Amdi WTC4 User Manual

Head end system channelized bi-directional amplifier
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
WTC4
Head End System
Channelized Bi-Directional Amplifier
User's Manual
rev 6
A p p l i e d
M i c r o
D e s i g n
I n c .
19516 Amaranth Drive Germantown MD 20874 ph 301.540.9506 | info@appliedmicrodesign.com | www.appliedmicrodesign.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WTC4 and is the answer not in the manual?

Questions and answers

Summary of Contents for Amdi WTC4

  • Page 1 WTC4 Head End System Channelized Bi-Directional Amplifier User’s Manual rev 6 A p p l i e d M i c r o D e s i g n I n c . 19516 Amaranth Drive Germantown MD 20874 ph 301.540.9506 | info@appliedmicrodesign.com | www.appliedmicrodesign.com...
  • Page 2 Table of Contents Notes, Cautions, and Warnings System Description System Block Diagram Downlink Rack Uplink Rack DSP Card Cage DSP Front Panels & Indicators DSP Description & Specifications Dual Power Amplifier Front Panel & Indicators Single Power Amplifier Front Panel & Indicators Power Amplifier Description &...

  • Page 3: Contact Information

    Notes, Cautions, and Warnings This is a Class B Booster. Part 90 (Class B) Signal Boosters WARNING. This is NOT a CONSUMER device. It is designed for installation by FCC LICENSEES and QUALIFIED INSTALLERS. You MUST have an FCC LICENSE or express consent of an FCC Licensee to operate this device.
  • Page 4 Introduction There are three major components to the Tower-4 system; the Head-End hardware, the Distributed Antenna System (DAS) hardware, and the Site-Wide Network (SWN). Signals from the SWN are input to the Downlink (DL) Head-End (HE) hardware. These signals are filtered and amplified by the HE DL, and fed into the DAS.

  • Page 5: Channel Card X

    WTC4 System Block Diagram Channel Card x 7 4 0 0 M H z Channel Card Assembly Downlink CBC/Combiner 400 MHz Dual Amplifier Model No. 1465DSP-4-2-P Model No. 1465CCS-4-400 Model No. 1465PAD-3-1-400 rev 9 Dual Dual Window 1 S3DL65 S6DLB...

  • Page 6: Table Of Contents

    Channel Card x 8 4 0 0 M H z Uplink Dual CBC/Splitter WTC4 System Block Diagram Model No. 1465CSD-8-400-3-800 Channel Card Assembly Model No. 1465DSP-4-2-P S9ULB rev 9 Window 1A Dual Dual FPGA Clock Generator Window 1A Uplink Group...

  • Page 7: System Specification

    System Specification DSP Section Frequency Range: Downlink Uplink 453 - 454 MHz 458 - 459 MHz 460 - 461 MHz 455 - 456 MHz 464 - 465 MHz 469 - 470 MHz 470 - 471 MHz 473 - 474 MHz 851 - 854 MHz 806 - 807 MHz 807 - 808 MHz...
  • Page 8 RF IN RF IN RF IN RF IN READY READY READY READY CHANNEL CARD ASSEMBLY POWER MODEL NO. 1465DSP-4-2-P RF OUT RF OUT RF OUT RF OUT ETHERNET POWER SUPPLY W1 - W3 482 - 485 MHz 460 - 464 MHz RACS RACS STATUS...
  • Page 9 RF IN RF IN RF IN RF IN READY READY READY READY CHANNEL CARD ASSEMBLY POWER MODEL NO. 1465DSP-4-2-P RF OUT RF OUT RF OUT RF OUT ETHERNET POWER SUPPLY FAN TRAY RF IN RF IN RF IN RF IN READY READY READY...
  • Page 10 DSP Card Cage - 4 Cards Model No. 1465DSP-4-2-P RF IN RF IN RF IN RF IN PPLIED ICRO ESIGN READY READY READY READY POWER RF OUT RF OUT RF OUT RF OUT ETHERNET POWER SUPPLY Card No. Card No. Card No.
  • Page 11 DSP Front Panel and Indicators RF Input RF IN STATUS Connector STATUS blinking: board is communicating steady: board is initialized with processor card Status Indicator steady: board is keyed Connector RF OUT RF Output Connector DSP Card L.E.D. columns blink alternately until processor card establishes communication with DSP cards.

