Zoomtak Telephonics 4300A User Manual

Bluetooth 56k fax modem
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
2.0
BLUETOOTH 56K FAX MODEM
Product Name: Bluetooth modem
Model No.: 4300A, 4161A
Applicant: Zoom Telephonics, Inc.
User's manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 4300A and is the answer not in the manual?

Questions and answers

Related Manuals for Zoomtak Telephonics 4300A

Summary of Contents for Zoomtak Telephonics 4300A

  • Page 1 BLUETOOTH 56K FAX MODEM Product Name: Bluetooth modem Model No.: 4300A, 4161A Applicant: Zoom Telephonics, Inc. User’s manual...

  • Page 2: Regulatory Statements

    REGULATORY STATEMENTS FCC Certification The United States Federal Communication Commission (FCC) and the Canadian Department of Communications have established certain rules governing the use of electronic equipment. Part15, Class B This device complies with Part 15 of FCC rules. Operation is subject to the following two conditions: 1.

  • Page 3: Table Of Contents

    Index C H A P T E R 1 Introduction C H A P T E R 2 Specifications C H A P T E R 3 Product Shape C H A P T E R 4 Bluetooth Modem Mode C H A P T E R 5 Generic Modem Mode C H A P T E R 6...

  • Page 4: Introduction

    1. Introduction The Bluetooth 56K wireless modem is a 56K modem equipped with Bluetooth function. It provides a standard V.92 Modem for WAN communication and access to Internet. With a Bluetooth adapter, you can dial up to access the network via this device wirelessly.

  • Page 5: Specifications

    2. Specifications 2.1. Features V92 Modem ITU-T V.92 and K56flex • V.34 (33.6 kbps), V.32 bis, V.32, V.22 bis, V.22, V.23, and V. 21; Bell • 212A and 103 Flow control and speed buffering • Automatic format/speed sensing • V.22bis fast connect •...

  • Page 6: Power Consumption

    2.5. Environment Operating Ranges Operation : 0 ~ 50℃, Humidity 10 ~ 90% • Storage : -20 ~ 90℃, Humidity 10 ~ 90% • 2.6. Power Consumption Operation: (Avg), (Max) • 175mA / 6V 220mA/6V Standby: • 52mA/6V 2.7. LED Indication Power LED: •...

