Summary of Contents for Omnex T100-900
- Page 1 Spread Spectrum Transmitter Model T100-900 User Manual Rev A Copyright 1998 OMNEX Control Systems Inc. All rights reserved.
- Page 2 Changes or modifications not expressly approved by OMNEX Control Systems Inc. invalidate any approval or warranty applying to the product and can void the user’s authority to operate this equipment.
- Page 3 2 USER GUIDE Configuration 2.1.1 Power Configuration The unit can operate in several different power-on modes: MODE ON/OFF DESCRIPTION SWITCH • Unit turns ON when When unit is first turned ON or any time the ON button is pressed, data is transmitted •...
- Page 4 B. TOGGLE Each output pair is independently toggled and latched. Every time a button is pressed, its corresponding output toggles. In the event of loss of carrier, the status of the output will either retain its state or turn OFF depending on the POWER ON mode selected. C.
