Summary of Contents for evertz 5600MSC

  • Page 1 Version 1.6 April 2006 The material contained in this manual consists of information that is the property of Evertz Microsystems and is intended solely for the use of purchasers of the 5600MSC Master Clock/SPG. Evertz Microsystems expressly prohibits the use of this manual for any purpose other than the operation of the 5600MSC.
  • Page 3: Important Safety Instructions

    Model 5600MSC Master Clock/SPG Manual IMPORTANT SAFETY INSTRUCTIONS The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of uninsulated “Dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.
  • Page 4 WARNING Changes or Modifications not expressly approved by Evertz Microsystems Ltd. could void the user’s authority to operate the equipment. Use of unshielded plugs or cables may cause radiation interference. Properly shielded interface cables with the shield connected to the chassis ground of the device must be used Revision 1.6...
  • Page 5 The 5600MSC may not be used on coin service provided by the telephone company. Connection to party lines is subject to state tariffs. If the modem in the 5600MSC is malfunctioning, it may affect the telephone lines. In this case, disconnect the modem until the source of the difficulty is traced.
  • Page 6 Evertz products are for informational use only and are not warranties of future performance, either express or implied. The only warranty offered by Evertz in relation to this product is the Evertz standard limited warranty, stated in the sales contract or order confirmation form.
  • Page 7: Table Of Contents

    2.4. CONNECTING THE SERIAL PORTS IN SYNCHRO MODE ............2-7 2.5. GPS RECEIVER INSTALLATION (G OPTION) ................2-8 2.5.1. Mounting the GPS Smart Antenna ................... 2-8 2.5.2. Connecting the GPS Smart Antenna to the 5600MSC ............. 2-9 2.5.3. System Startup ....................... 2-11 HOW TO OPERATE THE MASTER CLOCK/SPG............3-1 3.1.
  • Page 8 Model 5600MSC Master Clock/SPG Manual 3.3.4. Modem Status........................3-6 3.3.5. NTP Messages ......................... 3-6 3.3.6. LTC 1 Output Power Status Messages ................3-6 3.3.7. Power Supply Status Messages ..................3-7 3.3.8. GPI Input Supply Status Messages .................. 3-7 3.3.9. Cooling Fan Status Messages..................3-7 3.3.10.
  • Page 9 Model 5600MSC Master Clock/SPG Manual 3.6.3.3. Configuring the Analog Video Test Generator On Screen Message Display ..3-31 3.6.3.3.1. Editing the On Screen Message Display............3-31 3.6.3.3.2. Positioning the On Screen Message Display ..........3-31 3.6.3.3.3. Enabling the On Screen Message Display............ 3-31 3.6.3.3.4.
  • Page 10 3.7.6.2. Setting the Beginning and End of Daylight Saving Time ........3-62 3.7.6.3. Setting The DST Offset..................3-63 3.7.7. Firmware Utilities ......................3-63 3.7.7.1. Viewing the 5600MSC Firmware Version .............. 3-63 3.7.7.2. Upgrading the 5600MSC Firmware ............... 3-63 3.7.7.3. Viewing the HD Test Generator Firmware Version..........3-64 3.7.7.4.
  • Page 11 4.3. SERVICING INSTRUCTIONS...................... 4-8 4.3.1. Changing The Fuses ......................4-8 4.4. CONFIGURING WHAT MENUS WILL BE SEEN IN USER MODE USING VistaLINK .... 4-8 ® 4.4.1. Connecting the 5600MSC to VistaLINK ................4-9 ® 4.4.2. Installing VistaLINK ......................4-9 ®...
  • Page 12 Figure 2-2: Typical GPIO Circuitry.........................2-7 Figure 2-3: Pole Mounting the Smart Antenna....................2-9 Figure 2-4: Accutime 2000 Smart Antenna to 5600MSC Interface Cable (Evertz part WA-T09) ....2-10 Figure 2-5: Accutime 2000 Extender Cable ....................2-10 Figure 3-1: Model 5600MSC Front Panel Layout ..................3-1 Figure 3-2: Sync Generation - GPS Frequency Reference ................
  • Page 13 Model 5600MSC Master Clock/SPG Manual CHAPTER 1: OVERVIEW TABLE OF CONTENTS OVERVIEW ........................1-1 1.1. HOW TO USE THIS MANUAL..................... 1-3 1.2. DEFINITIONS..........................1-3 Figures Figure 1-1: Redundant Master Clock/SPG with Auto Changeover System Diagram ........1-2 Revision 1.6...
  • Page 14 Model 5600MSC Master Clock/SPG Manual This page left intentionally blank Revision 1.6...
  • Page 15: Overview

    SPGs or master clocks available in the industry. The 5600MSC may also be referenced to an external 5 MHz or 10 MHz master oscillator if higher stability is required. Both the SPG and the Master Clock sections may be referenced to high stability time and frequency standards present in the Global Position system (GPS) by adding the GPS option.
  • Page 16: Figure 1-1: Redundant Master Clock/Spg With Auto Changeover System Diagram

    Model 5600MSC Master Clock/SPG Manual All versions of the 5600MSC offer an AUX I/O port and a COM port for software upgrades and/or interconnecting two 5600MSC units (when used with the 5600ACO). An optional redundant power supply is also available.
  • Page 17: How To Use This Manual

