Summary of Contents for Spot-on MB-360
- Page 1 M B - 3 6 0 M O T O R I S E D T R A C K I N G B A S E W I T H W I R E L E S S H Y B R I D D E T E C T O R I N S T R U C T I O N M A N U A L...
- Page 2 SAFETY Read the following safety instructions before qualified repair personnel. Repairs, service attempting to operate this product. or maintenance performed by unqualified Keep these instructions in a safe place or store personnel will void the warranty. Only in the carry case for future reference. approved and authorised service technicians can carry out warranty repairs.
-
Page 3: Item Checklist
Please ensure the following items are included with your instrument. If anything is missing please contact your retailer. AUTO SCAN Spot-on MB-360 Spot-on MB-RC1 Carry case motorised base detector 5/8 x 11” thread adaptor Alkaline batteries (MB-360) Alkaline batteries (MB-RC1) - Page 4 MOTORISED BASE OVERVIEW 5/8” x 11 thread Control panel Bubble vial Adjustable support legs Adjustable support legs Battery compartment...
- Page 5 MOTORISED BASE OVERVIEW: CONTROL PANEL LED power indicator Power...
- Page 6 DETECTOR OVERVIEW: FRONT LED direction indicator LED centre indicator Laser sensor LED direction indicator Speaker Bubble vial Side control panel Side control panel AUTO SCAN Control panel...
- Page 7 DETECTOR OVERVIEW: BACK LED direction indicator LED centre indicator LED direction indicator Staff clamp mounting point Staff clamp thread Side control panel Side control panel Battery compartment...
- Page 8 DETECTOR OVERVIEW: CONTROL PANELS LED automatic scan indicator LED speaker indicator Counter clockwise rotation AUTO Speaker SCAN Clockwise rotation Power LED power indicator Automatic scan mode...
- Page 9 USING YOUR MOTORISED BASE MOTORISED BASE DETECTOR POWER SUPPLY (MB-360) POWER SUPPLY (MB-RC1) ▪ The instrument is powered by four AAA ▪ The instrument is powered by four AAA alkaline batteries. alkaline batteries. BATTERY REPLACEMENT (MB-360) BATTERY REPLACEMENT (MB-RC1) ▪ Rotate the thumb screw counter clock- ▪...
- Page 10 OPERATION ▪ Use the bubble vial on the base to ensure The detector is compatible with most red that the base is level. Rotate the adjustable and green beam line lasers with a vertical support legs to level the base, if required. beam and pulse mode.
- Page 11 OPERATION (continued) Speaker ▪ The LED direction indicators will light up red when the beam is close to centre. The ▪ When the detector is powered on the LED centre indicator will light up green default speaker setting is set to ‘loud’. The when the beam is completely aligned.
-
Page 12: Care And Maintenance
CARE AND MAINTENANCE ▪ This instrument should always be handled ▪ Clean the instrument with a dry, soft with care and transported within the carry cloth after use in dusty, damp or wet case provided. conditions before storing. ▪ Always turn the instrument off before ▪... -
Page 13: Warranty
WARRANTY The Spot-on MB-360 comes with a 1 (one) year manufacturers warranty. AUSTRALIA NEW ZEALAND “Our goods come with guarantees that more information please visit cannot be excluded under the Australian consumerprotection.govt.nz Consumer Law. You are entitled to a replacement or refund for a major failure and for compensation for any other reasonably foreseeable loss or damage. -
Page 14: Customer Support
CUSTOMER SUPPORT To assist you with any queries or technical questions please contact customer support Australia: 1300 658 338 New Zealand: 0800 367 527... -
Page 15: Specifications
SPECIFICATIONS Specifications Spot-on MB-360 Product code 30030 Warranty 1 Year Operating distance (laser detection) Refer to the instruction manual of your laser level Wireless communication distance Thread size 5/8” x 11 Battery type (motorised base) 4x 1.5v AAA Weight (motorised base) (kg) 0.57... - Page 16 www.s p o to n. c o m .a u...
