CONTENT
1. Overview
First, thank you for your choosing of this GSM fixed wireless phone.
We offer you this kind of GSM wireless communication terminal desktop products
according to the market demand, with years of experience of developing and producing phones.
The characteristics of the wireless access realize that the speech message sent anytime and
anywhere, especially suitable for rural areas and the remote ares that it is unconvenient to use
wire, etc. and any kind of indoor places for mobile communication.
To ensure that all the function of the products can use normally, please read this detailed
specification before use the products and note items as follows:
Please charge the battery for more than 16 hours when it is first charged.
For your safety, please do not use this product while driving.
In case of thunderstorms, please do not use this phone.
Please turn off it when on the plane, in the hospital, around dangerous goods, gas station
and around fuel and chemicals or other dangerous goods.
Please turn off the phone when there are medical equipments that indicating not use
wireless phone. This phone may interfere implanted heart pacemaker hearing aid and
other medical implant equipment .
This may be interfered around TV, radio and computer and other electrical equipment,
then the performance of phone may be affected.
Please turn off the phone then clean it. Please use a bit wet or anti-static cleaning cloth
to clean the phone, do not use cleanser and other chemicals.
This product will generate magnetic field, do not put it around such as computer disk
those kind of magnetic storage medium.
User manual for Q880 R1.0
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the Q880 R1.0 and is the answer not in the manual?

Questions and answers

Summary of Contents for GSM Q880 R1.0

  • Page 1 CONTENT 1. Overview First, thank you for your choosing of this GSM fixed wireless phone. We offer you this kind of GSM wireless communication terminal desktop products according to the market demand, with years of experience of developing and producing phones.
  • Page 2 For the phone function upgrade continuously, it may be some discrepancy with specification during the actual use, sorry. SAR: The device complies with RF specifications when the device used at 15mm far from your body. User manual for Q880 R1.0...
  • Page 3 10message ringtones & mute. Send & receive message, 200 message instore. 100 phone book LCD of date, time, signal strength and battery capacity. Instore, search, delete and callback 10 incoming calls and outgoing calls and missed call log. User manual for Q880 R1.0...
  • Page 4 Environmental temperature: -10 C - 55 Relative humidity (RH): ≤ 90% Atmospheric pressure: 86~106Kpa Operating frequency: GSM 850\ EGSM900\ DCS1800\PCS1900 MHz Operating voltage: AC220V, 50Hz,DC 5V 700mA Standby battery:chargable battery Stand-by time:more than 50 hours Continuous talking time:around 3 hours P.S.: stand-by time, continous talking time is determined by the local network condition.
  • Page 5 12.REDIAL key:In the stand-by state, press this button to dial the number that has been dialed last time. 13. C.LIST key: In the stand-by state, press this button to show the call history menu. User manual for Q880 R1.0...
  • Page 6 In case of loss or damage of information in card,please back up in time, and avoid touching the metal are,and put SIM card away from electromagnetic. Once SIM card is damaged, it is impossible for you to enter GSM network. In some ares, th phones have built-in SIM card, it is unnecessary to operate this.
  • Page 7 OFF: Long press power button [ON/OFF], the screen light off, the phone is off. User manual for Q880 R1.0...
  • Page 8 During the conversation, press 【 →】 button to adjust the conversation voice;there are 7 degree to adjust. Adjust the conversation voice of the hand shank if use hand shank to talk;adjust hands-free conversation voice if use hands-free. User manual for Q880 R1.0...
  • Page 9 (4) (Copy contacts):Copy record of SIM card to phone or from phone to SIM card. (5) (Move contacts):Move record of SIM card to phone or from phone to SIM card. (6) (Delete all contacts):Delete all contacts of SIM card or phone. User manual for Q880 R1.0...
  • Page 10 After editing, please press [OK] to send this message. (Call sender) :Call the sender. (Forward) :Forward this message to others. (Delete) :Delete this message. (Delete all) :Delete all the message inbox. 7-2-3(Drafts) : User manual for Q880 R1.0...
  • Page 11: Sms Templates

    7-2-6(SMS templates) Enter message submenu, choose SMS templates, after entering, then press [OK] to enter. You can see as follow: (Use) :Select this menu ,the templates message you choose will show on the editable screen. 7-2-7(Settings) User manual for Q880 R1.0...
  • Page 12 7-3-5(Call times) :automaticly save the time of all the calls. You also can delete all the times. 7-4(Organizer) In the stand-by state, press 【MENU】 to enter the main menu, press NO. button 【4】 , then press [OK], the phone will enter organizer submenu automaticly. User manual for Q880 R1.0...
  • Page 13 (Language) : after entering this menu, press 【↑、 ↓】 to choose English, and press [OK] to set it. (Pref.Input method) :choose the default input method, press 【↑、↓】to choose Smart ABC, Smart abc, ABC, abc, Numeric. (Contrast) :between 1-15 degree of concentration, press 【←、→】to adjust the concentration 在 1~15. User manual for Q880 R1.0...
  • Page 14: Call Divert

    (1)Disable: choose this, all the number can call the phone. (2)Restrict All: choose this, all the number can not call the phone. (3)Allow List: You can add numbers to the list to block the numbers call you. User manual for Q880 R1.0...
  • Page 15: Security Settings

    (Phone security) :Enter to set phone code and modify the code. 7-5-5(Restore factory settings) :press【OK】to input code”1122(initial password)”,then press 【OK】 ,to restore factory settings. Then the phonebook, call logs and speed dial number of the User manual for Q880 R1.0...
  • Page 16 (Ring type): Here you can set the ring type: Repeat, Ascending or Beep once. Just press up/down arrow key to select one and OK Key to save it. (Extra tone): Here you can turn on/off extra tone. User manual for Q880 R1.0...
  • Page 17 T U V T U V t u v t u v W X Y Z W X Y Z w x y z w x y z symbol,for details see the list of symbols User manual for Q880 R1.0...
  • Page 18 B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy User manual for Q880 R1.0...
  • Page 19 SAR: The radiated output power of this device is below the FCC radio frequency exposure limits. Nevertheless, the device should be used in such a manner that the potential User manual for Q880 R1.0...
  • Page 20 RF exposure guidelines the phone must be installed and operated with a minimum of 15 mm separation from the your body. Failure to observe these instructions could result in your RF exposure exceeding the relevant guideline limits. User manual for Q880 R1.0...
