Anchor CouncilMAN Owner's Manual

GETTING STARTED

Please check your new unit carefully for any damage which may have occurred during shipment. Each Anchor product is
carefully inspected at the factory and packed in specially designed boxes for safe transport.
Notify the freight carrier immediately of any damage to the shipping box or product. Repack the unit in the original box
and wait for inspection by the carrier's claim agent. Notify your dealer of the pending freight claim.
NOTE: All damage claims must be made with freight carrier!
RETURNING SYSTEMS FOR SERVICE OR REPAIR
For service or repair, please contact the dealer you purchased your system from or Anchor Audio Customer Service at
(888) 444-6077 to obtain a RA (Return Authorization) number. All shipments to Anchor Audio must include an RA
number and must be shipped prepaid. C.O.D. shipments will be refused and returned at your expense.
IMPORTANT: Save the shipping box & packing materials.
They were specially designed to ship your unit.

WARRANTY REGISTRATION

Visit our website at www.anchoraudio.com and select "Warranty Registration". Complete the online form to activate the
two-year limited warranty on your CoucilMAN Conference system.

COUNCILMAN TECHNICAL SPECIFICATIONS

AN-100CM
Console Speaker
Rated Power Output 30 watts
Max SPL @ Rated Power 106 dB @ 1 meter
Frequency Response 65 Hz – 18 kHz ± 3 dB
Speaker Type 4.5" woofer, 10 mm dome
tweeter Magnetically Shielded
AC Power Reqs. 100 – 240 VAC, 50/60 Hz
Fuse Rating T 1.0A / 250V (internally
mounted)
Export Model T 0.5A / 250V (internally
mounted)
CHM-100/DEL-100
Microphone Base
Power Requirement +22 VDC @ 60 mA from pin 2
of daisy chain
Output Impedence >10k ohms
Phantom Power 18V
Dimensions (HWD) 5.8 x 6.5 x 1.75" /
14.73 x 16.51 x 4.45 cm
Weight 0.90 lbs / .41 Kg
Daisy Chain In/Out Male and Female 3 pin XLR
CHM-100 Controls Push to Talk, Volume and
Mute Others
DEL-100 Controls Push to Talk and Volume
Warranty 2 years
(Features and specifications subject to change without notice)
Line In 3.5mm
Line Out Lo-Z, buffered, XLR and 1/4"
Balanced
Line Output Level -20 dBV (100 mVrms)
Enclosure Material ABS Plastic
Dimensions (HWD) 5.25 x 8.4 x 9"/13 x 21 x 23 cm
Weight 8.5 lbs / 3.8 Kg
Warranty 6 years
GM-100
Gooseneck Microphone
Pickup Pattern Cardioid
Type Back Electret Condenser
Phantom Power 9 - 52 Volts DC
Impedence 200 Ohms @ 1kHz
Response 80 Hz - 17 kHz ±3dB
Sensitivity -56 dB @ 1 kHz open circuit (0
dB = 1 V/ubar)
Dimension 18.75" from mic tip to XLR top,
2 flex sections
Microphone 0.54" O.D.
Warranty 2 years
CouncilMAN
CONFERENCE SYSTEM
OWNER'S MANUAL

A MESSAGE FROM THE OWNER

Thank you for choosing an Anchor Audio Conference system. Our products incorporate state-of-the-art design
and the finest quality of materials and workmanship. We're proud of our products and appreciate the confi-
dence which you have shown by selecting an Anchor system.
I hope you'll take a few minutes to review this manual. We've incorporated several unique features into our
products, and your knowledge of how to use them will enhance the performance and your enjoyment of the
system.
Janet Jacobs – President
on behalf of all Anchor Employees
888/444-6077•310/784-2300
100-0199-000 Rev. A 01/10
For Setup & Operation Videos Go To:
www.anchoraudio.com