  • Page 7: Product Shape

    3. Product Shape...

  • Page 8: Bluetooth Modem Mode

    1. Power LED indicator: Lights when the Bluetooth Modem powers on. 2. Link LED indicator: Lights when Bluetooth Modem is linked by a remote device. 3. ACT LED indicator: Blinks when data is transferring via Bluetooth connection. 4. OH LED indicator: Lights when Bluetooth Modem is dialing or gets connected.
  • Page 9 4. Bluetooth Modem Mode 4.1. Getting Started 1. Turn the switch to "BT" side 2. Connect the telephone line to the RJ-11 socket 3. Plug in the AC adapter to the power outlet.
  • Page 10 4.2. How to dial-up under Widcomm Bluetooth Windows (BTW) The Following procedures are using the Bluetooth software as reference on how to use the Bluetooth Modem to access the Internet. The user should follow accordingly based on the Bluetooth software in hand. For Windows 98 1.
  • Page 11 2. Bluetooth software will start searching the surrounding remote devices. Find the "Bluetooth Modem" icon and then double click on it.
  • Page 12 3. The service start discovery. 4. Then windows will ask you a 4-digit PIN Code to pair with the Bluetooth Modem. You can find the PIN Code on the bottom of your Bluetooth modem. The default Pin code is “1111”.
  • Page 13 5. Key in the PIN Code and click the "OK" button. 6. When Bluetooth Modem has been paired, it will show 3 services. Double click on "Dial-up Networking on Bluetooth Modem" service icon.
  • Page 14 7. When the connection is established, the service icon will change the color to green.
  • Page 15 8. If you are using the dial-up connection first time, the following window will pop out. Type in the area code of your location, and then click the "Close" button. 9. The "Connect To" window will auto pop-up. Please key in the user name, the password, and the phone number.
  • Page 16 10. The Bluetooth Modem starts dialing. 11. Once the connection is established you can run a web browser.
  • Page 17 For Windows ME 1. Double click the "My Bluetooth Places" icon on the desktop. The following window wills pop-up. Double click the "Find Bluetooth Devices" icon.
  • Page 18 2. Bluetooth software will start searching the surrounding remote devices. Find the "Bluetooth Modem" icon and then double click on it.
  • Page 19 3. The service start discovery. 4. Then windows will ask you a 4-digit PIN Code to pair with the Bluetooth Modem. You can find the PIN Code on the bottom of your Bluetooth modem. The default Pin code is “1111”.
  • Page 20 5. Key in the PIN Code and click the "OK" button. 6. When Bluetooth Modem has been paired, it will show 3 services. Double click on "Dial-up Networking on Bluetooth Modem" service icon.
  • Page 21 7. When the connection is established, the service icon will change the color to green.
  • Page 22 8. If you are using the dial-up connection first time, the following window will pop out. Type in the area code of your location, then click the "Close" button. 9. The "Connect To" window will auto pop-up. Please key in the user name, the password, and the phone number.
  • Page 23 10. The Bluetooth Modem starts dialing. 11. Once the connection is established you can run a web browser.
  • Page 24 For Windows 2000 1. Double click the "My Bluetooth Places" icon on the desktop. The following window wills pop-up. Double click the "Find Bluetooth Devices" icon.
  • Page 25 2. Bluetooth software will start searching the surrounding remote devices. Find the "Bluetooth Modem" icon and then double click on it.
  • Page 26 3. The service start discovery. 4. Then windows will ask you a 4-digit PIN Code to pair with the Bluetooth Modem. You can find the PIN Code on the bottom of your Bluetooth modem. The default Pin code is “1111”.
  • Page 27 5. Key in the PIN Code and click the "OK" button. 6. When Bluetooth Modem has been paired, it will show 3 services. Double click on "Dial-up Networking on Bluetooth Modem" service icon.
  • Page 28 7. When the connection is established, the service icon will change the color to green.
  • Page 29 8. The "Connect To" window will auto pop-up. Please key in the user name, the password, and the phone number. You can get the information form your ISP (Internet Service Provider) and then click the "Connect" button. 9. The Bluetooth Modem start dialing.
  • Page 30 10. Once the connection is established you can open your web browser.
  • Page 31 For Windows XP 1. Double click the "My Bluetooth Places" icon on the desktop. The following window wills pop-up. Click the "View devices in range" item in "Bluetooth Tasks".
  • Page 32 2. Bluetooth software will start searching the surrounding remote devices. Find the "Bluetooth Modem" icon and then double click on it.
  • Page 33 3. The service start discovery. 4. Then windows will ask you a 4-digit PIN Code to pair with the Bluetooth Modem. You can find the PIN Code on the bottom of your Bluetooth modem. The default ping code is “1111”.
  • Page 34 5. Key in the PIN Code and click the "OK" button.
  • Page 35 6. When Bluetooth Modem has been paired, it will show 3 services. Double click on "Dial-up Networking on Bluetooth Modem" service icon. 7. When the connection is established, the service icon will change the color to green.
  • Page 36 8. The "Connect BluetoothConnection" window will auto pop-up. Please key in the user name, the password, and the phone number. You can get the information form your ISP (Internet Service Provider) and then click the "Dial" button. 9. The Bluetooth Modem starts dialing. 10.
  • Page 37 4.3. How to use dial-up network under MAC O.S. 10.3 1. To use dial-up network function under MAC O.S.10.3, first from “system preference” click hardware ”Bluetooth” icon 2. System will show the “Bluetooth” windows, please click “Devices” ”Set Up New Device” start setup with “Bluetooth setup assistant”.
  • Page 38 3. At “Bluetooth Setup assistant” welcome screen please click “Continue” to next step. 4. In this step please “Other Device” in “Select Device Type” window and click “Continue” button to next step.
  • Page 39 5. In this page please select “bt56r3” in “Devices” window and click “Continue” button to next step 6. In this page please key in passkey the default passkey is “1111” and click “Continue” button to next step...
  • Page 40 7. In “Bluetooth Mobile Phone Set Up” page please select the service with your phone click “Continue” button to next step 8. In this page you should key in your ISP “Username”, “Password”, and ”Phone number” and remember change Modem Script to “Hayes Accura 56K”...
  • Page 41 9. In this page you are complete your Bluetooth dial up network setting, please click “Quit” button to finish “Bluetooth setup assistant”. 10. To use you dial-up network function please click phone icon on takes bar, and click “Connect”, please mark sure “Bluetooth” is selected. 11.

