. LED Alarm (red)
Report any anomalies:
they are: DOOR
LOW H20 LEVEL = low level H2o
ALARM
The front panel also has a cup connector (optional), suitable for the attachment of an external printer. It also has a switch with
fuses (2x10A. 6.3x32).
5.3 Display mode alarm
Each alarm is displayed in the machine in the following way:
- The time display shows the alarm code (ex: A01, A02 etc.).
- It has issued a long beep followed by 10 short, eventually silenced.
- In case of alarm A00 (door open) or A01 (insufficient water level) which are the most frequent, also they flash their
LEDS and DOOR LOW LEVEL H20.
- In other cases, the ALARM LED flashes and the cause of the alarm must be obtained from the code on the display, or if
present, from the printer that prints in detail the reason for alarm.
-
The machine remains in this state until the occurrence of the condition of the termination / acknowledgment, specified
individually for each alarm.
- If this (alarm) occurs during the cycle, the latter is interrupted and the pressure discharged.
5.3.1 Alarms and codes Summary
CODE ALARM
A00
A01
A02
A03
A04-A05
A06
A07
A08
A09
A10
A12
A13
* = Repeat cycle, the material to be sterilized is not sterile. If the problem persists, contact
manufacturer.
N.B: A00, A01, A02 do not cause (in the presence of printer) no print activity.
This document may not be reproduced in partial form without the authorization of TAU STERIL.
Instructions for Use
TAU CLAVE 3000 Fractionated Vacuum
= door open
= generic alarm identified by the code on the display time
Door open: occurs if the start of the cycle, the door is open. Disappears by
pressing any key or by closing the door.
Low water: occurs if at the start of the cycle, the water level in the cargo
tank is insufficient. Disappears by pressing any key or by resetting the
level. If during the refueling operations is peaked, the time display shows
"STOP" and the beeper sounds in the manner of an alarm. 2 ceased
beeper "STOP" disappears, and returns to its normal state.
Tank full exhaust: occurs when the level of water in the recovery tank is
excessive. Disappears just emptying the tank.
Black-Out: occurs in cases of abandoned cycle by Black-Out.
Disappears opening the door or pressing any key. *
Long time for the heating is energized with any key. *
High pressure: it excites with any key. *
High temperature: energizes with any key. *
Abnormal pressure: energizes with any key. *
Abnormal temperature: energizes with any key. *
Stage vacuum not successful. *
High temperature PTV: it disappears by pressing any push button *
High temperature PTC: it disappears by pressing any push button *
