- Page 2 This manual will tell you all about your new ServSwitch™ ServView, including how to install, operate, and troubleshoot it. For an introduction to the ServView, see Chapter 2. The ServView product code covered in this manual is: KVT109A...
- Page 3 SERVSWITCH™ SERVVIEW TRADEMARKS USED IN THIS MANUAL BLACK BOX and the logo are registered trademarks, and ServSwitchis a trademark, of Black Box Corporation. Apple and Macintosh are registered trademarks of Apple Computer, Inc. IBM, PS/2, and RS/6000 are registered trademarks of International Business Machines Corporation.
- Page 4 FCC/IC STATEMENTS FEDERAL COMMUNICATIONS COMMISSION AND INDUSTRY CANADA RADIO-FREQUENCY INTERFERENCE STATEMENTS This equipment generates, uses, and can radiate radio-frequency energy and if not installed and used properly, that is, in strict accordance with the manufacturer’s instructions, may cause interference to radio communication. It has been tested and found to comply with the limits for a Class A computing device in accordance with the specifications in Subpart J of Part 15 of FCC rules, which are designed to provide reasonable protection against such interference when the equipment is...
- Page 5 SERVSWITCH™ SERVVIEW EUROPEAN UNION DECLARATION OF CONFORMITY This equipment complies with the requirements of the European EMC Directive 89/336/EEC with respect to the EN 55022 (Class A) and EN 55024 standards, as well as the Low Voltage Directive 73/23/EEC with respect to the EN 60950...
- Page 6 NOM STATEMENT NORMAS OFICIALES MEXICANAS (NOM) ELECTRICAL SAFETY STATEMENT INSTRUCCIONES DE SEGURIDAD 1. Todas las instrucciones de seguridad y operación deberán ser leídas antes de que el aparato eléctrico sea operado. 2. Las instrucciones de seguridad y operación deberán ser guardadas para referencia futura.
- Page 7 SERVSWITCH™ SERVVIEW 12. Precaución debe ser tomada de tal manera que la tierra fisica y la polarización del equipo no sea eliminada. 13. Los cables de la fuente de poder deben ser guiados de tal manera que no sean pisados ni pellizcados por objetos colocados sobre o contra ellos, poniendo particular atención a los contactos y receptáculos donde salen del...
-
Page 8: Table Of Contents
2. Introduction ..................... 10 3. Safety Considerations ................11 4. Installation ....................12 4.1 The Complete Package ..............12 4.2 Assembling and Installing the ServView .......... 13 4.3 Connecting the Cables ..............16 5. Operation ....................18 5.1 Getting Started .................. 18 5.2 The TFT’s On-Screen Display ............ -
Page 9: Specifications
SERVSWITCH™ SERVVIEW 1. Specifications Compliance: CE (EN 55022 Class A, EN 55024, EN 60950); CISPR 22 Class A, CISPR 24, IEC 950; FCC Part 15 Subpart J Class A, IC Class/classe A Interface: Proprietary composite of VGA compatible video and... - Page 10 CHAPTER 1: Specifications Power: From utility-power (mains) outlet, through detachable power cord and IEC 320 male inlet, to internal transformer: Input voltage: 100 to 250 VAC; Input frequency: 50 to 60 Hz, single-phase; Input current: From 0.5 amps at 250 VAC to 0.7 amps at 100 VAC;...
-
Page 11: Introduction
SERVSWITCH™ SERVVIEW 2. Introduction The ServSwitch™ ServView is a rackmounted monitor/keyboard/mouse drawer for managing one or more rackmounted servers that occupies only 1U (1.75", 4.4 cm) of vertical rack space instead of the 10U (17.5", 44.5 cm) or more that can be necessary to house a CRT. -
Page 12: Safety Considerations
(or such hot) equipment in your rack that heat impairs or damages your devices. • Be careful not to spill any liquid on the ServView, and don’t use the ServView near water. • Do not insert foreign objects into any openings in the ServView’s housing. You could damage the ServView and/or give yourself a dangerous electric shock. -
Page 13: Installation
SERVSWITCH™ SERVVIEW 4. Installation 4.1 The Complete Package Along with the ServView, you should have received: • A telescoping rackmount-rail assembly; • A cable-carrier arm; • (6) 8-32 x ⁄ " screws; • (2) 8-32 x ⁄ " screws; • (12) 10-32 x ⁄... -
Page 14: Assembling And Installing The Servview
CAUTION! To reduce the risk of personal injury or damage to equipment, make sure that the rack is ready to receive the ServView before you install it: – The leveling jacks must be extended to the floor. – The full weight of the rack must rest on the leveling jacks. - Page 15 SERVSWITCH™ SERVVIEW 3. Attach one end of the cable-carrier arm to the back of the ServView with the included 8-32 x ⁄ " screws, as shown in Figure 4-2. Be careful not to attach this upside down: Make sure that the small “tab” section with the screwholes is oriented toward the inside of the rack, not toward the outside.
- Page 16 CHAPTER 4: Installation 7. After you’ve successfully mounted the ServView, attach the free end of the cable-carrier arm to the back end of one of the outside rails you installed in step 5. While holding the rail in place, back out the top and bottom screws (but not the middle screw) that you used to mount that end of the rail in step 5.
-
Page 17: Connecting The Cables
SERVSWITCH™ SERVVIEW 4.3 Connecting the Cables First, making sure that the power switch on the back of the ServView is in the OFF position (“O”), connect the included power cord to the IEC 320 power inlet just below the switch. - Page 18 CHAPTER 4: Installation Keyboard and mouse strands plug into Video strand plugs into PS/2 style 6-pin mini-DIN keyboard and HD15 female video port on mouse ports on CPU or switch CPU or switch Figure 4-5. Attaching the 3-in-1 cable to a CPU or to a KVM switch with separate user-port connectors.
-
Page 19: Operation
5. Operation 5.1 Getting Started To use the ServView, slide its drawer out of the rack cabinet until the retention clips of the ball-bearing slides catch. Open its TFT screen to a comfortable viewing angle. We suggest that, if possible, you set all your servers to 1024 x 768 resolution. -
Page 20: The Tft's On-Screen Display
Down button Exit button Figure 5-1. The ServView’s TFT-control buttons. To activate the ServView’s on-screen display, press the Enter key beside of the TFT screen. This will cause the main menu to appear, shown in Figure 5-2. MENU Auto Adjust... - Page 21 Down, and Exit. Some of these settings raise ergonomic issues. To make it as easy as possible to see the video on the ServView’s TFT screen, we recommend that you: • Adjust the TFT’s Brightness and Contrast to enhance readability as necessary.
-
Page 22: Maintenance And Troubleshooting
(afterimage effects, “burn-in”). Use a screen saver if the attached CPU or KVM switch supports this. The ServView has a fuse installed next to its ON/OFF switch. If this fuse ever blows, replace it only with another fuse with the same specifications (250V, 2.0 A maximum). -
Page 23: Shipping And Packaging
SERVSWITCH™ SERVVIEW 6.3 Shipping and Packaging If you need to transport or ship your ServView: • Package it carefully. We recommend that you use the original container. • If you are shipping the unit for repair, please include its power cord and CPU/switch cable. - Page 24 NOTES...
- Page 25 NOTES...
