  • Page 1 24774 00 - SN ES500DOa 02/04/2002 16:21 Page 1 Newhome ES500DOa 500mm wide Waist Level Electric Freestanding Cooker Double Oven & Grill with Solid Plate Hotplate (with fanned main oven) User & Installation Handbook...
  • Page 2 24774 00 - SN ES500DOa 02/04/2002 16:21 Page 2 SN ES500DOa...
  • Page 3: Table Of Contents

    Troubleshooting ........27 Stoves Customer Support ......28 Please keep this handbook for future reference, or for anyone else who may use the appliance.
  • Page 4: User's Section

    24774 00 - SN ES500DOa 02/04/2002 16:21 Page 4 Introduction Thank you for choosing this Electrical connection appliance Please refer to installation instructions We hope the following information for electrical connection. will help you to quickly familiarise In your own interest, and that of safety, yourself with the features of the make sure that the installation is carried appliance, and to use it successfully...
  • Page 5 24774 00 - SN ES500DOa 02/04/2002 16:21 Page 5 Introduction Environmental Protection Stoves Limited is committed to protecting the environment and operates an Environmental Management System which complies with BS EN ISO 14001:1996. Disposal of packaging • All our packaging materials are recyclable and environmentally friendly.
  • Page 6: Be Safe - Not Sorry

    24774 00 - SN ES500DOa 02/04/2002 16:21 Page 6 Be Safe - Not Sorry When you are cooking, keep Never use the appliance for children away from the vicinity heating a room. of the appliance. Do not drape tea towels over the This product is designed as a domestic flue vents or doors, as this creates cooking appliance for the preparation...
  • Page 7: Using The Hob

    24774 00 - SN ES500DOa 02/04/2002 16:21 Page 7 Using the Hob Before using the hob for the first time, Pans it should be primed and seasoned - When cooking with fat or oil, never refer to the instructions in the leave unattended.
  • Page 8: Using The Grill

    24774 00 - SN ES500DOa 02/04/2002 16:21 Page 8 Using the Grill Caution: Accessible parts may Detachable grill pan handle be hot when grill is used, young Warning; Always use an oven glove children should be kept away. to protect your hand when using the grill as all metal parts can become very hot.
  • Page 9 24774 00 - SN ES500DOa 02/04/2002 16:21 Page 9 Using the Grill Grilling Warming plates and dishes in the grill compartment It is recommended that the high temperature setting is used for toasting Ovenproof plates and dishes may be and for cooking foods such as bacon, warmed in the grill compartment when sausages or steaks.
  • Page 10: Using The Top Oven

    24774 00 - SN ES500DOa 02/04/2002 16:21 Page 10 Using the Top Oven Accessible parts may be hot Preheating when the oven is used. Young The oven must be preheated when children should be kept away. cooking frozen or chilled foods, and Important: Never put items directly we recommend preheating for yeast on the base of the oven, or cover the...
  • Page 11: Top Oven Baking Guide

    24774 00 - SN ES500DOa 02/04/2002 16:21 Page 11 Using the Top Oven Top oven baking guide Cooking temperatures The temperature settings and time given in the baking guides are based Cooking times on dishes made with block margarine. These times are based on cooking in a If soft tub margarine is used, it may be preheated oven.
  • Page 12: Using The Main Oven

    24774 00 - SN ES500DOa 02/04/2002 16:21 Page 12 Using the Main Oven Accessible parts may be hot Oven shelves when the oven is used. Young There are 6 shelf positions in the main children should be kept away. oven, counted from the bottom upwards. Position baking trays and roasting tins To switch on the oven on the middle of the shelves, and leave...
  • Page 13: Cooking With A Fanned Oven

    24774 00 - SN ES500DOa 02/04/2002 16:21 Page 13 Using the Main Oven Cooking with a fanned oven Notes: If you are used to cooking with a When 2 or more shelves are being conventional oven you will find a used, it may be necessary to increase number of differences to cooking with the cooking time slightly.
  • Page 14: Slow Cooking

    24774 00 - SN ES500DOa 02/04/2002 16:21 Page 14 Using the Main Oven Slow cooking Make sure that frozen foods are thoroughly before cooking. THAWED Do not slow cook joints of meat or poultry weighing more than 2 ⁄ ⁄ For roasting joints of meat or poultry, and for pot roasts preheat the oven to 190˚C and cook for 30...
  • Page 15: Main Oven Baking Guide

    24774 00 - SN ES500DOa 02/04/2002 16:21 Page 15 Using the Main Oven Main oven baking guide Item Temperature Shelf Approximate ˚C position cooking time Casseroles 140 - 150˚C 1 - 2 ⁄ - 2 hrs, depends on quantity Fruit cake 130 - 140˚C 2 - 3 Time depends on size...
  • Page 16: Traditional Fruit Cakes

