SAPPHIRE Technology EDGE HD 4 User Manual

1. Product Specifications
Item
CPU
Chipset
RAM
Storage
Graphics
LAN
WIFI
I/O
Power
Monitor
Keyboard/Mouse
Dimensions
Weight
Operating System
Important information for your safety and comfort
Please read these instructions carefully before using the product and
save for future reference.
Ÿ
Ensure that the Mini-PC is turned off and disconnected from the
mains supply before cleaning
Ÿ
Do not use liquid or aerosol cleaners, a damp cloth should suffice
Ÿ
Insert the power connector into the Mini PC before plugging the
mains cable into the AC power outlet.
Ÿ
When you need to disconnect power to the equipment, unplug the
power cord from the AC power outlet before removing the power
connector from the Mini PC.
TinyPC User Manual
Description
Intel Sandy Bridge Celeron 847 dual-core 1.10GHz
Intel NM70
2GB/4GB – DDR3
2.5'' SATA 250GB / 320GB / 500GB HDD
Intel HD Graphics
Built-in Ethernet supporting 10/100/1000 Mbps
Built-in WIFI supporting IEEE 802.11 b/g/n
VGA x1, HDMI x1, RJ45x 1, 1 x USB 3.0 Ports, 3x
USB 2.0 Ports Audio-In x1, Line Out x1
AC 100~240V 50/60Hz,19v~3.42A 65W
Supplied separately
Supplied separately
19.3(L) X 14.8(W) X 2.2(H) cm
530g
Pre-installed with FREE DOS; Supports Win7/Win8
