Zebra-Tech MPM-100 Quick Reference Manual

Mobile payment module
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
QRG.fm Page 1 Friday, October 14, 2011 3:24 PM
MPM-100
MOBILE PAYMENT MODULE
QUICK REFERENCE GUIDE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MPM-100 and is the answer not in the manual?

Questions and answers

Summary of Contents for Zebra-Tech MPM-100

  • Page 1 QRG.fm Page 1 Friday, October 14, 2011 3:24 PM MPM-100 MOBILE PAYMENT MODULE QUICK REFERENCE GUIDE...

  • Page 2: Service Information

    QRG.fm Page 2 Friday, October 14, 2011 3:24 PM MPM-100 Motorola reserves the right to make changes to any product to improve reliability, function, or design. Motorola does not assume any product liability arising out of, or in connection with, the application or use of any product, circuit, or application described herein.
  • Page 3 QRG.fm Page 3 Friday, October 14, 2011 3:24 PM Quick Reference Guide Introduction This Quick Reference Guide explains how to setup, use and maintain the MPM-100 Mobile Payment Module. Unpacking Carefully remove all protective material from around the device and save the shipping container for later storage and shipping.
  • Page 4 Power Button Smart Card Slot LED State Description Contactless Notification LEDs During a Contactless transaction, LEDs light from left to right indicating transaction is in process. Power Flashing Green MPM-100 is in sleep mode. Slow Flashing Red Battery is low.
  • Page 5 Bluetooth Single Blue Flash Active SPP connection with mobile device. Double Blue Flash After a power on, the MPM-100 is resuming pair relationship with mobile device. MPM-100 is in discoverable mode. Keypad Use the numeric keypad for entering data. Numeric Keys...

  • Page 6: Getting Started

    QRG.fm Page 6 Friday, October 14, 2011 3:24 PM MPM-100 Getting Started To start using the MPM-100, install one or two Security Access Module (SAM) cards (if required), install the battery and then charge the MPM-100. Installing SAM Cards NOTE An SAM card is not required for all applications. If using one SAM card, place the card in either holder.

  • Page 7: Installing The Battery

    1. Place the battery, contacts first, into the battery compartment. Contacts 2. Ensure that the battery is laying flat in the compartment. 3. Align the battery door with the battery compartment. 4. Secure the battery door to the MPM-100 using four screws.
  • Page 8 Charging the MPM-100 Using Cradle Place the MPM-100 into a slot in the cradle. Ensure that the MPM-100 is seated properly. Failure to do so can cause the MPM-100 to not charge properly. The MPM-100 Power LED indicates that the MPM-100 is charging.

  • Page 9: Turning On/Off

    Refer to the mobile device’s User Guide for more information. If the mobile device supports the Scan and Pair Bluetooth pairing feature, scan the Bluetooth MAC Address bar code on the back of the MPM-100 to pair the mobile device and the MPM-100.

  • Page 10: Magnetic Stripe Transactions

    Launch a transaction application on the mobile device and initiate a credit or debit transaction. On the MPM-100, swipe the credit or debit card through the magnetic stripe reader (MSR) slot, orienting the magnetic stripe as shown. For credit transaction the customer may need to sign on the mobile device screen.

  • Page 11: Contactless Transactions

    Launch a transaction application on the mobile device and initiate a credit or debit transaction. Hand the MPM-100 to the customer. The customer inserts the Smart card into the slot, orienting the card with the contacts facing down and toward the back of the MPM-100.

  • Page 12: Troubleshooting

    Fully charge the MPM-100. MPM-100 display does not Battery not charged. Recharge the battery. show correct or readable System error. Turn the MPM-100 off and then on. If problem information. still occurs, contact support. Display is blank. Battery not charged. Recharge the battery.

  • Page 13: Maintenance

    QRG.fm Page 13 Friday, October 14, 2011 3:24 PM Quick Reference Guide Cleaning To clean the MPM-100, use a clean cloth slightly dampened with water and a drop or two of mild soap. For stubborn stains, use alcohol or an alcohol-based cleaner. CAUTION Never use thinner, trichloroethylene, or ketone-based solvents –...

  • Page 14: Bluetooth Wireless Technology

    QRG.fm Page 14 Friday, October 14, 2011 3:24 PM MPM-100 CAUTION Only use Motorola approved and UL Listed accessories, battery packs and battery chargers. Do NOT attempt to charge damp/wet mobile devices or batteries. All components must be dry before connecting to an external power source.

  • Page 15: Vehicle Installation

    QRG.fm Page 15 Friday, October 14, 2011 3:24 PM Quick Reference Guide • Reduce or eliminate direct pressure • Provide adjustable workstations • Provide adequate clearance • Provide a suitable working environment • Improve work procedures. Vehicle Installation RF signals may affect improperly installed or inadequately shielded electronic systems in motor vehicles (including safety systems).

  • Page 16: Warnings For Use Of Wireless Devices

    QRG.fm Page 16 Friday, October 14, 2011 3:24 PM MPM-100 Warnings for Use of Wireless Devices Please observe all warning notices with regard to the usage of wireless devices. Potentially Hazardous Atmospheres - Vehicles Use You are reminded of the need to observe restrictions on the use of radio devices in fuel depots, chemical plants etc.

  • Page 17: Other Medical Devices

    QRG.fm Page 17 Friday, October 14, 2011 3:24 PM Quick Reference Guide Other Medical Devices Please consult your physician or the manufacturer of the medical device, to determine if the operation of your wireless product may interfere with the medical device. RF Exposure Guidelines Safety Information Reducing RF Exposure - Use Properly...

  • Page 18: Power Supply

    QRG.fm Page 18 Friday, October 14, 2011 3:24 PM MPM-100 Power Supply Use ONLY a LISTED Motorola, Verifone's direct plug-in power supply (5 VDC, 1 A), marked Class 2 or LPS (IEC60950-1, SELV). Type no.: • PWR087-002-01-A with USA type for USA and Canada •...

  • Page 19: Battery Safety Guidelines

    QRG.fm Page 19 Friday, October 14, 2011 3:24 PM Quick Reference Guide Battery Safety Guidelines • The area in which the units are charged should be clear of debris and combustible materials or chemicals. Particular care should be taken where the device is charged in a non commercial environment.

  • Page 20: Radio Frequency Interference Requirements - Fcc

    MPM-100 QRG.fm Page 20 Friday, October 14, 2011 3:24 PM Radio Frequency Interference Requirements - FCC Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

  • Page 21: Statement Of Compliance

    QRG.fm Page 21 Friday, October 14, 2011 3:24 PM Quick Reference Guide Statement of Compliance Motorola hereby, declares that this device is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. A Declaration of Conformity may be obtained from http://www.motorola.com/doc.
  • Page 22 QRG.fm Page 22 Friday, October 14, 2011 3:24 PM MPM-100...
  • Page 23 QRG.fm Page 23 Friday, October 14, 2011 3:24 PM Quick Reference Guide...
  • Page 24 QRG.fm Page 24 Friday, October 14, 2011 3:24 PM Motorola Solutions, Inc. 1301 E. Algonquin Rd. Schaumburg, IL 60196-1078, U.S.A. http://www.motorolasolutions.com MOTOROLA, MOTO, MOTOROLA SOLUTIONS and the Stylized M Logo are trademarks or registered trademarks of Motorola Trademark Holdings, LLC and are used under license. All other trademarks are the property of their respective owners.