    24774 00 - SN ES500DOa 02/04/2002 16:21 Page 16 Using the Ovens Traditional fruit cakes Roast turkey It should be remembered that ovens Roasting turkey involves cooking two can vary over time, therefore cooking different types of meat - the delicate times can vary, making it difficult to be light breast meat, which must not be precise when baking fruit cakes.
  • Page 17: Roasting Guide

    24774 00 - SN ES500DOa 02/04/2002 16:21 Page 17 Using the Ovens Roasting guide Notes: The times given in the roasting guide When cooking stuffed meat or are only approximate, because the poultry calculate the cooking time size and age of the bird will influence from the total weight of the meat cooking times as will the shape of a plus the stuffing.
  • Page 18: Automatic Cooking

    24774 00 - SN ES500DOa 02/04/2002 16:21 Page 18 Using the Main Oven Automatic cooking Do not The automatic cooking facility is • Warm food should never be controlled by the programmer (see placed in the oven if there is a ‘Programmer / Clock’...
  • Page 19 24774 00 - SN ES500DOa 02/04/2002 16:21 Page 19 Using the Main Oven Important: Hints for automatic cooking Food is more susceptible to the growth • Food is placed in a cold oven so of food poisoning organisms in warm you will need to add about 10 - 15 conditions.
  • Page 20: Programmer / Clock (If Fitted)

    24774 00 - SN ES500DOa 02/04/2002 16:21 Page 20 Programmer / Clock (if fitted) The Programmer Buttons Manual operation minute minder cook time ready time minus plus To set the programmer to manual To set the “Time of Day” operation at any time (cancelling any automatic setting), press the cook time and ready time buttons simultaneously.
  • Page 21 24774 00 - SN ES500DOa 02/04/2002 16:21 Page 21 Programmer / Clock (if fitted) Semi-automatic cooking (example) 1. A (Auto) symbol appears. You have started cooking a meal or dish in the oven, and want to set the time for the oven to switch off. Press the cook time button, then use the plus and minus buttons to set the display to show the length of cooking...
  • Page 22 24774 00 - SN ES500DOa 02/04/2002 16:21 Page 22 Programmer / Clock (if fitted) Fully automatic cooking (example) 5. A (Auto) symbol appears. For use when a delayed start time is required. You want to set the length of cooking time, and the time for the oven to switch off.
  • Page 23 24774 00 - SN ES500DOa 02/04/2002 16:21 Page 23 Programmer / Clock (if fitted) The oven will automatically switch off 9. A (Auto) symbol will flash. at 18.00 hours (6.00 pm) and the alarm will sound (9). To switch off the alarm press the minute minder button (10).
  • Page 24: Cleaning

    24774 00 - SN ES500DOa 02/04/2002 16:21 Page 24 Cleaning Caution: Any cleaning agent Vitreous Enamel parts used incorrectly may damage & GRILL PAN OVEN GRILL CAVITY INTERIORS the appliance. HOB TOP Always let the appliance cool Use a mild cream cleaner- eg; ”Cif”. before cleaning.
  • Page 25 24774 00 - SN ES500DOa 02/04/2002 16:21 Page 25 Cleaning Solid plate elements oil to the hotplate surface. Wipe off any excess oil, then heat the hotplate Cleaning: on a medium setting for 1 minute. Important: Ensure that elements are Occasional seasoning will help to switched off and cool before cleaning.
  • Page 26: Installation Instructions

    24774 00 - SN ES500DOa 02/04/2002 16:21 Page 26 Installation Instructions This is a type X appliance regarding Clearances installation requirements. This cooker may be fitted flush to Important: Ensure that you route base units. However, for models with all mains cables well clear of any side opening doors, we recommend a adjacent heat source.
  • Page 27: Connect To Electrical Supply

    24774 00 - SN ES500DOa 02/04/2002 16:21 Page 27 Installation Instructions Levelling This appliance conforms to EN55014 regarding suppression of radio and The appliance must not be installed on television interference. a raised base. The appliance should be located on a level surface.
  • Page 28: Technical Data

    24774 00 - SN ES500DOa 02/04/2002 16:21 Page 28 Technical Data Data badge Electrical ratings On the bottom of the front frame * High speed hotplate elements are behind the oven door. indicated by a central red spot. Electrical supply Element 220 - 240V ~ 50Hz Main fanned oven...
  • Page 29: Troubleshooting

    24774 00 - SN ES500DOa 02/04/2002 16:21 Page 29 Troubleshooting Before contacting Stoves Customer Oven does not work Support, please check the guide Check that the Automatic Programmer below - there may be nothing wrong is set for manual operation.
  • Page 30: Stoves Customer Support

    10am - 4pm Enter appliance numbers here for future reference: Model No Serial No Please ensure you have the above details (Model No and Serial No) to hand when calling Stoves Customer Support. They are essential to booking your call.
  • Page 31 24774 00 - SN ES500DOa 02/04/2002 16:21 Page 31...
  • Page 32 24774 00 - SN ES500DOa 02/04/2002 16:21 Page 32 STOVES LIMITED STONEY LANE, PRESCOT, MERSEYSIDE, L35 2XW 08 24774 00 © 2002...
