User Manual
Preface
All Rights Reserved - Printed in China
Netbook Computer User Guide
This manual guides you in setting up and using your new notebook computer.
Information in this manual has been carefully checked for accuracy and is subject
to change without notice.
No part of this manual may be reproduced, stored in a retrieval system, or
transmitted, in any form or by any means, electronic, mechanical, photocopy,
recording, or otherwise, without prior written permission.
Please read this manual carefully before using the computer.
The following signs call attention to features and operations that may be
dangerous to the user. Follow the instruction closely to reduce the risk of physical
harm or damage to the equipment.
Danger: Not following the instruction will result in immediate death or serious
injury.
Warning: Not following the instruction could result in death or serious injury.
Caution: Not following the instruction could result in minor or moderate injury
and/or damage to the product.
Trademarks
Product names used herein are for identification purposes only and may be the
trademarks of their respective companies.
Microsoft, Windows XP, Windows MCE, Windows Vista, Windows 7 and Windows
Sound System are trademarks of Microsoft Corporation.
Intel Atom D425 GMA3150.
All other brands or product names mentioned in this manual are trademarks or
registered trademarks of their respective companies.
1
Advertisement
Table of Contents
Summary of Contents for StarWorth SWNTS30I
-
Page 1: Preface
User Manual Preface All Rights Reserved - Printed in China Netbook Computer User Guide This manual guides you in setting up and using your new notebook computer. Information in this manual has been carefully checked for accuracy and is subject to change without notice. -
Page 2: Table Of Contents
User Manual Table of Contents Preface…………………………………………………………………………………1 1. Important Safety Instructions 1.1 Selecting a place to work …………………………..………………………….3 1.2 Notice of the Battery Pack Maintenance……………..……………………..3 1.3 Notice of the AC Adapter Maintenance………………..…………………..4 1.4 Computer Maintenance………………………………..…………………..5 1.5 Carrying Computer in Travelling……………………………………………..7 1.6 HDD Maintenance………………………………………………………………..7 1.7 Notice of Using the Computer…………………………..…………..……..8 2. -
Page 3: Important Safety Instructions
User Manual 1. Important Safety Instructions Please read this manual carefully before using the computer. These safety instructions will ensure many years of safe enjoyment from the product. Set up your computer on a flat, stable surface. (We are not responsible for the problems and damages caused by incorrect use of the computer in an unsafe environment.) 1.1 Selecting a place to work... -
Page 4: Notice Of The Ac Adapter Maintenance
User Manual Keep the battery pack away from heat. There is a risk of explosion or fire. Do not short-circuit battery terminals. There is a risk of explosion. Do not subject the battery pack to temperatures above 140 degrees F (60 degrees C). -
Page 5: Computer Maintenance
User Manual Supplying improper levels of voltage/current may result in electric shock, fire, and/or damage to the computer. If you hear a noise from the power cord or outlet, unplug the power cord immediately, and contact the customer service for help. There is a risk of fire or electric shock. - Page 6 User Manual If you drop your computer, remove the power cord and battery pack, and then contact the customer service for check up. There is a risk of electric shock or fire. Do not place a burning candle or cigarette on the computer. There is a risk of fire.
-
Page 7: Carrying Computer In Travelling
User Manual Keep the computer away from heat. The computer may deform and there is the risk of fire. When attaching an external device, make sure the connector from the device and the port on the computer are of the same type. There is a risk of damage to the computer. -
Page 8: Notice Of Using The Computer
User Manual 3. Exposure to virus. 4. The computer is turned off during operation. 5. Exposure to a physical shock while the hard disk drive is operating. Warning To prevent data lose due to hard disk drive damages, always backup your data. -
Page 9: Overview
User Manual 2. Overviews This chapter describes the component and structure of netbook PC as well as the functions of various ports. 2.1 Package contents The following items are included in the package. Match the items on this list with the items in the box. -
Page 10: Front View
User Manual Learning the components and their functions helps you to use the computer more easily and thoroughly. 2.2 Front view 1. Camera 2. LCD screen 3. Keyboard 4. Touchpad... - Page 11 User Manual 5. Click button 6. LED Status Indicator 7. Palm Rest 1. Microphone Jack 2. Headphone Jack 3. Card reader (Compatible with SD/MiniSD/MMC/RSMMC/MS/MS pro/MS Duo)
-
Page 12: Rear View
User Manual 2.3 Rear View 1. Lithium Battery Pack 2.4 Right View 1. USB 2.0 Port 2. USB 2.0 Port 3. RJ-45 Jack for LAN 4. External D-Sub VGA outpu 5. DC-IN Jack... -
Page 13: Left View
User Manual 2.5 Left View 1. Power Button 2. Thermal Vent 3. Kensington Security Lock 2.6 Bottom View 1. Lithium Battery Pack 2. Thermal Vent 3. HDD Cover 4. Battery Latch 5. RAM Cover... -
Page 14: Led Status Indicators
User Manual 2.7 LED Status Indicators 1. Power: Power status indicator indicates the following status of the computer. Green: The system is powered on. Off: The computer is turned off or is in hibernation mode. Blinking: The computer is in standby mode. 2. -
Page 15: Basic Operations
User Manual 3. Basic Operations This section describes how to use the basic features of your computer. Read this section before using the computer. 3.1 Using the battery pack The battery pack must be fully charged before first use. Caution: You must turn off the computer before changing the battery pack. -
Page 16: Using The Ac Adapter
User Manual To use the battery pack safely and effectively, 1. Do not short-circuit the battery pack. 2. Keep the battery pack away from heat or fire. 3. Store the battery pack at room temperature. (32 ~140 °F/0 ~ 60 °C) 4. - Page 17 User Manual Turning off the computer Quit all running applications; click [Start] and choose [Shut Down] from the start up menu. In the Turn off computer window, choose [Turn off]. The computer is turned off automatically. Caution: If the HDD indicator is on, do not turn off the computer, as doing so may damage...