  • Page 12: Window 2

    DSP Front Panel and Indicators Power steady: unit is powered POWER Indicator POWER Power Switch POWER SUPPLY Power Supply The Channel Card is a Software Defined Radio (SDR) that can process up to sixteen channels. The filter parameters of each channel can be independently selected to optimize the Adjacent Channel Time Delay Interference (TDI).
  • Page 13 DSP Specifications (all parameters are software defined) Frequency Range Downlink Uplink 453 - 454 MHz 458 - 459 MHz 460 - 461 MHz 455 - 456 MHz 464 - 465 MHz 469 - 470 MHz 470 - 471 MHz 473 - 474 MHz Number of Channels 2 (standard);...
  • Page 14 Dual Power Amplifier - Front Panel and Indicators Model No. 1465PAD-3-1-400 Input 1 Input 2 RACS Input 3 Input 4 RACS Power Connector Connector Connector Connector Connector Connector Indicator W1 - W3 482 - 485 MHz 460 - 464 MHz RACS RACS 400 MHz DUAL AMPLIFIER...
  • Page 15 Dual Power Amplifier - Front Panel and Indicators Model No. 1465PAD-2-1-400 Input 1 RACS Input 2 Input 3 RACS Power Connector Connector Connector Connector Connector Indicator W6 W10 PPLIED ICRO ESIGN 477 - 479 MHz 453 - 454 MHz RACS RACS 400 MHz DUAL AMPLIFIER STATUS...

  • Page 16: Power Amplifier Specifications

    The 1465PA channel amplifier is a high-linearity, multi-carrier amplifier for DAS (Distributed Antenna System) applications. The unit is a single or dual-amplifier configuration. Each amplifier has its own processor board, alarms, panel indicators and power supply. processor board controls the enable signal to the amplifier and monitors forward power, reverse power, current, fan status and heat sink temperature.
  • Page 17 CBC/Combiner - Front Panel Model No. 1465CCS-4-400 Input 1 Input 2 Input 3 Input 4 Connector Connector Connector Connector 400 MHz IN 1 IN 2 IN 3 IN 4 800 MHz IN 5 Input 5 Output Connector Connector The 1465CCS-4-400 is a Cross Band Coupler (CBC) and Combiner in one chassis; it is designed for DAS (Distributed Antenna System) applications.
  • Page 18 CBC/Splitter - Front Panel and Indicators Model No. 1465CSD-8-400-3-800 Output 1A Output 2 Output 4 Output 7 Connector Connector Connector Connector Output 1 Output 3 Output 5 Output 10 RACS Power Connector Connector Connector Connector Connector Indicator 400 MHz PPLIED ICRO ESIGN RACS...
  • Page 19 The 1465CSD-8-400-3-800 is a Cross Band Coupler and Splitter housed in one chassis; it is designed for DAS (Distributed Antenna System) applications. The CBC/Splitter separates signals from the 400 MHz and 800 MHz bands into two paths. Each path has a splitter for multi-channel distribution of multi-carrier signals for downstream processing.
  • Page 20 RF IN RF IN RF IN RF IN READY READY READY READY CHANNEL CARD ASSEMBLY POWER MODEL NO. 1465DSP-4-2-P RF OUT RF OUT RF OUT RF OUT ETHERNET POWER SUPPLY W1 - W3 482 - 485 MHz 460 - 464 MHz RACS RACS STATUS...
  • Page 21 RF IN RF IN RF IN RF IN READY READY READY READY CHANNEL CARD ASSEMBLY POWER MODEL NO. 1465DSP-4-2-P RF OUT RF OUT RF OUT RF OUT ETHERNET POWER SUPPLY FAN TRAY RF IN RF IN RF IN RF IN READY READY READY...
  • Page 22 RF IN RF IN RF IN RF IN READY READY READY READY CHANNEL CARD ASSEMBLY POWER MODEL NO. 1465DSP-4-2-P RF OUT RF OUT RF OUT RF OUT ETHERNET POWER SUPPLY W1 - W3 482 - 485 MHz 460 - 464 MHz RACS RACS STATUS...
  • Page 23 RF IN RF IN RF IN RF IN READY READY READY READY POWER CHANNEL CARD ASSEMBLY MODEL NO. 1465DSP-4-2-P RF OUT RF OUT RF OUT RF OUT ETHERNET POWER SUPPLY FAN TRAY RF IN RF IN RF IN RF IN READY READY READY...
  • Page 24 PPLIED ICRO ESIGN...
  • Page 25 Back to Index PPLIED ICRO ESIGN...
  • Page 26 Downlink Installation No antennas, cables, and/or coupling devices are shipped with this equipment. RF IN RF IN RF IN RF IN READY READY READY READY POWER RF OUT RF OUT RF OUT RF OUT ETHERNET POWER SUPPLY W1 - W3 482 - 485 MHz 460 - 464 MHz RACS...
  • Page 27 Uplink Installation No antennas, cables, and/or coupling devices are shipped with this equipment. RF IN RF IN RF IN RF IN READY READY READY READY POWER RF OUT RF OUT RF OUT RF OUT ETHERNET POWER SUPPLY FAN TRAY RF IN RF IN RF IN RF IN...
  • Page 28 Appendix A NMS GUI Manual...
  • Page 29 SER’S ANUAL Network Monitoring and Control System 1.0 – AMDI (NMS) Applied Micro Design Inc. May, 2015...
  • Page 30 Revision Sheet Revision Sheet Release No. Date Revision Description 5/25/15 User’s Manual Created NMS User’s Manual Page i...
  • Page 31 GETTING STARTED ........................2-1 Startup ............................2-1 System Requirements ......................2.1 Opening the Map........................2-1 Exit NMS..........................2-2 MAPS...............................3-1 Overview Map........................3-1 Node View Map ........................3-2 COMPONENT LEVEL GUI ......................4-1 AMDI DSP Processor Board Control ..................4-1 4.1.1 Status/Control .........................4-1 4.1.2 Thresholds..........................4-2 4.1.3 Update.............................4-3 4.1.4 Faults............................4-4 AMDI Power Amplifier Control ....................

