Summary of Contents for Mentor Graphics MF0200
- Page 1 MF0200 ANUAL FOR ATEWAY ERSION...
-
Page 2: Federal Communication Commission Interference Statement
RADEMARKS ©2016 Mentor Graphics Corporation, all rights reserved. This document contains information that is proprietary to Mentor Graphics Corporation and may be duplicated in whole or in part by the original recipient for internal business purposes only, provided that this entire notice appears in all copies. - Page 3 User Manual for MF0200 Gateway Box FCC Radiation Exposure Statement This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. CE Mark Warning This equipment is compliant with Class A of CISPR 32.In a residential environment this equipment may cause radio interference.
- Page 4 User Manual for MF0200 Gateway Box BATTERY CAUTION: Danger of explosion if battery is incorrectly replaced. Replace only with same or equivalent type recommended by the manufacturer. Do not discard used batteries in to regular trash. These batteries need to be recycled according to the manufacturer's instructions.
-
Page 5: Table Of Contents
User Manual for MF0200 Gateway Box Table of Contents Federal Communication Commission Interference Statement ............1 Introduction to MF0200 CSP Gateway ................... 6 1.1. CSP Gateway Specification .................... 7 1.1.1. Front View of CSP Gateway Device ..................8 ... - Page 6 User Manual for MF0200 Gateway Box P a g e...
-
Page 7: Introduction To Mf0200 Csp Gateway
ATEWAY The MF0200 CSP gateway hardware is a cloud-connected high-performance computer which is a component of Mentor Graphics’ Cloud Services Platform (CSP). This device is fully managed from a flexible and extendable cloud-hosted backend. The MF0200 serves as an interface between any cloud-hosted service and on premise devices connected to the gateway via wired and/or wireless interfaces such as TV/Display connected via HDMI cable to the gateway, USB devices (e.g. -
Page 8: Csp Gateway Specification
User Manual for MF0200 Gateway Box 1.1. CSP G ATEWAY PECIFICATION Following table shows specifications of the CSP gateway device. NXP i.MX6 quad-core 1.0GHz Heatsink System RAM 2GB DDR3 eMMC 16GB WiFi 802.11b/g/n 2.4G single-band Bluetooth HDMI One (1) full-size HDMI One (1) | 6pin | wire-to-board connector Pin1 –... -
Page 9: Front View Of Csp Gateway Device
User Manual for MF0200 Gateway Box 1.1.1. F CSP G RONT IEW OF ATEWAY EVICE 1. Wi-Fi Antenna. 2. LED: Ethernet 0 interface activity indicator 3. LED: Ethernet 1 interface activity indicator 4. LED: Cloud LED 5. LED: Peripherals LED 6. -
Page 10: Back View Of Csp Gateway Device
User Manual for MF0200 Gateway Box 1.1.2. B CSP G ATEWAY EVICE 1. RR: Reset 2. FR: Factory Reset 3. USB ports 4. Ethernet 0 and Ethernet 1 port 5. Power Supply P a g e... -
Page 11: Csp Gateway Led Indicator Chart
User Manual for MF0200 Gateway Box 1.1.3. CSP G ATEWAY NDICATOR HART Following table shows how the LED lights indicate the operations being performed on the CSP gateway device. no. CSP Box State GREEN GREEN Peripherals Peripherals Cloud Cloud Power On... - Page 12 User Manual for MF0200 Gateway Box firmware CSP System Error applying patch Heartbeat CSP System firmware update done Heartbeat Heartbeat Heartbeat Heartbeat 11 | P a g e...