    Figure 1-1 shows a typical configuration for a redundant system. For further information on connecting the 5600MSC in a dual redundant configuration consult the 5600ACO manual.
  • Page 18 Model 5600MSC Master Clock/SPG Manual frequency is 4 times the colour subcarrier frequency (approximately 14.3 MHz for NTSC and 17.7 MHz for PAL) AES: (Audio Engineering Society): A professional organization that recommends standards for the audio industries. AES-3: See AES/EBU.
  • Page 19 Model 5600MSC Master Clock/SPG Manual even though one of its signal parameters is approaching or passing the specified limits. At a given moment however, the parameter will reach a point where the data can no longer be interpreted correctly, and the picture will be totally unrecognizable.
  • Page 20: Revision

    Model 5600MSC Master Clock/SPG Manual DAYLIGHT SAVING TIME (DST): Daylight Saving Time (DST) or Summer Time as it is called in many countries, is a way of getting more daylight out of the summer days by advancing the clocks by one hour during the summer. Then, the sun will appear to rise one hour later in the morning when people are usually asleep anyway, at the benefit of one hour longer evenings when awake.
  • Page 21 Model 5600MSC Master Clock/SPG Manual used in both parallel and serial interfaces. It reflects definitions found in EBU Tech 3267 (for 625 line systems) and SMPTE 125M (parallel 525 line systems) and SMPTE 259M (serial 525 line systems). This document was formerly known as CCIR-656.
  • Page 22 Model 5600MSC Master Clock/SPG Manual SMPTE 12M: The SMPTE standard for the Time and Address Control signal in widespread use in the professional video and audio industries. SMPTE 12M defines the specifications for both Linear Time Code (LTC) and Vertical Interval Time Code (VITC).
  • Page 23 2.4. CONNECTING THE SERIAL PORTS IN SYNCHRO MODE ............2-7 2.5. GPS RECEIVER INSTALLATION (G OPTION) ................2-8 2.5.1. Mounting the GPS Smart Antenna ................... 2-8 2.5.2. Connecting the GPS Smart Antenna to the 5600MSC ............. 2-9 2.5.3. System Startup ....................... 2-11 Revision 1.6...
  • Page 24 Figure 2-1: 5600MSC Rear Panel........................2-1 Figure 2-2: Typical GPIO Circuitry.........................2-7 Figure 2-3: Pole Mounting the Smart Antenna....................2-9 Figure 2-4: Accutime 2000 Smart Antenna to 5600MSC Interface Cable (Evertz part WA-T09) ....2-10 Figure 2-5: Accutime 2000 Extender Cable ....................2-10 Tables Table 2-1.
  • Page 25: Installation

    This BNC connector is for input for 5 or 10 MHz reference. When power is off, this output will be a direct relay connection to the 10 MHz OUT. The FREQUENCY REF menu item must be set to 10 MHz freq ref in order to lock the 5600MSC master oscillator to the 10 MHz input.
  • Page 26: Table 2-1. Standard Rj45 Wiring Colour Codes

    RJ-45 connector at each end. Make the network connection by plugging one end of the cable into the RJ-45 receptacle of the 5600MSC and the other end into a port of the supporting hub. The straight-through RJ-45 cable can be purchased or can be constructed using the pinout information in Table 2-1.
  • Page 27: Linear Time Code Connections

    Model 5600MSC Master Clock/SPG Manual be ON when the 5600MSC has established a good link to its supporting hub. This gives you a good indication that the segment is wired correctly. The LED will BLINK when the 5600MSC is sending or receiving data. The LED will be OFF if there is no valid connection.
  • Page 28: Parallel Remote Control And Auxiliary Connections

    5600MSC. IMPORTANT INSTALLATION NOTICE: For a reliable telephone connection to the modem in the 5600MSC, a direct telephone line must be used. This line must not pass through a PBX or similar key device. 2.1.7. Parallel Remote Control and Auxiliary Connections AUX I/O: A 9 pin female ‘D’...
  • Page 29: Analog Audio And Video Test Generator Connections (Stg Option)

    Model 5600MSC Master Clock/SPG Manual 2.1.8. Analog Audio and Video Test Generator Connections (STG Option) ANALOG TG OUT This BNC connector has an analog composite video output compatible with the SMPTE 170M or ITU 624-4 standards. The ANALOG TEST GEN group of sub-menus on the OUTPUT Setup menu is used to configure the Analog test generator outputs.
  • Page 30: Hd Sdi Test Generator Connections (Htg Option)

    2.1.11. Power Connections The 5600MSC has one or two (redundant supply is optional) universal power supplies that operate on either 100-115 or 220-240 volts AC at 50 or 60 Hz and automatically senses the input voltage. Power should be applied by connecting a 3-wire grounding type power supply cord to the power entry modules on the rear panel.
  • Page 31: Connecting The Serial Ports In Synchro Mode

    Synchro cable supplied with the 5600ACO or make your own as shown in Table 2-7. On the 5600MSC connected to the A inputs of the 5600ACO, set the Serial Port Mode to Synchro Tx. On the 5600MSC connected to the B inputs of the 5600ACO, set the Serial Port Mode to Synchro Rx. The system configuration of both units can now be accomplished by setting the menu items of the Master A unit only.
  • Page 32: Gps Receiver Installation (G Option)

