Summary of Contents for Airtech Information & Communication Co. ATP-100
- Page 1 User’s Manual Land Mobile Radio (LMR) Model: ATP-100...
- Page 2 APPROVAL Always use Airtech supplied accessories (antennas, batteries, belt clips, speaker/mics, etc.). Use of unauthorized 1. FCC Approval accessories can cause the FCC RF exposure compliance requirements to be exceeded. FCC ID: ONKATP-100 Always keep the antenna at least 2.5 cm (1 inch) away from 1) Safety Training Information the body when transmitting and only use the belt-clips, when attaching the radio to your belt, etc., to ensure FCC RF...
- Page 3 RF Exposure It is designed and manufactured not to exceed the emission limits for exposure to radio frequency (RF) Tests for SAR are conducted using standard operating energy Federal Communications positions specified by the FCC with the phone Commission of the U.S. Government. These limits are transmitting at its highest certified power level in all part comprehensive...
-
Page 4: Table Of Contents
CONTENTS General Features Ultra compact design & size (102(W)x50(H)x36(D), 310g with high capable battery) GENERAL FEATURES..........4 Heavy duty durable construction UNPACKING..............5 256 channels OPTIONAL ACCESSORIES.........5 38 CTCSS/ 83 CDCSS/ 83 INVERR CDCSS GETTING READY............2 PC Programmable, transferable by cloning DESCRIPTION..............3 Time-out timer (TOT) OPERATION ..............4 Busy Lockout (BCLO) -
Page 5: Unpacking
transceiver so that the tabs on the transceiver engage Unpacking the four openings in the battery pack. Slide the battery pack toward the top of the transceiver until a click heard. Unpack and check that all items have been enclosed. Removal: Turn off the transceiver. -
Page 6: Description
ⓒ Helical Antenna. ⓓ Tx / Rx Indicate LED (3 colors) Description Transmitting Blinking Low battery Receiving, monitoring Green Blinking Different sub-tone when receiving Initializing, programming Orange cloning ⓔ External Earphone/MIC and Programming Jack Socket ⓕ Speaker ⓖ Tx Output H/L ⓗ... -
Page 7: Operation
channel. During priority scanning you may talk Operation c. on the last busy channel by pressing the function button and up button. After completing 1. Power on / off and Volume Control: the conversation, restart scan. Rotate the Power on/off and Volume Control Switchⓑ To delete a busy channel from scan, press clockwise to turn power on, then the LED lights orange down button. -
Page 8: Charger And Battery
Charger and Battery 1. Battery (Li-ion) Voltage DC 7.5V Duty time (5-5-90) Over 10 hrs 2. Charger Input power (90~250VAC) Operating temperature 10-30 deg. C Connect the charger to an appropriate outlet (90~250 VAC). Turn the transceiver power off and place the radio into the front socket of the charger.