  • Page 32: Product Description

    1.0 Product Description PRODUCT DESCRIPTION NMS User’s Manual...

  • Page 33: Overview

    1.0 Product Description PRODUCT DESCRIPTION Overview The WTC NMS is a graphical user interface, GUI, program that notifies WTC personnel if a specific component fails or if a condition exists that can cause a failure. The GUI continuously polls each component and displays the current status on the GUI screen.

  • Page 34: Acronyms And Abbreviations

    WTC – World Trade Center. This is the site for the system installation. GUI – Graphical User Interface NMS – Network Management and Control System AMDI – Applied Micro Design Inc. DSP – Digital Signal Processing RF – Radio Frequency CBC –...

  • Page 35: Getting Started

    2.0 Getting Started GETTING STARTED NMS User’s Manual...

  • Page 36: Startup

    2.0 Getting Started GETTING STARTED Startup The system comes with the NMS pre-installed. Start NMS server: 1. Double-click the Intermapper® icon on the Desktop. Figure 2: InterMapper® Desktop Shortcut 2. The Map List window will appear. Figure 3: Map List System Requirements To use NMS, ensure the following minimum software and Hardware requirements are available: ...

  • Page 37: Exit Nms

    2.0 Getting Started Exit NMS Close all map windows, Intermapper® application, and component GUI windows. NMS User’s Manual Page 2-2...

  • Page 38: Maps

    3.0 Maps MAPS NMS User’s Manual...

  • Page 39: Overview Map

    3.0 Maps MAPS The WTC NMS consists of layered maps which provide different levels of detail. The user can double click on a node, to see a more detailed view of the equipment or to identify a failed or about to fail component.

