ResponseLink MDT-122 User Manual

MDT MDT MDT MDT- - - - 122 122 122 122
Man-Down Transmitter

1. INTRODUCTION

1. INTRODUCTION 1. INTRODUCTION 1. INTRODUCTION
MDT-122 is an automatic personal security transmitter. This
micro-processor controlled transmitter is designed for use by
guards in a prison, by security officers in an organization or
institution, or by employees in a large industrial complex (as an
industrial signaling device for safety). In areas that 1 person is
not allowed to work alone, MDT-122 can be an excellent solution.
The MDT-122 alarm signal can be received by a compatible
receiver, like MCR-308, and can be integrated in any alarm
system.
MDT-122 is attached to the guard's pouch / holster.
The transmitter is activated in the following events (see fig. 2):
A. PANIC
When the guard needs help, he presses both buttons
(pressing both buttons is required to prevent an accidental
panic message transmission).
B. MANDOWN
When the guard falls down (automatic transmission when the
unit is tilted down by more than 60
C. PULL-CORD
The pull-cord is attached strongly by a clip to the guard's belt
on one side and is plugged into the transmitter by an easily
detachable plastic pin on the other side. Pulling the cord or
the unit away causes the plastic pin to be detached and to
1
DE2295U
°
).
MCR-308 Optional
wireless alarm
receiver system
OUT
READY ARM
ND
BYPASS HOME
POWER AWAY
L. BAT
1 2 3
4 5 6
7 8 9
JAMM
2 CLR 0 ENT
2
MDT-122
Figure 1 - Integration of MDT-122 in an Alarm System
release an internal
transmission. This may happen when an attacker tries to
draw the unit away from the guard or by the holder, in case of
emergency and difficulty to press the twin buttons for alarm.
Pull
cord Temporary
TILT OFF
push-button
Tilt ON/OFF
Right
slide switch
push
button
Cover
screw
LED
Left
pushbutton
Figure 2 - External View
Optional
automatic
dialer
B C D PROGRAM
1 2 3 PROG
2 - CHANNEL
E F ALARM-1
AUTOMATIC
4 5 6 AL-1
SPEECH DIALER
A
ALARM-2
B
7 8 9 AL-2
C
A-F A STOP
D
0 #
* STOP
DIAL
Model: DL-
Siren
3
Response
User's Guide
switch that activates an
Vertical (normal)
Position
Figure 3 - Activating the
Internal Tilt Switch
Public
telephone
exchange
alarm
1
