Page 1: User Manual
IR Intelligent Speed Dome Camera User Manual... - Page 2 IR Intelligent Speed Dome Camera User Manual Thank you for buying our company product, any question or request please feel free to contact The manual only use for our speed dome camera. This manual maybe includes some inaccurate information on technology/product function/ operation or print error, we will update it in the new versions manual in future.
-
Page 3: Table Of Contents
IR Intelligent Speed Dome Camera User Manual CONTENTS User Instructions .......................... - 3 - 1. Product Feature........................- 4 - 2. Main Technical Parameters ...................... - 5 - 3. Cable Definition........................- 6 - 4. Address, Protocol, Baud Rate Setting..................- 6 - 4.1 Dome Address Setup ...................... -
Page 4: User Instructions
IR Intelligent Speed Dome Camera User Manual User Instructions Thank you for purchasing and using our company’s products. According to our introduction of guarantee, Within the specified warranty period, our company will free to repair or replace parts that are damaged under normal use.User don’t disassemble repair itself without Our Consent. -
Page 5: Product Feature
IR Intelligent Speed Dome Camera User Manual 1. Product Feature 1) 7"elegant appearance, housing rotates follow the camera lens, IR light will not reflect by the cover. You needn’t open the PTZ housing to set the Add Code & Baud Rate, more convenient. 2) Drove by bearing and belt, more stable and smooth, long life performance. -
Page 6: Main Technical Parameters
IR Intelligent Speed Dome Camera User Manual 2. Main Technical Parameters 1) Electricity Power supply; DC12V--（4A) PTZ drive;DC12V--/0.5A IR light power supply;DC12V--（1.8A） lens Drive;DC12V/200mA Camera power supply;DC12V/500mA Retrofitting Temperature controlling device Working temperature;-20℃-+65℃ Address range;0～255 Communication mode;RS485 Protocol;Pelco-D, Pelco-P Baud rate;2400bps、4800bps、9600bps Adjustable Controlling Equipment: Video Matrix、industrial control DVR、DVR、controlling keyboard etc. -
Page 7: Cable Definition
IR Intelligent Speed Dome Camera User Manual 3. Cable Definition Signal, power supply cable connection, please reference following chart: 4. Address, Protocol, Baud Rate Setting The IR dome camera is built-in decoder board, through decoder to set the address, protocol, baud rate settings,realized PTZ and camera lens control of dome camera. -
Page 8: Baud Rate Setting
IR Intelligent Speed Dome Camera User Manual range of 1~255. Every camera’s dome address should be same as the DVR or keyboard’s. Dip switch use binary, dial every number to be "ON" is means as 1, dial to be "OFF" is means as 0, details please reference the sheet. -
Page 9: Function Setting
IR Intelligent Speed Dome Camera User Manual 5. Function Setting 5.1 Setup / Calling For Preset. Preset function refers to through controlling equipment setting / call IR dome position parameters of the horizontal Angle and vertical Angle, by storing in digital form to the IR dome, when needs to call these parameters, adjust the IR dome to preset a set state. -
Page 10: Limit Positions On Left And Right(A To B) 、 360 Degree Scan、 Setting And Remove The Setup Of Scanning Speed
IR Intelligent Speed Dome Camera User Manual （2）Stay time setting for preset position when auto cruising It can set stay time for preset position as 4 /8 /10 /15 /20 Seconds when the IR dome camera auto cruising. Operation method by controlling keyboard, DVR to implement the command “set No.75 preset position”... -
Page 11: Factory Default
IR Intelligent Speed Dome Camera User Manual c、Press “SHOT” key; d、Press “ACK” key; e、The dome camera will be moved to the left limit required by the position by shaking joystick. f、Enter“92” g、Press “SHOT” key; h、Press “ACK” key; （2）Start A、B scan By controlling keyboard or DVR to implement the command “set No.93 preset position”（If you not set the left/ right limit position, it will prompt to set the left/ right limit position）... -
Page 12: System Osd Menu Setup(For Models With Osd Menu)
IR Intelligent Speed Dome Camera User Manual 6.System OSD menu setup(for models with OSD menu) Main Menu System Information 、 System Setup、 Function Setup、 Display Setup 、Camera Menu Setup 、Factory Default、Exit Function Setup System System Setup Camera Display Setup preset setup Information motion flip:on Syetem time display:off... -
Page 13: Syetem Information
IR Intelligent Speed Dome Camera User Manual 3.function setup 4.display setup 5.camera menu setup 6.factory default 7.exit keyboard button function explanation: [RIGHT]pan right;Enter to sub menu or a setup [LEFT]pan left;Return to previous menu or exit a setup [UP]tilt up;During menu setup, move menu option up or modify parameter [DOWN]tilt down;During menu setup, move menu option down or modify parameter 6.3 Syetem Information Users can check the speed dome information by menu, the information include: speed dome... -
Page 14: Preset Func
IR Intelligent Speed Dome Camera User Manual Special Function 1.Preset func 2.Idle func 3Patrol func 4Timer Task 5Trace func 6Return 6.5.1 Preset Func Through Preset func , you can perform on the PTZ camera preset setting,single clearance and all preset clearance ,it’s convenient to call and add cruise group. Preset function 1.Preset No.: 01 2. -
Page 15: Timer Task
IR Intelligent Speed Dome Camera User Manual 6.5.4 Timer Task Through the Timer Task ,you can set the PTZ camera in set of execution of the set period of action. Timer Task 1.Task to run:off 2.set task 3.clear task 4.return 6.5.5 Trace Func Through the Trace func,you can track record,running,remove the PTZ camera,trajectory support 8,each support 3 minutes of recording.It will record the user’s operation in the process of... -
Page 16: Restore The Factory Value
IR Intelligent Speed Dome Camera User Manual 6.8 Restore The Factory Value Chose 《Restore the factory value》 , you can drop all of the PTZ camera’s parameter ,such as 6.9 EXIT Chose <exit> to exit the PTZ menu - 15 -... -
Page 17: Ptz Dome Camera Instruction List
IR Intelligent Speed Dome Camera User Manual 7.PTZ dome camera instruction list Function Mode Of Operation The first cruise line（1-16 presets） call 71 The second cruise line（17-32 presets） call72 The third cruise line（33-48 presets） call73 The fourth cruise line（240-255 presets） call74 A cruise preset for 4 seconds call75... -
Page 18: Notice
IR Intelligent Speed Dome Camera User Manual 8. Notice 1.The power supply of this product should be DC12V-14V, please use matched power from our company to supply; 2.Forbid turning around by outside force whether power on or off 3.Dial switch is on the bottom of the ball cover. Open buckle, you can adjust the address code and baud rate. -
Page 19: After-Sales Service
IR Intelligent Speed Dome Camera User Manual After-Sales Service Dear user, in order to get the high quality service for the speed dome camera, please read the below service charters. 1. We can offer the service of limited warranty and life-long maintenance (1)In the limited warranty (within 24 month from getting the camera), you can enjoy the maintenance free service. -
Page 20: Appendix
IR Intelligent Speed Dome Camera User Manual Appendix Appendix I: Lightning and Surge Protection This product is adopted the protection circuit which is composed of the gas discharge tube and TVS diode. It can effectively prevent the damage of equipment by transient lightning under 3.0 kV, surge and other kinds of pulse signal. - Page 21 IR Intelligent Speed Dome Camera User Manual 1. Add a Resistor to the farthest camera form the controller, and turn over loading or the communication to “ON", the other distance is too far turn to off. 2. Add code distributor. Video cable poor contact Eliminate Power shortage to the power supply...