-
Page 13: Getting Started
User Manual for MF0200 Gateway Box 2. G ETTING TARTED To setup the gateway, you require: 2.1. CSP M OBILE ORTAL PPLICATION The basic system requirements to set up the gateway device are: 1. Android device which operates on android version 5.1 or above. -
Page 14: Initial Configuration And Connection
User Manual for MF0200 Gateway Box 3. I NITIAL ONFIGURATION AND ONNECTION 3.1. P OWER UP 1. Attach the provided antenna to the gateway: Screw on antenna to the provided socket on the gateway. The antenna can be rotated and angled so it can be aligned in any installation position. -
Page 15: Login
User Manual for MF0200 Gateway Box 3.2. L OGIN Launch the CSP mobile setup application on your mobile device and login into the CSP mobile portal by providing a valid username and password. Figure 1: Login Enter Credentials provided to you by the CSP administrator to login. Following... - Page 16 User Manual for MF0200 Gateway Box Figure 2: Home screen 15 | P a g e...
-
Page 17: Pairing & Connecting
User Manual for MF0200 Gateway Box 3.3. P & C AIRING ONNECTING To pair the gateway device it is needed to go to the dashboard and setup the device. Figure 3: Home screen After clicking the menu button the Dashboard can be seen. - Page 18 User Manual for MF0200 Gateway Box Click on setup to pair and configure the box. Figure 5: Two ways of setting up a gateway device The gateway device can be selected in two ways – by selecting the gateway from a drop-down list or by scanning the barcode located on the back of the gateway.
-
Page 19: List Gateway Devices
User Manual for MF0200 Gateway Box 3.3.1. L ATEWAY EVICES List of all the gateway devices provisioned with particular account will be displayed. Figure 6: List of gateway devices After choosing the gateway, application requests to turn on the Bluetooth on the mobile device (smartphone) if it already has not been enabled. - Page 20 User Manual for MF0200 Gateway Box Figure 7: Enter pin for pairing Enter the pin of CSP gateway device provided to you by the CSP administrator. 19 | P a g e...
-
Page 21: Gateway Device Info
User Manual for MF0200 Gateway Box 3.3.1.1. Gateway Device Info After authentication the following screen would appear with information regarding the selected CSP gateway device. This shows the current settings of the CSP Gateway device. status Figure 8: Gateway Device Info- To see the network configurations of the CSP gateway device select “Network... - Page 22 User Manual for MF0200 Gateway Box Network Configuration Figure 9: Gateway Device Info- 21 | P a g e...
-
Page 23: Update Network Settings
User Manual for MF0200 Gateway Box 3.3.1.2. Update Network Settings Click on Update Network Settings to change the network settings. Figure 10: Update Network Settings. After selecting “Update Network Settings” new screen would appear that allows the user to choose the networking interface. In this case it is “Ethernet”. -
Page 24: Ethernet Configuration
User Manual for MF0200 Gateway Box 3.3.1.3. Ethernet Configuration: Figure 11: Choose the network interface After choosing Ethernet click “NEXT”. 23 | P a g e... -
Page 25: Ethernet Setup - Dhcp
User Manual for MF0200 Gateway Box 3.3.1.3.1. Ethernet Setup - DHCP Ethernet can be setup to either DHCP or Static configuration. Click on save button to select DHCP. Figure 12: Ethernet Setup 24 | P a g e... - Page 26 User Manual for MF0200 Gateway Box Figure 13: Confirm Changes to Setting. Select “Apply DHCP” to confirm the selection. After DHCP settings; following window appears to confirm that configuration is sent. 25 | P a g e...
- Page 27 User Manual for MF0200 Gateway Box Figure 14: Configuration sent After configurations are sent the CSP gateway device is automatically rebooted. 26 | P a g e...
- Page 28 User Manual for MF0200 Gateway Box Figure 15: Rebooting the device. Updated configurations are displayed after reboot of CSP gateway device. 27 | P a g e...
- Page 29 User Manual for MF0200 Gateway Box Figure 16: Updated network configuration 28 | P a g e...
- Page 30 User Manual for MF0200 Gateway Box Figure 17: Updated Status 29 | P a g e...
