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

  • Page 14: Names Of Parts

    Names of parts 1 State display lamp 2 Button 3 Bluetooth antenna※ 4 Terminal for external connection 5 Name sticker 6 Snap button ※The antenna is built-in. Covering the area where the antenna is installed with hands could impact the quality.

  • Page 15: How To Use

     When you charge, remove this product form the hitoe wear. ※Even when charging is done with power turned on, the power will be turned off in approx.
  • Page 16 ※See the handling manual of smartphones for the operation of smartphones. 1. Turn the power of for the product. 2. Attach the product to the hitoe wear. •See the handling manual of the hitoe wear for how to attach the product to the hitoe wear. 3. Wear the hitoe wear.
  • Page 17 Trouble? Please take the following measures, and if the trouble still remains, please contact the ‘Trouble inquires’ Phenomenon Possible causes and how to fix them • Out of battery? →Recharge the battery. ※Out of battery in case the state display lamp is not lit even Cannot turn on power when the button is pressed.

  • Page 18: Main Specifications

    Trademark  ‘ hitoe’ is the trademark by Toray Industries, Inc. and Nippon Telegraph and Telephone Corporation.  The word-mark and logo of Bluetooth® are registered trademarks owned by Bluetooth SIG, Inc., and NTT DOCOMO, INC. use them based on the license.
