User Manual Instruction
1.Safety And Warnings --------------------------------------------------------- 2
2.Your equipment includes ---------------------------------------------------- 3
3. Receiver Function Instruction -------------------------------------------- 3
(1) Front Panel ----------------------------------------------------------------------------- 3
(2) Rear Panel ------------------------------------------------------------------------------ 4
(2) Side Panel ------------------------------------------------------------------------------ 6
(3) Remote Control Unit ------------------------------------------------------------------ 7
4. Safety Instructions ------------------------------------------------------------ 7
5. Declaration Of Conformity ----------------------------------------------- 10
6. Caution--------------------------------------------------------------------------12
ADB-1729CWF vuCaster/
Contents
ADB
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ADB-1729CWF and is the answer not in the manual?

Questions and answers

Summary of Contents for Shenzhen Jiuzhou Electric Co. ADB-1729CWF

  • Page 1: Table Of Contents

    User Manual Instruction ADB-1729CWF vuCaster/ Contents 1.Safety And Warnings --------------------------------------------------------- 2 2.Your equipment includes ---------------------------------------------------- 3 3. Receiver Function Instruction -------------------------------------------- 3 (1) Front Panel ----------------------------------------------------------------------------- 3 (2) Rear Panel ------------------------------------------------------------------------------ 4 (2) Side Panel ------------------------------------------------------------------------------ 6 (3) Remote Control Unit ------------------------------------------------------------------ 7 4.

  • Page 2: Safety And Warnings

    1.Safety And Warnings Our decoder ensures you access to TV service signal and allows you to enjoy better image sharpness and sound. In addition the service feature gives you benefits like quick program switching, automatic channel search, parental control all in an end user-friendly interface easy to use. With advanced 8PSK and QPSK demodulation and decoding, it is able to receive and decode all the digital TV video standards supported by DVB, MPEG2 and MPEG4 modulation.

  • Page 3: Your Equipment Includes

    2.Your equipment includes Your Set-Back-Box also includes the following items: （1） 1 Pcs Digital Satellite SBB (Set-Back-Box) （2） 1 Pcs HDMI cable （3） 1 Pcs Ethernet cable （4） 1 Pcs Power adapter （5） 1set Mounting kit and screws 3. Receiver Function Instruction (1) Front Panel LED Display The Product equipped with the dual colour LED for the power state...

  • Page 4: Rear Panel

    (default) RF4CE transceiver The Product equipped with a RF4CE transceiver for Product’s remote control capability, compliant with Zigbee RF4CE Specification. Wi-Fi Interface The Product equipped with a non-concurrent dual band 2.4GHz / 5GHz 2T2R Wi-Fi interface compliant with IEEE 802.11ac and legacy (a/b/g/n) standard.
  • Page 5 compliant with HDMI specification 2.0 for digital audio/video output. Rear2* USB2.0 Port(5V ,1000mA) Connector used to connect the receiver to your external storage unit for recording and playback audio and video (external storage unit not included) ，support PVR。 Ethernet Port The Product equipped with one, RJ45 IEEE 802.3 [21] compliant, 100/10Mbit Ethernet port for LAN interface.

  • Page 6: Side Panel

    (2) Side Panel Smart Card Connector The Product equipped with a single Smart Card connector compliant with ISO 7816-1 [73]. The connector slot hidden behind the flip doors secured with anti-tamper protection. SD card port The Product equipped with one, SD card port compliant with SD Card Mechanical specification .

  • Page 7: Remote Control Unit

    (3) Remote Control Unit(testing) 4. Safety Instructions .Using this product, always follow basic precautions described below. You minimize this the risk of fire or electric shock. Conditions for installation and use of the product...
  • Page 8 The product must be installed and ready to work according to the instructions.The product must be installed and used indoors, at room temperaturenot exceeding 40 ° C.The product should not be placed near any heat source or direct sunlight.The product should be put in place with good air flow so it does not undergo overheating.
  • Page 9 transmission line branching or subscriber compatible with the requirements of BS EN 60728-11.To minimize the risk of fire or electric shock, do not connect too manydevices into one electrical outlet using an extension cord or splitters. Current consumption of devices connected to the USB port can not exceed output current of the socket.

  • Page 10: Declaration Of Conformity

    5. Declaration Of Conformity ADB hereby declares that this product complies with the essential requirements and other relevant provisions of EMC Directive 2004/108 / EC, Directive LVD 2006/95 / EC ErP Directive 2009/125 / EC and RoHS Directive 2011/65 / EU. This product complies with the standards: EN 60065, EN 55032: 2012, EN 55024, EN 55020, (EC) No 1275/2008, (EC) No 278/2009 and the "Voluntary Agreement Industry 3.0".
  • Page 11 reduced to less than 9W. Through the use of the power management options. After 4 hours, the idle power consumption is reduced to below 0.5 W. DISPOSAL AND RECYCLING OF UNUSED PRODUCT INFORMATION FOR USERS according to the Regulation of the Minister of Economy of 8 May 2013.

  • Page 12: Caution

    6. Caution This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions,...
  • Page 13 RF Exposure The equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This device should be installed and operated with minimum distance 20cm between the radiator & your body. The equipment indoor use only.