    2.5. GPS RECEIVER INSTALLATION (G OPTION) The 5600MSC units (with the +G option fitted) are designed to work with the Trimble Accutime 2000 Smart Antenna that can be located up to 1000 feet from the 5600MSC unit. The Smart Antenna houses the GPS receiver, antenna, power supply and other support circuitry in a sealed, shielded, self- contained unit with a digital interface to the main unit.
  • Page 33: Connecting The Gps Smart Antenna To The 5600Msc

    9 pin male subminiature D connector and should be connected to the GPS connector on the rear panel of the 5600MSC. The pin out of the cable is shown in Figure 2-4. If you require a longer cable, a 100 foot (Evertz part WA-T76) or 400 foot cable (Evertz part WA-T11) may be...
  • Page 34: Figure 2-4: Accutime 2000 Smart Antenna To 5600Msc Interface Cable (Evertz Part Wa-T09)

    When securing the cable, start at the antenna and work towards the 5600MSC unit. Connect the 9 pin male D connector to the GPS connector on the rear panel of the 5600MSC. Power is provided from the 5600MSC along the interface cable to the smart antenna.
  • Page 35: System Startup

    During this time the GPS STATUS display on the front panel will show the various stages of initialization. For complete information on configuring the 5600MSC operate with the GPS Smart antenna see section 3.8 of this manual INSTALLATION Page 2-11...
  • Page 36 Model 5600MSC Master Clock/SPG Manual This page left intentionally blank Page 2-12 INSTALLATION Revision 1.6...
  • Page 37 Model 5600MSC Master Clock/SPG Manual CHAPTER 3: OPERATION TABLE OF CONTENTS HOW TO OPERATE THE MASTER CLOCK/SPG............3-1 3.1. AN OVERVIEW OF KEY AND DISPLAY FUNCTIONS .............. 3-1 3.1.1. The Setup Menu Pushbutton Group ................. 3-1 3.1.2. The Display Button Group ....................3-2 3.1.3.
  • Page 38 Model 5600MSC Master Clock/SPG Manual 3.6.1.8. Enabling Daylight Saving Time Compensation on the LTC Output ....... 3-21 3.6.1.9. Enabling the LTC Output Parity Bit ................ 3-21 3.6.1.10. Enabling LTC Output Colour Frame Bit ..............3-21 3.6.1.11. Setting The LTC Output Level ................3-21 3.6.2.
  • Page 39 Model 5600MSC Master Clock/SPG Manual 3.6.7.2.2. Selecting the HD SDI Test generator Genlock Type........3-39 3.6.7.3. Setting The Phase of the HD SDI Video Test Generator Output ......3-40 3.6.7.4. Configuring the HD SDI Video Test Generator On Screen Message Display ..3-41 3.6.7.4.1.
  • Page 40 3.7.6.2. Setting the Beginning and End of Daylight Saving Time ........3-62 3.7.6.3. Setting The DST Offset..................3-63 3.7.7. Firmware Utilities ......................3-63 3.7.7.1. Viewing the 5600MSC Firmware Version .............. 3-63 3.7.7.2. Upgrading the 5600MSC Firmware ............... 3-63 3.7.7.3. Viewing the HD Test Generator Firmware Version..........3-64 3.7.7.4.
  • Page 41 Model 5600MSC Master Clock/SPG Manual This page left intentionally blank Revision 1.6...
  • Page 43: How To Operate The Master Clock/Spg

    A front panel Setup menu provides a quick and simple method of configuring the 5600MSC for your application. Sections 3.2 to 3.8 give detailed information on the specific operations required to control the 5600MSC.
  • Page 44: The Display Button Group

    Model 5600MSC Master Clock/SPG Manual When in one of the Setup menus the ESC key is used to move to the next lower sub- menu levels or to select a menu parameter that is to be changed. The ESC key is also used to cancel the process of entering numeric data.
  • Page 45: An Overview Of The Status Indicators

    Model 5600MSC Master Clock/SPG Manual 3.1.5. An Overview of the Status Indicators There are 10 status indicators located on the front panel that show operational status of the 5600MSC at a glance. PANEL LOCK This green LED indicates that the Front Panel is locked against accidental changes.
  • Page 46: Front Panel Display Functions

    Model 5600MSC Master Clock/SPG Manual 3.2. FRONT PANEL DISPLAY FUNCTIONS 3.2.1. Front Panel Displays The DISPLAY key is used to select what data is being displayed in the alphanumeric display. After you press the DISPLAY key, you can use the keys or the shaft encoder knob to select the various Display items.
  • Page 47: Gps Status Messages

    The 5600MSC is not currently locked to its frequency reference or the Freq Free Run Frequency Ref menu item is set to Internal freq ref An indication of where the 5600MSC is in its process of locking to its xxx% Ref Lock frequency reference An indication of the reference frequency compared to the internal Ref Freq xx.x%...
  • Page 48: Modem Status

    The modem is hanging up, either because the call was complete, or Hanging up because it timed out. 3.3.5. NTP Messages The current I.P. Address of the 5600MSC in decimal dot format. Axxx.yyy.zzz.aaa The current I.P. Gateway Address of the 5600MSC in decimal dot Gxxx.yyy.zzz.aaa format.
  • Page 49: Power Supply Status Messages