  • Page 40: Node View Map

    3.0 Maps Node View Map The Node View Map provides a detailed view of the equipment room which includes the Uplink and Downlink racks. Devices in alarm mode flash red. The user can drill down into the device to view detailed status of the hardware, set alarm thresholds, enable/disable the device, and update device firmware.

  • Page 41: Component Level Gui

    4.0 Component Level GUI COMPONENT LEVEL GUI NMS User’s Manual...

  • Page 42: Amdi Dsp Processor Board Control

    Each component GUI includes 3 tab pages Status, Thresholds, and Update. AMDI DSP Processor Board Control 4.1.1 Status/Control The status tab displays the current status for the individual DSP Channel Cards installed in the chassis.

  • Page 43: Thresholds

    Table 1. DSP Channel Card Threshold Values To edit thresholds, click the ‘Thresholds’ tab, then click ‘Edit’, when prompted for a username/password use the following: Username: AMDI Password: admin Figure 5. Login Prompt to edit thresholds This will allow the user to make changes to the threshold values.

  • Page 44: Update

    4.0 Component Level GUI Figure 6. DSP Thresholds tab 4.1.3 Update Update Processor Firmware: To update the firmware running inside the processor, click ‘Open HEX’ and navigate to the coorisponding .hex file. Once the file has been selected, click update. There will be a label that says “Programming Complete”...

  • Page 45: Faults

    FORWARD POWER FAULT The measured forward power Verify DSP board RF output and value is less than the forward AGC settings using the AMDI UI power threshold. application. REVERSE POWER FAULT The measure reverse power value Verify RF cables are connected is greater than the reverse power properly.

  • Page 46: Thresholds

    Number representing the maximum allowable temperature in degrees C. Table 3. Power Amplifier Threshold Values To edit thresholds, click the ‘Thresholds’ tab, then click ‘Edit’, when prompted for a username/password use the following: Username: AMDI Password: admin NMS User’s Manual Page 4-5...

  • Page 47: Update

    4.0 Component Level GUI Figure 10. Login Prompt to edit thresholds This will allow the user to make changes to the threshold values. Figure 11. Power Amplifier Thresholds Tab 4.2.3 Update Update Processor Firmware: To update the firmware running inside the processor, click ‘Open HEX’ and navigate to the coorisponding .hex file.

  • Page 48: Faults

    REVERSE POWER FAULT The measure reverse power value Verify RF cables are connected is greater than the reverse power properly. threshold. Table 4. Power Amplifier Fault Messages AMDI Cross Band Coupler 4.3.1 Status NMS User’s Manual Page 4-7...

  • Page 49: Thresholds

    The thresholds tab allows the user to set the current draw threshold for the LNAs. To edit thresholds, click the ‘Thresholds’ tab, then click ‘Edit’, when prompted for a username/password use the following: Username: AMDI Password: admin Figure 14 Login Prompt to edit thresholds This will allow the user to make changes to the threshold values.

  • Page 50: Update

    4.0 Component Level GUI Figure 15 CBC Thresholds Tab 4.3.3 Update Update Processor Firmware: To update the firmware running inside the processor, click ‘Open HEX’ and navigate to the coorisponding .hex file. Once the file has been selected, click update. There will be a label that says “Programming Complete”...

  • Page 51: Faults

    4.0 Component Level GUI 4.3.4 Fault The table below describes the fault message displayed in the Status column on the ‘Status’ tab page. The alarm is generated whenever a measured value exceeds the threshold. Fault Name Description Troubleshooting CURRENT FAULT The current draw for the LNA is Verify the CBC is connected and greater than the current threshold...
  • Page 52 Appendix B RACS (Radio Access Control System) Description...

  • Page 53: Window

    RACS function for the DL and UL racks respectively. Each of the components described above is listed along with the corresponding AMDI model number. Figures 3, 4, and 5 show the RACS section of a typical Card Cage, DL Power Amplifier, and UL CBC in more detail.
  • Page 54 The following is a list of relay fault assignments: DSP Channel Card #1 Fault DSP Channel Card #2 Fault DSP Channel Card #3 Fault DSP Channel Card #4 Fault Spare #1 Spare #2 Figure 3 shows the Card Cage block diagram and the RACS relay lines. Power Amplifier RACS Interface The Power Amplifier chassis contains either one or two power amplifier modules.
  • Page 55 Notes: 1.RACS fault thresholds are the same as for the chassis front-panel LED’s. Thresholds are set using the AMDI GUI. 2.The “Forward Power” fault is not defined at this time. 3.All faults are generated under firmware control of the processor board in the corresponding chassis.