-
Page 31: Ethernet - Static Configuration
User Manual for MF0200 Gateway Box 3.3.1.3.2. Ethernet - Static Configuration DHCP is selected by default but if the user requires to change it to Static configuration; it can be changed by turning DHCP off. Figure 18: Ethernet Setup 30 |... - Page 32 User Manual for MF0200 Gateway Box Fill in the needed fields and “click” save button. Figure 19: Ethernet Setup- Static Configuration The application prompts if the user wants to continue applying new settings to the CSP gateway device. Same flow is followed as described in “Ethernet DHCP”.
-
Page 33: Wireless Configuration
User Manual for MF0200 Gateway Box 3.3.1.4. Wireless Configuration To configure the CSP gateway device to connect to the CSP backend via wireless connection select Wi-Fi in the options and follow the following steps. Figure 20: Configuration options 32 |... - Page 34 User Manual for MF0200 Gateway Box Figure 21: Wi-Fi credentials Fill in the required fields: 1. Wi-Fi SSID: the SSID for the Wi-Fi network to be used. 2. Password: password for the Wi-Fi. 33 | P a g e...
- Page 35 User Manual for MF0200 Gateway Box Figure 22: Applying configurations to the box\ Once the reboot of CSP gateway device is done it will be online via Wi-Fi. 34 | P a g e...
-
Page 36: Scan Barcode
User Manual for MF0200 Gateway Box 3.3.2. S ARCODE Alternatively, to add the gateway with barcode place the barcode in the view provided. Figure 23: Barcode Scanning After the device is recognized follow the same steps as given in Section 3.3.1.1 “Gateway... -
Page 37: Firmware Update
User Manual for MF0200 Gateway Box 3.4. F IRMWARE PDATE When the CSP gateway device is properly configured it will automatically update the firmware, if update is available. Operation of patch update can also be seen through LED indication, as specified in Section no. -
Page 38: Add Peripheral Device
User Manual for MF0200 Gateway Box 4. A ERIPHERAL EVICE To add the peripheral device go to the dashboard and select “Add New”. Figure 24: Dashboard 37 | P a g e... -
Page 39: Step 1
User Manual for MF0200 Gateway Box 4.1. S This will list the CSP gateway devices available for that particular account. Figure 25: List of CSP gateway devices Select the gateway device to add new peripheral. 38 | P a g e... -
Page 40: Step 3
User Manual for MF0200 Gateway Box 4.2. S Input the basic information of the peripheral. Figure 26: Peripheral Basic Info Fill in the required fields: 1. Peripheral Friendly Name: name of the peripheral for easy recognition 2. Network Address: local IP of the peripheral 3. - Page 41 User Manual for MF0200 Gateway Box 4.3. S The information regarding manufacturer, type and model of the peripheral are added in this step. Figure 27: Peripheral Type/ Model 40 | P a g e...
- Page 42 User Manual for MF0200 Gateway Box Select a peripheral type to add the type of the peripheral. There are two basic types of peripherals printer and mote. Figure 28: Types of peripheral 41 | P a g e...
- Page 43 User Manual for MF0200 Gateway Box After choosing the peripheral type, select the manufacturer of the peripheral. Figure 29: Manufacturers After choosing the manufacturer, select the model of the peripheral and click next. 42 | P a g e...
- Page 44 User Manual for MF0200 Gateway Box Figure 30: models of peripherals 43 | P a g e...
-
Page 45: Step 4
User Manual for MF0200 Gateway Box 4.4. S Add the QR and NFC details of the peripheral. It is an optional step. If the user does not wish to input this information the system would generate these codes by itself. - Page 46 User Manual for MF0200 Gateway Box The final review of the peripheral’s information. Tap the add button to add the peripheral. Figure 32: Review information 45 | P a g e...
- Page 47 User Manual for MF0200 Gateway Box If the peripheral is added successfully following message is displayed. Figure 33: Success response 46 | P a g e...
-
Page 48: Vesa Mount 75Mm * 75Mm Information
User Manual for MF0200 Gateway Box 5. VESA M * 75 OUNT NFORMATION 6. C ONTACT If need be the user can contact for support at: csp_support@mentor.com 47 | P a g e...