    AN OVERVIEW OF THE SETUP MENU SYSTEM The key to the operational flexibility of the 5600MSC lies in the Setup menu system. The Setup menu system uses the 16 digit alphanumeric display and provides a quick, intuitive method of configuring 5600MSC, guiding you to the correct setup for your application.
  • Page 50 SELECT key to save these items. When two 5600MSC units are operating in a dual redundant configuration, the COM ports of the two units can be interconnected and one of the units can send all its menu settings to the other unit, so they are configured identically.
  • Page 51: Configuring The Input References

    The INPUT SETUP menu is used to set up various items related to the input references to the 5600MSC. The chart below shows the items available in the INPUT SETUP menu. Sections 3.5.1 to 3.5.6 give detailed information about each of the sub menus.
  • Page 52: Figure 3-2: Sync Generation - Gps Frequency Reference

    Model 5600MSC Master Clock/SPG Manual Field 1 of NTSC 10 field sequence (see SMPTE 318M) 160.16 sec (4800 NTSC frames) 59.94 Hz Sync Generation Master Frequency DARS Frequency Locking Generation Generator Menu Settings INPUT FREQUENCY REF GPS freq ref 160.16 sec (4004 PAL frames)
  • Page 53: Figure 3-5: Sync Generation - 10 Mhz Reference - Ntsc Outputs

    Model 5600MSC Master Clock/SPG Manual Field 1 of NTSC 10 field sequence (see SMPTE 318M) 160.16 sec (4800 NTSC frames) 59.94 Hz Sync Generation May be X or Z May be X or Z DARS Phase Locking Preamble Preamble Master...
  • Page 54: Configuring The Time Reference

    The user must enter the initial time using the numeric keys on the front panel. After the time has been set once, the 5600MSC will use an internal battery-backed up clock to restore the time after a power disruption.
  • Page 55 Model 5600MSC Master Clock/SPG Manual When set to 25 Hz LTC tm ref the 5600MSC system time is referenced to time information being read at the LTC input port. The incoming time must be 25 Frames per second. When set to 25 Hz LTC tm nd the 5600MSC system time is referenced to time information being read at the LTC input port.
  • Page 56: Setting The Vitc Reader Line

    GENLOCK RANGE reference. The FREQUENCY REF menu item must be set to Video freq ref GL range narrow in order to lock the 5600MSC to an external video reference (see section GL range wide 3.5.1). Set this menu to GL range narrow when the frequency stability of the genlock video is tightly controlled and within 0.1 ppm.
  • Page 57: Synchronizing The System Master Oscillator To The Frequency Reference Immediately3-15

    The front panel display will show SYSTEM JAMMED for 0.6 seconds after the oscillator has been synchronized. The internal frequency reference oscillator in the 5600MSC is calibrated at the factory to that it can quickly stabilize when power is applied to the unit.
  • Page 58: Configuring The Lock Speed

    Abrupt lock to GL range narrow . Slow lock When set to Abrupt lock the 5600MSC will make a sudden change in internal oscillator to bring it into lock with the time and frequency reference being applied. This setting may cause disturbances to the sync and timecode outputs as the unit relocks to its reference.
  • Page 59: Configuring The Outputs

    The OUTPUT SETUP menu is used to set up various items related to the different outputs of the 5600MSC. The chart below shows the items available in the OUTPUT SETUP menu. Sections 3.6.1 and 3.6.2 give detailed information about each of the sub menus.
  • Page 60: Selecting Normal Or Powered Ltc Output (Ltc1 Output Only)

    XLR connector will be a standard SMPTE 12M signal or whether it will be LTC 1 OUTPUT modulated to drive Evertz 1200 series clocks operating in slave mode. The LTC 1 Power LTC 1 output on the 9 pin D connector does not have the capability of L1 power off powering the 1200 series clocks.
  • Page 61: Selecting When The Ltc Time Is Synchronized To The System Time

    Model 5600MSC Master Clock/SPG Manual Select L1 rate 25.00 to generate time code that counts at 25 frames per second and has a bit rate of 2000 bits per second. This LTC will run at exactly real time and is often used for driving master clock systems. This time code will be synchronous to video sync pulse outputs in the PAL-B, 1080i/50, and 720p/50 video standards.
  • Page 62: Synchronizing All The Ltc And Vitc Times To The System Clock Immediately

    Model 5600MSC Master Clock/SPG Manual 3.6.1.5. Synchronizing All The LTC and VITC Times to the System Clock Immediately OUTPUT This menu item allows the user to synchronize the LTC 1, LTC 2 and all the VITC output times to the System Time immediately.
  • Page 63: Enabling Daylight Saving Time Compensation On The Ltc Output

    3.6.2. Configuring the Video Sync Outputs There are two banks of three video sync outputs (for a total of six outputs) available on the 5600MSC. The format of each output can be set independently of each other with the restriction that all outputs in bank 1 (S1, S2, and S3) or bank 2 (S4, S5 S6) must be operating at the same clock frequency.
  • Page 64: Selecting The Clock Frequency For Each Bank Of The Sync Outputs

    The maximum voltage output of the timing pulses is approximately 1 volt p-p. Users may have to increase the amplitude of these pulses by using a Evertz equalizing DA (model 7700ADA-EQ or 500ADA-EQ) with the gain set to maximum in order to interface these pulses to other equipment.
  • Page 65: Configuring The Vitc Generator For The Colour Black Outputs