  • Page 56: Window

    WTC4 HE Alarms Diagram Downlink Group rev 3 400 MHz 400 MHz 800 MHz Channel Card Assembly Model No. 1465DSP-4-2-P Amplifier Amplifier DB-25 DB-25 Processor Processor (RACS) Serial Serial (RACS) RACS RACS Interface Interface Amplifier DB-25 Processor Serial (RACS) Ethernet Interface...

  • Page 57: Window

    WTC4 HE Alarms Diagram Uplink Group rev 3 DB-25 Processor (RACS) Serial RACS Interface Ethernet Interface to Ethernet Processor switch Analog (MCAS) Power Interface Status Current Current Sense LNA 2 Current Fault Current Current Sense LNA 1 Current Fault Digital...

  • Page 58: Window

    Alarm DB-25 Pin No. DSP Card # 1 NO DSP Card # 1 COM Window Window Window Window DSP Card # 1 NC DSP Card # 2 NO DSP Card # 2 COM DSP Card # 2 NC DSP Card # 3 NO DSP Card # 3 COM Serial DSP Card # 3 NC...

  • Page 59: Power Amplifier

    Alarm DB-25 Pin No. Fwd Pwr NO Fwd Pwr COM Fwd Pwr NC 400 MHz Ref Pwr NO Ref Pwr COM Ref Pwr NC Current Fault NO Amplifier Current Fault COM Processor Serial Current Fault NC RACS Interface Temp Fault NO Temp Fault COM Ethernet Interface to Ethernet...
  • Page 60 Alarm DB-25 Pin No. LNA # 1 Current NO LNA # 1 Current COM LNA # 1 Current NC LNA # 2 Current NO LNA # 2 Current COM LNA # 2 Current NC Spare # 1 NO Spare # 1 COM Processor Serial Spare # 1 NC...
  • Page 61 Appendix C DSP User GUI Operation...
  • Page 62 This document describes the operation of the WTC GUI, the graphical user interface program that is used to configure each of the DSP modules. To use the WTC GUI connect a USB cable from the PC to a DSP module and start the program by double-clicking on the desktop shortcut that looks like this: When the WTC GUI program starts it looks for DSP modules on the USB interface.

  • Page 63: Window

    The WTC firmware allows up to eight channels in uplink mode but other firmware is available from AMDI that allows up to sixteen channels per DSP module. The ULW8 has six channels. The GUI hides the GUI controls for the channels beyond those six since the settings read from the board tell the GUI program that for the “Up Link Window 8”...
  • Page 64 As you can see in the figure above, for each channel the GUI provides controls that specify these values: Channel Frequency (MHz) Channel filter bandwidth Channel filter order Output AGC setpoint (dBm) Squelch A and B types Squelch A and B values The GUI also provides the following outputs: Squelch A and B ON or OFF indicators Channel Input signal level (dBm)

  • Page 65: Window

    A filter with an order of 6 provides an input to output delay of about 24 microseconds but the filter transitions from its passband to its stop bands slowly. A filter with an order of 80, on the other hand has sharp edges but a longer delay.
  • Page 66 Notice that the BW: is set to 3 MHz. The BW control lets the user select from 50kHz, 100 kHz, 150 kHz, 200 kHz, 250 kHz, 500 kHz, 1 MHz, 1.5 MHz, 2 MHz, 2.5 MHz, 3 MHz, 3.5 MHz, 4 MHz, 5 MHz or 5.5 MHz.
  • Page 67 The pushbutton labeled “Update Firmware” is used to write new firmware into the DSP module. It lets the user select a “.BIT” file to load. This should only be done when AMDI sends a new firmware file and the new file has been loaded onto the PC. The present firmware file is on the PC named AmdiDspWtc.bit.
