SAFETY WARNINGS

Tool Free Bed with Enclosure Rails
Tool Free beds are designed for nine different configurations. For safety, beds should be only
configured in one of these nine styles and are not to be assembled in any other manner. For proper
assembly of the bed frame please follow the Tool Free Bed Assembly Instructions attached as it
relates to you particular choice of bed style.
1.
Each bed has been designed for a specific mattress size so that no greater than 1" is left
between the mattress and the bed end structure to prevent the likelihood of serious injury or
fatalities due to entrapment or falls. The table below specifies the appropriate and only
mattress size to be used with each bed. Absolutely do not use a different mattress size!
ITEM #
TF22BM3674
TF22BM3680
TF22BM3874
TF22BM3880
TF22BO3674
TF22BO3680
TF22BO3874
TF22BO3880
2.
Guardrails are available and required for bunking or lofting beds. Check with your
Student Housing staff. Guardrails are to be used on both sides of the top bed when
bunked or lofted. Top pin location in not to be used when bunked or lofted.
3.
Top surface of mattress must be at least 5" (five inches) below the upper edge of the
guardrails if guardrails are in use. A guardrail may terminate before reaching the bed end
structure, providing there is no more than 15 inches between either end of the guardrail and
the bed end structures in the same plane.
4.
Do not allow children under six years of age to use the upper bunk.
5.
Periodically check and ensure that the guardrails, ladder, and other components are in their
proper position, free from damage, and that all connectors are tight. Four each 3/8"
diameter x 4" long steel pins should be used - one at each post connection - when lofting or
bunking Tool Free Beds.
6.
Do not allow horseplay on or under the bed and prohibit jumping on the bed.
7.
Only use the built-in ladder formed by the end slats of the bed boards or the ladder
provided for entering and leaving the upper bed if in a loft or a bunk.
8.
Do not use substitute parts. Contact your Student Housing staff for correct substitute or
repair parts. You may contact us directly for information.
RT London-Norse
8605 Commerce Place Drive NE
RT London-Norse, 8605 Commerce Place NE, Lacey, WA 98516, Ph# 360-943-5090, Fax# 360-943-8596
Instructions for Tool Free beds, Page 1
NOMINAL
MATTRESS SIZE
36" x 74-75"
36" x 80"
38" x 74-75"
38" x 80"
36" x 74-75"
36" x 80"
38" x 74-75"
38" x 80"
NOMINAL
MATTRESS THICKNESS
No less than 7"
No less than 7"
No less than 7"
No less than 7"
No less than 7"
No less than 7"
No less than 7"
No less than 7"