    Model 5600MSC Master Clock/SPG Manual OUTPUT SYNC 1 OUTPUT S1 1080i/60 Tri-level sync in the 24, 25, 30 and 60 frames per second high definition S1 1080i/50 standards is available when the respective Bank Setup menu item is set to S1 1080p/24sf HD 1.000 .
  • Page 66: Selecting The Vitc Lines

    OUTPUT These menu items select the lines on which the VITC will be inserted when the VITC enable menu item is set to VITC On . The 5600MSC keeps track SYNC 1 OUTPUT of the lines for both the PAL and NTSC video standards, you will have to set Sync 1 VITC Ln 1 the line numbers separately for each video standard.
  • Page 67: Enabling Colour Frame Compensation On The Vitc Output

    Model 5600MSC Master Clock/SPG Manual 3.6.2.3.4. Enabling Colour Frame Compensation on the VITC Output OUTPUT This menu item allows the user to control whether colour frame compensation will be applied to the Sync 1 output’s VITC time. SYNC 1 OUTPUT...
  • Page 68: Synchronizing The Vitc Time To The System Clock Immediately

    Model 5600MSC Master Clock/SPG Manual 3.6.2.3.6. Synchronizing The VITC Time to the System Clock Immediately OUTPUT This menu item allows the user to synchronize the Sync 1 output’s VITC time to the System Time immediately. This synchronization will also happen...
  • Page 69: Setting The Vitc Time Zone

    Model 5600MSC Master Clock/SPG Manual 3.6.2.3.9. Setting The VITC Time Zone OUTPUT This menu item allows the user to set a time zone offset between the system time and the Sync 1 output’s VITC time. The time zone offset value...
  • Page 70: Enabling Ten Field Pulse

    Model 5600MSC Master Clock/SPG Manual 3.6.2.3.11. Enabling Ten Field Pulse OUTPUT This menu item allows the user to control whether SMPTE 318M compatible ten field pulse sequence is inserted on the sync output. This pulse SYNC 1 OUTPUT sequence is commonly used to synchronize the AES audio sample Sync 1 Ten Field distribution over ten field of NTSC video.
  • Page 71: Figure 3-10: Video Sync Phase Alignment In 50 Hz Field Rate Systems

    Model 5600MSC Master Clock/SPG Manual 1125/50/I Video signal 1122 1123 1124 1125 625/50/I Video signal Figure 3-10: Video Sync Phase Alignment in 50 Hz Field Rate Systems The front panel display will show WARNING LIVE CTL for 0.6 seconds to indicate that adjusting the Sync output phase menu items will affect the phasing of the respective Sync output immediately.
  • Page 72: Configuring The Analog Video Test Generator Output (Stg Option Only)

    Model 5600MSC Master Clock/SPG Manual For example if the Colour Frame is 2, V Phase is 255, H Phase is 7 and fine phase is 0.0% then while adjusting the H Phase upwards by 3 steps, the display will show 00.0...
  • Page 73: Configuring The Analog Video Test Generator On Screen Message Display

    3.6.3.3. Configuring the Analog Video Test Generator On Screen Message Display The 5600MSC Analog Video Test generator has a programmable 16-character text message that may be used to display a source identification message or any other information on the screen.
  • Page 74: Setting The Font Size Of The On Screen Message Display

    Model 5600MSC Master Clock/SPG Manual 3.6.3.3.4. Setting the Font Size of the On Screen Message Display OUTPUT The ATG Message Font menu item is used to turn set the size of the font used for the Analog Video Test Generator On Screen Message Display.
  • Page 75: Table 3-3: 525 Line Test Signal Selection

    Model 5600MSC Master Clock/SPG Manual Test Signal Name Test Signal Name SMPTE Color bars FCC Multiburst 75% Color bars FCC Composite 100% Color bars Chroma Freq. Response Composite Signal NTC 7 Combination 2T Pulse and Bar NTC 7 Composite SinX/X Pulse...
  • Page 76: Configuring The Sdi Video Test Generator Output (Stg Option Only)

    3.6.5.3. Configuring the SDI Video Test Generator On Screen Message Display The 5600MSC SDI Video Test generator has a programmable 16-character text message that may be used to display a source identification message or any other information on the screen.
  • Page 77: Editing The On Screen Message Display

    Model 5600MSC Master Clock/SPG Manual 3.6.5.3.1. Editing the On Screen Message Display OUTPUT The STG Message Text menu item is used to edit the text message. When you enter the STG Message Text menu item, the actual text message is...
  • Page 78: Enabling The Sdi Embedded Audio Channel In The Test Signal Output

    Model 5600MSC Master Clock/SPG Manual 3.6.5.4.1. Enabling the SDI Embedded Audio Channel in the Test Signal Output There are identical menus for each of the 4 groups. For the sake of simplicity only the menu item for group is described in the manual.
  • Page 79: Setting The Sdi Embedded Audio Channel Frequency

    Model 5600MSC Master Clock/SPG Manual 3.6.5.4.3. Setting the SDI Embedded Audio Channel Frequency There are identical menus for each of the audio channels. For the sake of simplicity only the menu item for channel 1 is described in the manual.
  • Page 80: Setting The Sdi Embedded Audio Ident Mode

