MT1890 BARCODE SCANNER

Assembly Instructions: LITHIUM-ION

BATTERY PART REPLACEMENT

PART NO. MT2013; MT2015-IPODUSA

(w/iPod included)

EDI NO.19370; 10777 (w/iPod included)

Phone 800-987-6935 ext. 151 / 641-753-5999 ext. 151

104 S. 8th Ave.

Marshalltown, IA

Fax 641-753-3065

www.MT-MOBILITY.com

1 of 8

Table of Contents

Need help?

Do you have a question about the MT1890 and is the answer not in the manual?

Questions and answers

Summary of Contents for Marshalltown Company MT1890

Page 1 MARSHALLTOWN MT1890 BARCODE SCANNER ASSEMBLY INSTRUCTIONS: LITHIUM-ION BATTERY PART REPLACEMENT PART NO. MT2013; MT2015-IPODUSA (w/iPod included) EDI NO.19370; 10777 (w/iPod included) 104 S. 8th Ave. Marshalltown, IA Phone 800-987-6935 ext. 151 / 641-753-5999 ext. 151 Fax 641-753-3065 WS1227 www.MT-MOBILITY.com...
Page 2 MT1890 Barcode Scanner can withstand drops up to 15 feet on to solid concrete without damaging product parts. The MT1890 Barcode Scanner is designed to integrate with an Apple iPod Touch 6th and 5th Generation, allowing users to train themselves due to the simplicity of the device. The scanner engine provides high-quality accurate barcode scans even on old or damaged barcodes.
Page 3 ASSEMBLY INSTRUCTIONS FOR LITHIUM-ION BATTERY PART REPLACEMENT STEP 1. Remove screws on outer shell using #00 Phillips screwdriver. Pull bottom mold down and top mold up to snap apart shell. STEP 2. Remove iPod and inner sleeve from shell. Remove snap power slide from shell. STEP 3.
Page 4 ASSEMBLY INSTRUCTIONS: LITHIUM-ION BATTERY PART REPLACEMENT STEP 4. With caution; carefully pull battery wires out of space at top of battery compartment. With caution, carefully pull battery off bottom of battery compartment. (NOTICE: battery is attached to the bottom of battery compartment with silicon adhesive solution) STEP 5.
Page 5 ASSEMBLY INSTRUCTIONS: LITHIUM-ION BATTERY PART REPLACEMENT STEP 7. Use adhesive on bottom of battery compartment and place battery in compartment. (NOTICE: MT MOBILITY (manufacturer) recommends using silicon or 2mm 3M sticker tape for adhesive). With caution; tuck battery wires in space at top of battery compartment.
Page 6 ASSEMBLY INSTRUCTIONS: LITHIUM-ION BATTERY PART REPLACEMENT STEP 10. Place top mold of shell on bottom mold of shell. Snap molds together. STEP 11. Ensure buttons align with screws. Secure screws on outer shell using a #00 Phillips screwdriver. WS1227 6 of 8 104 S.
Page 7 SUPPORT We’re here to help with all of your product support questions. Get support by phone or email. CONTACT MT MOBILITY SUPPORT Phone: 641-753-5999 ext. 113 Toll Free: (1) 800-987-6935 ext. 113 Email: info@mt-mobility.com Monday – Friday; 7am – 5pm (CST, U.S.A.) WS1227 7 of 8 104 S.
Page 8 a division of MARSHALLTOWN 104 S. 8th Ave. Marshalltown, IA Phone 800-987-6935 ext. 151 / 641-753-5999 ext. 151 Fax 641-753-3065 www.MT-MOBILITY.com WS1227 8 of 8 104 S. 8th Ave. Marshalltown, IA Phone 800-987-6935 / 641-753-5999 ext. 151 • Fax 800-477-6341 / 641-753-3065 www.MT-MOBILITY.com 02-2017/Rev.B...