-
Page 18: Using The Keyboard
User Manual the data being read from or written to the drive. Warning If Windows does not shut down correctly, press and hold the power switch for more than 5 seconds; the system will shut down. Turning off the computer this way may damage the system. -
Page 19: Cursor Control Keys
User Manual Ⅱ.Cursor control keys: You can move the cursor in the direction of the arrows. Editing keys: You can move the cursor to the beginning or end of the current line, or up and down the screen. Ⅲ.Embedded numeric keypad: The embedded numeric keypad functions like a desktop numeric key pad. - Page 20 User Manual Shift key: Hold Shift key down and press another key to enter the upper case letter for the key. Alt Gr：Hold Alt Gr key down and press another key to enter the bottom right case letter for the key（Please note that it must be used in Spanish Language OS only）.
-
Page 21: Using The Touchpad
User Manual Ⅴ.Hot keys: The following Hot keys provide you with shortcuts to operations, such as adjusting the brightness of the computer display. Fn+Esc: Force the computer to enter power-saving mode. (Ex: system standby and hibernation) Fn+F1: Enable/disable the wireless network Fn+F3: Enable/disable the audio output. - Page 22 User Manual Do not remove the cover sheet of the touch pad as doing so may damage the touch pad. Do not use the touch pad with two fingers, wearing gloves, or wet hand as it may not function correctly. Using the touch pad with a dirty or oily finger may damage the touch pad.
- Page 23 User Manual also tap the touch pad twice to get the same result. To launch an application, you can select and double-click the .exe file or the program icon. Drag and drop: To drag an object, select and move the object by clicking and holding the left button and sliding the finger across the touch pad without releasing the button.
-
Page 24: Setting Up The System
User Manual Drag: Move the icon without releasing the left button Drop: Release the left button above the recycle bin. 4. Setting Up the System The system setup saves your computer’s hardware configurations in CMOS RAM. The system setup provides you with information, such as the size and type of your hard disk, size of the installed memory, date, and time. -
Page 25: Setting A Supervisor Password
User Manual 4.3 Setting a supervisor password If you want to protect the system setup from an unauthorized user, follow the instructions below to set a password. You can set a password in the BIOS Setup Utility program. Caution: If you forget the password, you cannot gain access to your system. Make sure you write down the password in a safe place only you can refer to in case you forget the password. - Page 26 User Manual Note: You can use a supervisor password to gain access and change items in the BIOS Setup Utility, and select Power on Boot. We recommend using a user password if someone else has to use the computer. If the following message appears, enter a new password and press Enter. A password must be consisted of character A~Z and numbers 0~9, and have the maximum length of 8.
-
Page 27: Setting A User Password
User Manual If the following message appears, select Yes and press Enter to restart the computer. 4.4 Setting a user password A user password is a secondary compared to a supervisor password. You must set a supervisor password in order to set a power-on password. Start the BIOS Setup Utility and use arrow keys to select Security menu. -
Page 28: Changing Or Removing A Password
User Manual Confirm New Password Press F10 to save the new settings. If the following message appears, select Yes and press Enter to restart the computer. 4.5 Changing or removing the password You must know the password to change or remove it. Start the BIOS Setup Utility, enter your password, and then press Enter. -
Page 29: Recovering The Factory Default Settings
User Manual Press F10 to save the new settings. If the following message appears, select Yes and press Enter to restart the computer. 4.6 Recovering the factory default settings If a user accidentally modifies the system setup, follow the instruction below to recover the factory default settings. -
Page 30: Specifications
User Manual If the following message appears, select Yes and press Enter to recover the factory default settings. Press F10 to save the new settings. If the following message appears, select Yes and press Enter to restart the computer. 5.Specifications CPU: Intel Atom D425 1.8GHz Chipset: Intel GMA3150+ Intel ICH7-M Screen: LED Screen 10.1inch TFT... -
Page 31: Operating Environment
User Manual External I/O Interfaces: External monitor connector Microphone jack Speaker/Headphone jack 2 Universal Serial Bus (USB) connectors RJ45 Ethernet connector Cardreader: SD/MMC/MS Keyboard: 83 key with 19mm key pitch and 2.5mm key stroke Touch Pad: Integrated Touchpad, Left key, Right Key Dimension: 250mm(L) x 185mm(W) x (26mm ~ 32mm)(H) Weight : About 1.3kg (including 6 cell Li-Ion battery pack) Battery: 6cell 4400mAh Battery life≥2Hour...