    Model 5600MSC Master Clock/SPG Manual 3.6.5.4.5. Setting the SDI Embedded Audio Ident Mode OUTPUT The STG Ident Type menu item is used to select the type of left right ident used when the STG AUD x Freq menu item for a specific channel is set to SDI TEST GEN ident.
  • Page 81: Configuring The Hd Sdi Video Test Generator Output (Htg Option Only)

    This menu item sets whether the HDSDI Test generator will free run on its OUTPUT internal crystal oscillator or be referenced to a genlock signal from one of HD TEST GEN the 5600MSC sync outputs connected to the TG GEN LOCK input. HTG Genlock HTG genlock off HTG genlock on 3.6.7.2.2.
  • Page 82: Setting The Phase Of The Hd Sdi Video Test Generator Output

    1080i/59.94, 1080p/29.97, 1080p/29.97sF, 1035i/59.94 Table 3-5: Valid Genlock Types Note: 720p/50 is only available when the 5600MSC is fitted with a 7751TG2-HD Test generator Card. You can use the Firmware menu item on the GENERAL menu to determine if your unit is fitted with the 7751TG2-HD or not.
  • Page 83: Configuring The Hd Sdi Video Test Generator On Screen Message Display

    3.6.7.4. Configuring the HD SDI Video Test Generator On Screen Message Display The 5600MSC HD SDI Video Test generator has a programmable 16-character text message that may be used to display a source identification message or any other information on the screen.
  • Page 84: Setting The Outputs For Screen Message Display

    Model 5600MSC Master Clock/SPG Manual 3.6.7.4.4. Setting the Outputs for Screen Message Display OUTPUT The HTG Msg Output menu item is used to determine which outputs of the HD SDI Video Test Generator will show the On Screen Message Display.
  • Page 85: Setting The Embedded Audio Frequency

    Model 5600MSC Master Clock/SPG Manual 3.6.7.5.2. Setting the Embedded Audio Frequency On units fitted with the 7750TG2-HD Test generator card there are 4 identical menus to set the audio signal for each of the audio channels in the group selected by the HTG Audio Group menu item.
  • Page 86: Setting The Display Time For The Signal Name Display

    Model 5600MSC Master Clock/SPG Manual These menu choices are only available on units fitted with the 7751TG2-HD. OUTPUT The HTG Audio Output menu item is used to select whether the outputs of the HD SDI Test Signal Generator will contain embedded or not.
  • Page 87: Configuring The Hd Sdi Test Generator Colour Space

    Table 3-6 shows the test signals that are available. Most of the test signals are industry standard signals. Sections 3.6.8.1 to 3.6.8.3 describe the test signals that are unique to the 5600MSC. The name of the current test signal is shown on the front panel display. TECHNICAL DESCRIPTIONOPERATION Page 3-45 Revision 1.6...
  • Page 88: Clean Aperture With Graticule

    Model 5600MSC Master Clock/SPG Manual The front panel display will show WARNING LIVE CTL for 0.6 seconds to indicate that changing the HD Test Generator test signals will affect the Analog Test Generator output immediately. You do not have to press the SELECT button to accept the new values.
  • Page 89: Production Aperture

    Model 5600MSC Master Clock/SPG Manual 3.6.8.1. Clean Aperture with Graticule This signal contains a number of key physical dimensions of the HDTV active picture area. It divides the 16x9 aspect ratio clean aperture area into an 8x6 graticule grid. The center 6x6 grid corresponds to a 4x3 aspect ratio rectangle that is concentric with the 16x9 clean aperture.
  • Page 90: Setting The Global Phase Offset Value

    For the sake of simplicity in the manual only the menus for Audio Event 1 will be described. The AUDIO EVENT menus only affect the analog audio output of the 5600MSC. The AES and DARS outputs are configured using the AES/DARS OUTPUT menus.
  • Page 91: Setting The Audio Level Sound Type

    Model 5600MSC Master Clock/SPG Manual 3.6.11.1. Setting the Audio Level Sound Type OUTPUT This menu item sets the level of sound. It applies to all of the events. AUDIO LEVEL The level ranges from –20dBu to +8dBu in 0.2dBu steps.
  • Page 92: Setting The Audio Event Sound Type

    Model 5600MSC Master Clock/SPG Manual 3.6.11.3. Setting the Audio Event Sound Type OUTPUT This menu item sets the type of sound will occur at the audio event start time. The frequency of the audio sound is set by using the A1 Sound Freq AUDIO EVENT 1 menu item.
  • Page 93: Configuring The Dars And Aes Outputs (Stg Option Only)

    Model 5600MSC Master Clock/SPG Manual Example 1: Create a sequence to have a single 1 second duration 1 kHz beep once per hour at the half hour and a double 1 second beep once per hour at the hour. 1. Set the Audio 1 Start Time to 99:00:00:0. Set the Audio 1 Sound Type to Beep . Set the Audio 1 Sound Freq to 1.0 kHz .
  • Page 94: Setting The Aes Channel Frequency

    Model 5600MSC Master Clock/SPG Manual 3.6.12.2. Setting the AES Channel Frequency There are two identical menus for each of the audio channels on the AES output. For the sake of simplicity only the menu item for channel 1 is described in the manual.
  • Page 95: Configuring The Aes/Dars Lock Type

