Koma Elektronik Field Kit Manual

Hide thumbs Also See for Field Kit:

Need help?

Do you have a question about the Field Kit and is the answer not in the manual?

Page 1 FieldKit DIY Manual Otto Mikkonen Author: Last updated: 11.04.2017...
Page 2 Required Materials - 1 x FieldKit PCB - 1 x FieldKit Front Panel - 1 x FieldKit Wooden Enclosure (Bottom + Lid) - 4 x Small Bottom Pad - 4 x M2.5 woodscrew - 1 x Horizontal DC Jack - 1 x Vertical DC Jack - 17 x Vertical Minijack - 17 x Beauty Nuts - 18 x Minipot...
Page 3 Build 1) Hardware Introduction: Follow the silkscreen to determine where each part goes. Each part only fits one footprint so it's usually only possible to place a part to it's correct place. The only time where you have to pay some attention is when placing the switches (DPDT and SP3T have the same footprint).
Page 4 2) Snap off the extra length off the legs Finally we are going to put a jumper over the power selectors pins to have the Field Kit powered from the PSU (other option would have been the EuroRack power). Place the 1x2-...
Page 5 2) Mounting the PCB Next we are going to do the little things needed to have the Field Kit sitting in it's wooden enclosure. Take out the front panel if you still have it on from the previous phase. Place the fully fabricated circuit board inside the bottom part of the wooden enclosure.