  • Page 42: Generic Modem Mode

    5. Generic Modem Mode 5.1 Getting Started 1. Turn the switch to "RS-232" side 2. Connect the telephone line to the RJ-11 socket. 3. Plug in the RS-232 cable male connector to RS-232 connector of Bluetooth Modem and plug in the female connector to your PC. 4.
  • Page 43 5.2 Driver Installation under Windows For Windows 98 1. Make sure your PC is powered on and you are running the Windows operating system. Then system will recognize the device and display the "Add New Hardware Wizard" dialog box. Please insert the driver CD and then click the "Next"...
  • Page 44 2. Select "Search for the best driver for your device (Recommended)", then click the "Next" button. 3. Select "Specify a location" and type "G:\Modem" (where G:\ is the path of your CD-ROM drive) in the location or you can click the "Browse" button to select, and then click the "Next"...
  • Page 45 4. Please click the "Next" button, the driver then installs itself. 5. Click the "Finish" button to complete the installation process.
  • Page 46 For Windows ME 1. Make sure your PC is powered on and that you are running the Windows operating system. Then system will recognize the device and display the "Add New Hardware Wizard" dialog box. Please insert the driver CD and then click the "Next"...
  • Page 47 2. Select "Search for the best driver for your device." then choose "Specify a location" and type "G:\Modem" (where G:\ is the path of your CD-ROM drive) in the location or you can click the "Browse" button to select, then click the "Next" button. 3.
  • Page 48 4. Click the "Finish" button to complete the installation process.
  • Page 49 For Windows 2000 1. Make sure your PC is powered on and that you are running the Windows operating system. Then system will recognize the device and display the "Found New Hardware Wizard" dialog box. Please insert the driver CD then click the "Next"...
  • Page 50 2. Select "Install the software automatically (Recommended)", then click the "Next" button.
  • Page 51 3. Select "Specify a location" then click the "Next" button. 4. Type "G:\Modem" (where G:\ is the path of your CD-ROM drive) in the location or you can click the "Browse" button to select, then click the "Next" button.
  • Page 52 5. Click the "Next" button, the driver then installs by itself. 6. Windows will search for and recognize the driver of the device, then display one message. Please click the "Yes" button. Windows will then automatically copy the driver files and related files into the system.
  • Page 53 7. After copying the driver files, click the "Finish" button to complete the installation process.
  • Page 54 For Windows XP 1. Make sure your PC is powered on and that you are running the Windows operating system. Then system will recognize the device and display the "Found New Hardware Wizard" dialog box. Select "Install from a list or specific location (Advanced)", insert the driver CD then click the "Next"...
  • Page 55 2. Select "Search for the best driver in these locations." and choose "Include this location in the search:" then type "F:\Modem" (where F:\ is the path of your CD-ROM drive) in the location or you can click the "Browse" button to select,. Click the "Next" button.
  • Page 56 3. Windows will search for and recognize the driver of the device, then display one message. Please click the "Continue Anyway" button. Windows will then automatically copy the driver files and related files into the system. 4. After copying the driver files, click the "Finish" button to complete the installation process.
  • Page 57 5.3 How to dial-up under Windows Please refer to the Windows Operating System user guide to setup a dial-up connection.

  • Page 58: How To Use Btmodemutility

    6. How to use BTModemUtility? This utility can change the name and Pin Code of the Bluetooth modem device. This utility can be found in the driver CD. (The path is: \Modem\Utility) Before you change pin code, please notes these steps. 1.
  • Page 60 6.2. Getting Started 1. Double click the "Serial port on Bluetooth Modem" icon to connect.
  • Page 61 2. You can find the serial port number on the bottom of the screen. (In this case the Bluetooth serial Port is set at COM3). 3. We recommend you NOT to select “Do not display this message again”. That will allow you to find out your virtual COM port next time.
  • Page 62 4. Then run the "BTModemUtility" from your CD path:\\Utility\BTModemUtility.exe. If you choose the wrong virtual COM port, it will show “Fatal Error: Receive data timeout.”, “Fatal Error: Failed to send data out.” or “Fatal Error: Cannot open the selected COM port.”. Please check your COM port in “step 2”.
  • Page 63 5. You will see target device information on the screen. The default Pin Code is 1111. You can change the device name and a new Pin Code. Note: The device name and Pin Code have to be alphanumeric.
  • Page 64 6. If you choose “Disable Authentication Requirement”, you won’t have to enter the Pin Code next time. Then press "OK", and "Exit".
  • Page 65 7. After changing to a new device name or Pin Code, you must unpair the device. Note: Select the device and right click the mouse button to choose “Pair Device“or “Unpair Device“.
  • Page 66 8. Then you select one of the Bluetooth Modem function. 9. The device will require you to enter the new Pin Code...
  • Page 67 10. You will see the new device name in the request window, and you can enter the new PIN Code to complete the pairing process.

  • Page 68: How To Use Modem Country Region

    7. How to use Modem Country Region? This utility can change the country region of the Bluetooth modem device. This utility can be found in the driver CD. (The path is: \Modem\Utility) Before you change country region, please notes these steps. For RS-232 Mode 1.
  • Page 69 4. Choose “Search for the best driver in these locations”→”Include the location in the search”. And press ”Browse” to the path in CD-ROM.
  • Page 70 5. Press “Continue Anyway”. 6. Press “Finish”.
  • Page 71 7. Check your COM port in “Device Manager” → ”Property” → ”General”. (In this case the serial port is COM1). 8. Select your COM port.
  • Page 72 9. Select your country. 10. Press “OK” to finish country region setting.
  • Page 73 For BT Mode 1. Turn the switch to "BT" side 2. Double click the "Serial port on Bluetooth Modem" icon to connect.
  • Page 74 3. You can find the serial port number on the bottom of the screen. (In this case the Bluetooth serial Port is set at COM3). 4. We recommend you NOT to select “Do not display this message again”. That will allow you to find out your virtual COM port next time.
  • Page 75 5. Select your COM port. 6. Select your country. 7. Press “OK” to finish country region setting..