    Model 5600MSC Master Clock/SPG Manual 3.6.12.4. Configuring the AES/DARS Lock Type OUTPUT The AES Lock Type control is used to select how the AES/DARS output will be aligned to the video. When the dominant output video standard is AES/DARS OUTPUT NTSC-M or 1.001 HD rates we recommend setting this control to...
  • Page 96: General Configuration Items

    The GENERAL SETUP menu is used to set up various items related to the overall operation of the 5600MSC. Table 3-7 shows the items available in the GENERAL SETUP menu. Sections 3.7.1 to 3.7.15 give detailed information about each of the sub menus.
  • Page 97: Configuring The Serial Port Mode

    5600MSC units. You will be able to view the menu settings but not change most of them. You can also set the TIME REF to Synchro time ref .
  • Page 98: Configuring What Items Are Ignored In Syncro Rx Mode

    5600MSC fitted with the modem option in order to obtain its time reference. Alternately, if the 5600MSC is fitted with the GPS option, it can be set up as a master time source for other 5600MSCs to call in to.
  • Page 99: Setting The Modem Operating Mode

    Model 5600MSC Master Clock/SPG Manual 3.7.3.1. Setting the Modem Operating Mode GENERAL This menu item sets the operational mode of the modem MODEM SETUP When the Modem Mode is set to modem off the modem will not answer or Modem Mode dial automatically.
  • Page 100: Setting The Modem Phone Number To Dial

    MODEM SETUP such as the Canadian National Research Council (NRC) or another Phone number 5600MSC that is referenced to GPS time. 000-000-000 When you press the SELECT key the current phone number will be displayed. If you want to exit the phone number entry mode press the ESC key at any time.
  • Page 101: Dialing The Modem Immediately

    Model 5600MSC Master Clock/SPG Manual 3.7.3.6. Dialing the Modem Immediately GENERAL This menu item forces the modem to dial out to a remote system to get the time immediately regardless of the setting of the Modem Mode menu item. MODEM SETUP It will not retry, regardless of the settings of Modem retries.
  • Page 102: Configuring The Function Of The General Purpose Inputs

    GPI 1 FUNCTION When set to Gpi 1 not used the respective general purpose input will not Gpi 1 not used affect the operation of the 5600MSC. Gpi 1 sdi signal Gpi 1 atg signal When set to Gpi 1 sdi signal, a falling level on the respective general purpose input will cause the sdi test generator to toggle to the next test signal.
  • Page 103 Model 5600MSC Master Clock/SPG Manual To make DST work, the clocks have to be adjusted one hour ahead when DST begins, and adjusted back one hour to standard time when DST ends. There are many countries observing DST, and many who do not.
  • Page 104: Setting The Dst Date Entry Mode

    For further information about daylight saving time in your area consult the web page http://www.timeanddate.com/time/aboutdst.html. Because of the variation of daylight saving time rules throughout the world, the 5600MSC has several registers to allow the user to set the DST rules for their region. There is a set of DST registers for the LTC and each of the video outputs.
  • Page 105: Setting The Dst Offset

    DST offset 1 hour 3.7.7. Firmware Utilities The Firmware menu item allows you to view the firmware version that is installed in the 5600MSC and to upgrade the firmware when a new version is released. 3.7.7.1. Viewing the 5600MSC Firmware Version GENERAL This item is used to display the 5600MSC’s firmware version.
  • Page 106: Viewing The Hd Test Generator Firmware Version

    This menu item is used to switch between Engineering mode and User mode. In User mode various menu items can be hidden to simplify the operation of the 5600MSC. In Engineering mode, all menu items are shown, and Vista LINK control is enabled to allow hiding various menus for User mode.
  • Page 107: Saving And Storing 5600Msc Presets

    Get EUROPE Fact sets all the outputs to PAL rates wherever possible. Using any GET may change any of the settings of the 5600MSC. It may disrupt the timing of all the sync outputs, and the LTC and VITC timecodes and therefore must be used with caution.
  • Page 108: Configuring The Internet Protocol Address

    123.321.255.111 3.7.10.2. Setting up the Internet Protocol Address Mode GENERAL This item is used to determine if the IP address of the 5600MSC will be determined from another server or will be set locally. IP RULES IP Address Mode...
  • Page 109: Setting Up The Internet Protocol Gateway Enable

    NTP server (the 5600MSC) shall indicate an unlocked condition when it has no reference. The 5600MSC must have its TIME REF menu item set to GPS time ref , with a GPS antenna connected to show a GPS locked condition. (The STATUS display message will say Time GPS Locked .) The 5600MSC may also have its TIME REF menu item set to Modem time ref ,...
  • Page 110: Setting Up The Ntp Restriction Mask

    Setting up the NTP Restriction Mask. GENERAL This item is used to set the restricted Internet Protocol mask for restriction 1. Restricted addresses are addresses that the 5600MSC will NOT respond to. NTP RULES Ntp restrict 1 Restrict 1 mask 123.123.355.111...
  • Page 111: Setting The User Bits In Manual User Bit Mode

    Model 5600MSC Master Clock/SPG Manual 1. Press the GENERAL key to enter the GENERAL SETUP menu. Use the arrow keys ( , ) or turn the SHAFT ENCODER knob to display the Set System Date menu item and press the SELECT key.
  • Page 112: Setting The User Bits Mode

