Project Name:
Bluetooth AP
User Manual of Bluetooth Access Point
Approved by:
Department :
Mobile Communication S/W Department,
CPE R&D Division
Document No.
Date Issued:
Product User's Guide
Neil Liu
CPE-U1-1210S-USR02-011N
Revision:
08-30-2002
Prepared by:
0.1
Jill Cheng

Advertisement

loading
Need help?

Need help?

Do you have a question about the BT3021 and is the answer not in the manual?

Questions and answers

Related Manuals for TECOM BT3021

Summary of Contents for TECOM BT3021

  • Page 1 Project Name: Document No. Bluetooth AP CPE-U1-1210S-USR02-011N Date Issued: Revision: 08-30-2002 User Manual of Bluetooth Access Point Product User’s Guide Approved by: Prepared by: Neil Liu Jill Cheng Department : Mobile Communication S/W Department, CPE R&D Division...

  • Page 2: Product Overview

    TECOM CO., LTD. TECOM Bluetooth Access Point PROJECT Prepared by: CPE-U1 Internal Document 1. INTRODUCTION 1.1. The Bluetooth Technology Bluetooth is a worldwide standard for the wireless exchange of data between two compatible devices. It utilities short-distance radio link technology and replaces the...
  • Page 3 TECOM CO., LTD. TECOM Bluetooth Access Point PROJECT Prepared by: CPE-U1 Internal Document 2.3. Bluetooth Clients supported Point-to-multipoint with 1.1 clients supporting: LAN Access Profile (LAP) WEBSITE UPDATES FOR COMPATIBILITY MATRIX??? 2.4. Configuration and Management Local connection, over Bluetooth or Ethernet LAN...
  • Page 4 TECOM CO., LTD. TECOM Bluetooth Access Point PROJECT Prepared by: CPE-U1 Internal Document If you do not have a DHCP-enabled network, or you would like to manually set up your Access Point’s network configurations eg. its static IP address, then you can use the Web Interface’s various advanced configuration pages such as Network, Bluetooth...
  • Page 5 TECOM CO., LTD. TECOM Bluetooth Access Point PROJECT Prepared by: CPE-U1 Internal Document If your PC is in the same network with the Access Point, running the setup-free Locator utility will automatically scan the network and identify your Access Point. It will display the IP address.
  • Page 6 TECOM CO., LTD. TECOM Bluetooth Access Point PROJECT Prepared by: CPE-U1 Internal Document Network Settings: Access Point Internet Settings (IP Address, Subnet Mask, Gateway and DNS entries). Figure 3 Information page on the Web Interface Devices page displays information about the Bluetooth clients currently connected to the Access Point.
  • Page 7 TECOM CO., LTD. TECOM Bluetooth Access Point PROJECT Prepared by: CPE-U1 Internal Document Figure 4 Devices page on the Web Interface 3.1.3. Network This is an advanced setup page for the Network settings of Bluetooth Access Point. Here you can set the Bluetooth name for your Access Point. The factory default name is Bluetooth AP.
  • Page 8 TECOM CO., LTD. TECOM Bluetooth Access Point PROJECT Prepared by: CPE-U1 Internal Document Figure 5 Network page on the Web Interface 3.1.4. Advanced Setup without DHCP When Bluetooth Access Point is powered up, it automatically looks for a DHCP server in the network to get an IP address for itself so that the Access Point is ready to use without user intervention.
  • Page 9 TECOM CO., LTD. TECOM Bluetooth Access Point PROJECT Prepared by: CPE-U1 Internal Document Figure 6 Configuring the IP Address through Locator Alternatively, you can use the Web Interface to manually set the IP address of the Access Point: 1. Connect your PC to Bluetooth Access Point through a cross-over CAT5 Ethernet cable (or through a hub using normal Ethernet cables) 2.
  • Page 10 TECOM CO., LTD. TECOM Bluetooth Access Point PROJECT Prepared by: CPE-U1 Internal Document You can leave the IP Addresses for Bluetooth clients Automatic even if the IP Address of Bluetooth Access Point is set manually. You may, however, decide to set them manually specifying a starting static IP Address in the same subnet of your Access Point’s IP Address.
  • Page 11 TECOM CO., LTD. TECOM Bluetooth Access Point PROJECT Prepared by: CPE-U1 Internal Document Figure 7 Bluetooth page on the Web Interface 3.1.6. Utilities You can set a new Web Interface password in this page. The default password is admin. You can also restore the Access Point to its factory default settings.

  • Page 12: Technical Specifications

    TECOM CO., LTD. TECOM Bluetooth Access Point PROJECT Prepared by: CPE-U1 Internal Document Figure 9 Configure on Locator 3. Upgrade 4. Web The basic Web Interface let user can monitor and configure Access Point and all of Bluetooth device information in anywhere.

  • Page 13: Troubleshooting Guide

    TECOM CO., LTD. TECOM Bluetooth Access Point PROJECT Prepared by: CPE-U1 Internal Document Compliance: • Bluetooth Core Specification 1.1 Qualified Bluetooth Security • Security Mode 1 (non-secure) • Security Mode 2 (service level enforced security) • Security Mode 3 (link level enforced security) •...
  • Page 14 TECOM CO., LTD. TECOM Bluetooth Access Point PROJECT Prepared by: CPE-U1 Internal Document I cannot access the Internet First, make sure that your Bluetooth client is connected to the Access Point. You should be able to successfully "ping" the Access Point (from a shell or command prompt) at its IP address.
  • Page 15 TECOM CO., LTD. TECOM Bluetooth Access Point PROJECT Prepared by: CPE-U1 Internal Document The LAN Link/Activity LED does not light Make sure the RJ45 cable connection at the side of the Access Point is secure and that the connection to the wall or device (e.g. a hub) is secure, as well. If the LAN Link LED...
  • Page 16 TECOM CO., LTD. TECOM Bluetooth Access Point PROJECT Prepared by: CPE-U1 Internal Document Finally, make sure that the password has not been changed. If you think that the password may have been changed and/or lost, you can restore the Access Point to the factory defaults.

  • Page 17: Fcc Information

    TECOM CO., LTD. TECOM Bluetooth Access Point PROJECT Prepared by: CPE-U1 Internal Document Notice : The changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. IMPORTANT NOTE: The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter.