    The format for longitude is wxxxyyzz where w is 3 for west, and 4 for east. xxx is degrees, yy is minutes, and zz is fractions of minutes. For example, at Evertz Microsystems factory, the data is: 20432049 and 30794623 which corresponds to 43 degrees, 20.49 minutes north and 79 degrees,...
  • Page 113: Operating With Global Positioning System Lock (G Option)

    OPERATING WITH GLOBAL POSITIONING SYSTEM LOCK (G Option) When the GPS option is installed, the 5600MSC can be both frequency and time locked to the Global Positioning system (GPS). The following section described an overview of the GPS system and the operation of the 5600MSC when it is locking to the GPS satellites.
  • Page 115: Figure 4-1: Vistalink Figure 4-2: Vistalink Figure 4-3: Vistalink

    4.3. SERVICING INSTRUCTIONS...................... 4-8 4.3.1. Changing The Fuses ......................4-8 4.4. CONFIGURING WHAT MENUS WILL BE SEEN IN USER MODE USING VistaLINK .... 4-8 ® 4.4.1. Connecting the 5600MSC to Vista LINK ................4-9 ® 4.4.2. Installing Vista LINK ......................4-9 ®...
  • Page 116 Model 5600MSC Master Clock/SPG Manual This page left intentionally blank Revision 1.6...
  • Page 117: Technical Description

    Model 5600MSC Master Clock/SPG Manual TECHNICAL DESCRIPTION 4.1. SPECIFICATIONS 4.1.1. Analog Sync Outputs: Standards: SMPTE 170M (NTSC-M), ITU-R BT.470-6 (PAL-B) SMPTE 274M (1080i/60, 1080i/50,1080p/30, 1080p/30sF, 1080p/25, 1080p/25sF, 1080p/24, 1080p/24 and the 1/1.001 divisor versions where applicable) SMPTE 296M (720/60, 720p/59.94) 1 Hz and 6 Hz pulse (and the 1/1.001 divisor versions)
  • Page 118: Genlock Input

    Model 5600MSC Master Clock/SPG Manual 4.1.4. Genlock Input Type: autodetects standard SMPTE 170M (NTSC-M), ITU-R BT.470-6 (PAL-B) Colour Black 1 V p-p Composite Bi-level sync (525i/59.94 or 625i/50) 300 mV HD Tri-level Sync (same HD standards as sync outputs) Connector:...
  • Page 119: Dars & Aes Test Generator Outputs (Stg Option Installed)

    Model 5600MSC Master Clock/SPG Manual 4.1.7. DARS & AES Test Generator Outputs (STG option installed) Standard: Unbalanced: SMPTE 276M Single ended AES (24 bits) Balanced: AES3-1992 (24 bits) Number of Outputs: DARS: 1 unbalanced, 1 balanced AES Test Gen :...
  • Page 120: Sdi Test Generator Outputs (Stg Option Installed)

    Model 5600MSC Master Clock/SPG Manual 4.1.10. SDI Test Generator Outputs (STG option installed) Standard: SMPTE 259M-C (270 Mb/s) Number of Outputs: 2 outputs of selected test signal 2 outputs of black video Embedded Audio: Up to 4 groups as specified in SMPTE 292M...
  • Page 121: Upgrading The Firmware

    UPGRADING THE FIRMWARE 4.2.1. Overview The firmware in the 5600MSC and the internal HD SDI Test generator is contained on two separate FLASH EPROMs. From time to time firmware updates will be provided to add additional features to the unit.
  • Page 122: Initiating Firmware Upgrade Mode From The Terminal Program

    7 to 12. 7. Power up the 5600MSC Master Clock/SPG. After the unit powers up, a banner with the boot code version information should appear in the terminal window. The cursor to the right of the word “BOOT>”...
  • Page 123: Completing The Upgrade

    5600MSC.bin There are two different versions of HD test generator cards that may be installed in the 5600MSC. The front panel will show the version that is installed. Make sure that you upload the correct version for your unit.
  • Page 124: Servicing Instructions

    ® configure what menu items will be shown when the 5600MSC is set to user mode. This allows the operation of the 5600MSC to be simplified to just a few menu items required for operational control and prevents users from changing critical parameters that may disturb the operation of the sync and time code system.
  • Page 125: Connecting The 5600Msc To Vistalink

    Follow the instructions in section 2.1.4 to connect the 5600MSC to the Ethernet network. Once you have established a physical connection you will need to set up the IP addresses of the 5600MSC using the IP Rules menu items on the GENERAL menu.
  • Page 126: Figure 4-1: Vistalink Configuration - Input Menu Pruning

    Model 5600MSC Master Clock/SPG Manual You can not send the configuration to a 5600MSC that is operating in User mode. You must first set it to Eng mode using the Eng/User Mode menu item on the GENERAL menu. Figure 4-1: VistaLINK Configuration –...
  • Page 127: Figure 4-2: Vistalink Configuration - Output Menu Pruning

    Model 5600MSC Master Clock/SPG Manual Figure 4-2: VistaLINK Configuration – Output Menu Pruning ® TECHNICAL DESCRIPTION Page 4-11 Revision 1.6...
  • Page 128: Figure 4-3: Vistalink Configuration - General Menu Pruning

    Model 5600MSC Master Clock/SPG Manual Figure 4-3: VistaLINK Configuration – General Menu Pruning ® Page 4-12 TECHNICAL DESCRIPTION Revision 1.6...

Table of Contents

Save PDF
